Lazer Safe PCSS-A Series Technical Manual page 209

LS-CS-M-046
12.20 Emergency Stop Option 20
These options are reserved and not available for selection.
12.21 Emergency Stop Option 21
Emergency Stop Option 21 is based upon Emergency Stop Option 3 with a modification to
the rear door switch arrangement.
12.21.1 Door Switches
Door Switch - Left
Door Switch - Right
Figure 12-12: Option 21 Door Switch Configuration (AIO Connections)
Note:
Additional software filtering can be applied when a light curtain is used for the
rear door monitoring. Ensure the latest software is installed into the PCSS-A if
required with this option. This allows for pulsing outputs that are usually
associated with some models of light curtains.
12.21.2 Level Limit Switches
The level limit switch wiring for Option 21 is identical to Option 3, as shown in
12.21.3 Emergency Stop Channels
The emergency stop channel wiring is identical to Option 1, as shown in
Original Language Version: 1.25
Door Switch - Rear
24 VDC
IOA – CN4
X23
12
X22
11
X21
10
X20
9
X19
8
X18
7
X17
6
X16
5
X15
4
X14
3
X13
2
X12
1
IOA – CN5
X35
12
X34
11
X33
10
X32
9
X31
8
X30
7
X29
6
X28
5
X27
4
X26
3
X25
2
X24
1
PCSS-A Series Technical Manual
IOA – CN6
P35
12
P34
11
P33
10
P32
9
P31
8
P30
7
P29
6
P28
5
P27
4
P26
3
P25
2
P24
1
Section 12.3.2.
Section 12.1.3.
Page 189
Released: 12/09/2024
