4.5 Conformity-assessed Devices
Display
2
Fig. 7: Weighing range display for conformity-assessed devices
(example)
Pos . Name Description
1 Labeled Labels the differentiated
points points.
2 Model- Optional display
specific
information
4.6
The buttons on the device may have different statuses.
The principle is explained with the following example:
1
Symbol
Entris
Operating Concept
Status Display of the Buttons
Name Description
Button The button is highlighted
enabled orange. Pressing the
button opens a menu, for
example.
Inactive The button is highlighted
button white. No action, e.g.,
toggle between weight
units, can be carried out.
