PCSS-A Series Technical Manual
Table 8-6: PCSS operation parameters from the CNC (OperMode) 26-31
Note:
1
stream; it does not need to be mapped in the ISaGRAF application.
Page 56
Original Language Version: 1.25
Channel # Description
26-27 Reserved
28 Foot Station 1
29 Foot Station 2
30 Foot Station 3
31 Foot Station 4
The PCSS-A kernel software extracts this data directly from the incoming data
Channel # Description
0 Left gate closed
1 Right gate closed
2 Back gate closed
3 Laser A front clear
4 Laser A middle clear
5 Laser A rear clear
6 Laser B front clear
7 Laser B middle clear
8 Laser B rear clear
9 Light guard clear
10 Spare
11 Spare
12 Spare
13 Spare
14 Spare
15 Spare
Table 8-7: PCSS Status to the CNC (Status)
Channel # Description
0-31 Spare
Table 8-8: Generic Analogue inputs (gA_in)
Channel # Description
0-31 Spare
Table 8-9: Generic Analogue outputs (gA_out)
Channel # Description
0-127 Spare
Table 8-10: Generic Digital inputs (gD_in)
Channel # Description
0-127 Spare
Table 8-11: Generic Digital outputs (gD_out)
1
1
1
1
