Lazer Safe PCSS-A Series Technical Manual page 265

LS-CS-M-046
Station
4
-
To select down switch option 5 during the PCSS configuration, set the initial value for down
switch option selection variable to 5 as described in
option and all required inputs are activated when the PCSS software is started.
15.12 Down Switch Option 6 – Four Operator Foot Control Only
The connections in this option allow four operator stations with foot pedal control on each as
shown in Figure 15-6
normally closed (NC) contacts from the foot pedal switches on each of the operator stations
are monitored. The NO contacts are monitored using standard inputs, while the NC contacts
are monitored using safety inputs.
Foot Pedal 4 - Down
Foot Pedal 3 - Down
Foot Pedal 2 - Down
Foot Pedal 1 - Down
This option provides selection for any two of the four available operator stations with either
the 1 Foot - 1 Foot operator mode on one of the stations selected or 2 Foot - 2 Foot on two
stations.
Original Language Version: 1.25
Station Station Station
3 2 1
- - -
Table 15-8: Down Switch Option 5 Compatible Operator Modes
for the AIO. In this application both the normally open (NO) and
24 VDC
Figure 15-6: Four Operator Foot Control (AIO Connections)
Station 4H 4H
02 4H 2F
Yes Yes Yes
Section
IOA – CN3
X11
12
X10
11
X09
10
X08
9
X07
8
X06
7
X05
6
X04
5
X03
4
X02
3
X01
2
X00
1
IOA – CN5
X35
12
X34
11
X33
10
X32
9
X31
8
X30
7
X29
6
X28
5
X27
4
X26
3
X25
2
X24
1
PCSS-A Series Technical Manual
2F 2H 2H
2F 2H F
Yes Yes Yes
9.2. This will ensure that this
IOA – CN6
P35
12
P34
11
P33
10
P32
9
P31
8
P30
7
P29
6
P28
5
P27
4
P26
3
P25
2
P24
1
Released: 12/09/2024
F
F
Yes
Page 245
