Power Supply Specifications
Input points
Input voltage
Input current
4.3.3
CN3 has input connections for up, down and error reset switches on a 12-way removable
terminal block. These are standard inputs (X00 – X11).
4.3.4
CN4 has input connections for valve monitors and door switches on a 12-way removable
terminal block. These are standard inputs (X12 – X23).
4.3.5
CN5 has input connections for emergency stop contactor feedback, emergency stop, door
and level switches on a 12-way removable terminal block. These are pulsed inputs (X24 –
X35).
4.3.6
CN6 has connections for pulsed outputs associated with the inputs on CN5, on a 12-way
removable terminal block. These are pulsed outputs (P24 – P35).
4.3.7
CN7 has miscellaneous input connections on a 12-way removable terminal block for the
PCSS-A1 and A2. Four pulsed inputs (X36 – X39) and four standard inputs (X40 – X43) are
available.
4.3.8
CN8 has miscellaneous output connections on a 12-way removable terminal block for the
PCSS-A1 and A2. Four pulsed outputs (P36 – P39) associated with the inputs on CN7, and
four standard outputs (Y12 – Y15) are available.
Original Language Version: 1.25
6
24 VDC ± 10%
24 A
CN3 Connections
CN4 Connections
CN5 Connections
CN6 Connections
CN7 Connections
CN8 Connections
