Operating Instructions
PMA.Evolution
EVO1Y1
Paint-mixing scales for use in potentially explosive atmospheres of zone 2
98648-020-45

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMA.Evolution EVO1Y1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sartorius PMA.Evolution EVO1Y1

Summary of Contents for Sartorius PMA.Evolution EVO1Y1

  • Page 1 Operating Instructions PMA.Evolution EVO1Y1 Paint-mixing scales for use in potentially explosive atmospheres of zone 2 98648-020-45...

  • Page 3: Table Of Contents

    ........... 14 Sartorius Service 6.1 Switching the Device On/Off...

  • Page 4: About This Document

    About This Document About This Document Validity These operating instructions apply to color-mixing scale models: − EVO1Y Symbols Used As a means of instruction and direct warning of hazards, all especially important text statements to be observed in these installation instructions will be marked as follows: This instruction denotes a possible danger with medium risk of death or severe injury if not avoided.

  • Page 5: Safety

    Do not operate the scale if its housing, AC adapter, or any connections are damaged. Immediately disconnect the damaged device from the power. Do not expose the scale, the AC adapter or the accessories supplied by Sartorius to extreme temperatures, aggressive chemical vapors, moisture, shocks, vibrations, or strong electromagnetic fields.
  • Page 6 (moisture, foreign bodies). Before cleaning the AC adapter or the scale: Disconnect all devices from the power. The scale should only be opened by Sartorius-trained personnel with the power disconnected. Do not open the AC adapter. Avoid generating static electricity on the glass panel of the touch screen and plastic casing.

  • Page 7: Intended Use

    Safety Intended Use This scale is only intended for mixing colors and paints. The scale is used in Zone 2 potentially explosive areas. Appropriate containers must be used for each type of material. The scale can be operated via the keypad as a stand-alone device or using applica- tion software (e.g., a paint-mixing program from a paint manufacturer) installed on a connected PC.

  • Page 8: Device Overview

    Device Overview Device Overview Front View Item Description Operating and display elements (see also Chapter 3.3, page 10) Stand Weighing pan EVO1Y1 Operating Instructions...

  • Page 9: Rear View

    Device Overview Rear View Item Description USB port Cable holders Stand AC adapter with country-specific mains adapter (optional) USB connection cable Anti-theft locking device Grounding terminal for equipotential bonding Menu access switch Leveling (verified models only) Leveling feet (verified models only) EVO1Y1 Operating Instructions...

  • Page 10: Operating And Display Elements

    Device Overview Operating and Display Elements Sharp or pointed instruments (such as ballpoint pens) can damage the device! − The touch screen should only be operated by lightly pressing it using the tips of your fingers. Function Factor key for paint-mixing applications Zeroing/taring &...
  • Page 11 Device Overview Item Function Activated function in the menu list (see Chapter 3.4, page 12) Maximum weighing range Minimum load Min (verified models only) Verification scale interval e (verified models only) Readability of the scale (scale interval d) In verified mode for devices where e ≠ d: The frame indicates a scale inter- val (standard scale interval d is smaller than verification scale interval e) Weight unit and stability indicator Communication with the PC...

  • Page 12: Menu List

    Device Overview Menu List The “o” in the active column indicates the activated function in the respective menu. Level 1 Level 2 Level 3 Active Level 4 Function CODE SETUP | - - - - SCALE | - - - AMBIEN. Setup location 1.1.1 |- - - -...
  • Page 13 Device Overview Level 1 Level 2 Level 3 Active Level 4 Function CODE | - - - REC.MOD. Recalculation 1.3.4 (SETUP) |- - - - Gross weight 1.3.4.1 TOTAL |- - - - Individual 1.3.4.2 INDIV. GEN.SRV. | - - - MEN.RES. Menu reset 1.9.1 |- - - -...
  • Page 14 Device Overview Level 1 Level 2 Level 3 Active Level 4 Function CODE (DEVICE) INTERF. | - - - PROT. Data transfer protocol 2.2.1 |- - - - SBI protocol 2.2.1.1 |- - - - XBPI protocol 2.2.1.2 xBPI | - - - BAUD Baud rate 2.2.2 |- - - -...
  • Page 15 Device Overview Level 1 Level 2 Level 3 Active Level 4 Function CODE INPUT | - - - - Password 4.1. PASSWD. | - - - Change/enter password 4.1.1 NEW PW Information INFO | - - - - Version number (firmware) VER.NO.

  • Page 16: Installation

    Legislation requires that a seal be affixed to verified scales. On Sartorius devices, this seal takes the form of a sticker with the “Sartorius” logo. If the seal is removed, the validity of verification will become void and you must have your scale re-verified.

  • Page 17: Installing The Scale

    Installation Installing the Scale The scale must be disconnected from the power supply for all assembly work. Inserting the Weighing Pan Place the weighing pan onto the scale from above. Power Supply The scale is connected to the power supply via a PC/notebook or using the optional AC adapter YPS06-USB (see Chapter “13 Accessories,”...
  • Page 18 − If the stated supply voltage or the plug design of the AC adapter does not comply with your country's standard, please inform your nearest Sartorius representative. − The power must be connected in accordance with the regulations applicable in your country.

  • Page 19: Connecting The Scale

    Installation 4.4.2 Connecting the Scale Connecting the Scale Insert the USB cable plug into the USB socket on the back of the display. Loosen the screw (1) on the lock. Swivel the lock over the USB cable. Re-tighten the lock screw. Laying the USB Cable Lay the USB cable through the cable holders on the back of the scale.

  • Page 20: Anti-Theft Locking Device

    If deviations are evident during startup due to transport damage (e.g., no display, no backlighting), disconnect the scale from the power supply and contact the Sartorius Service Center. Connect the scale to the equipotential bonding conductor using an equipotential bonding cable with a gauge of at least 4 mm².

  • Page 21: Commissioning

    Commissioning Commissioning Leveling Leveling for Models Verified for Use in Legal Metrology Only Turn the two feet as shown in the figure until the air bubble is centered within the circle of the level indicator. Air bubble at “12 o'clock:” Turn both feet clockwise. Air bubble at “3 o'clock:”...

  • Page 22: Operation

    Operation Operation Switching the Device On/Off Switching On Briefly press the j key (on/standby). The automatic self-test runs. This ends when the display shows 0.0 g. If another value is displayed: Set the scale to zero via the 0 key. Switching Off Press and hold the j key for several seconds (on/standby).

  • Page 23: Calibration

    Operation 6.4.1 Calibration External Calibration/Adjustment for Verified Scales Scale for use in legal metrology must be externally calibrated before being verified at the location of use. − When the scale is used in legal metrology, external calibration is locked as follows: −...

  • Page 24: Weighing With Two Decimal Places

    Operation 6.5.2 Weighing with Two Decimal Places (Not for Models Verified for Use in Legal Metrology) A menu setting is required for weighing with two decimal places (see Chapter “6.7.2.4 Activating the Toggle Key (Not for Models Verified for Use in Legal Metrology),”...

  • Page 25: Weighing Using The Recalculation Function

    Operation Factor Calculation Example As you add the components of your formula, the weight is displayed in “g.” For models verified for use in legal metrology, the displayed value is marked with a l symbol to indicated computed values. Suppose you want to weigh 250 ml for a basic formula that has a total of 1 l, and you don't want to have to manually recalculate the individual components of the formula.
  • Page 26 Operation Recalculation Example (Gross Weight) For models verified for use in legal metrology, the displayed value is marked with a l symbol to indicate computed values. Place the empty container on the weighing pan. 118.0 The scale shows the weight of the empty paint can. Briefly press the 0 key to tare.

  • Page 27: Menu Settings

    Operation Menu Settings 6.7.1 Accessing the SETUP Menu Accessing the SETUP menu and settings is described in the following using “Adapting the scale to ambient conditions” as an example (SETUP -> SCALE -> AMBIEN.): Press the ! key for approx. two seconds. Level 1 of the SETUP menu is displayed.

  • Page 28: 6.7.2.2 Language Setting

    Operation 6.7.2.2 Language Setting Level 1 Level 2 LANG. Press O, select LANG. Press ! o German Press O / P, select language English Press !, “o” appears UK/US French The desired setting is applied. Italian Press § several times to exit the menu etc.

  • Page 29: 6.7.2.5 Activating The "Lock" Function

    Operation Level 1 Level 2 Level 3 Level 4 Press ! SETUP | - - - APP.PRG. Press O / P, select APP.PRG. | - - - UNIT 2 Press !, press O / P, select UNIT 2 |- - - o GRAMS Press !, press O / P, select setting (e.g., GRAMS) |- - - Press !, “o”...

  • Page 30: 6.7.2.7 Resetting The Scale: "Reset

    Operation Changing the Password The password is numeric and can have up to six digits. Entering six spaces deletes the password, which deactivates the password function. This restores the device to its original setting (scale is not password-protected). Access the Setup menu (see Chapter 6.7.2.1, page 27). Level 1 Level 2 Level 3 Press O / P, select INPUT, press !
  • Page 31 Electrical Hazard from Voltage or Current! Repair work on the (optional) AC adapter must only be carried out by trained service technicians. Contact Sartorius Service for proper repairs (see Chapter 14, page 39). To ensure the continued accuracy of your scale, we recommend scheduling regular servicing at least once a year.
  • Page 32 Faults Faults Problem Cause Remedy No segments appear on − No AC power is available − Check power supply the weight display The weight readout − No weighing pan on − Position the weighing shows “LOW” the scale The weight readout −...
  • Page 33 The crossed-out waste bin symbol indicates that separate collection is required. In Germany and several other countries, Sartorius itself assumes responsibility for the return and legally compliant disposal of its electronic and electrical products. These products may not be placed with household waste or brought to collection centers run by local public disposal operations –...
  • Page 34 ID code (explosion protection) II 3G Ex ic nA IIB T4 Gc as per EC Type Examination Certificate no. FM15ATEX0008X Power supply Only via USB interface or Sartorius AC adapter YPS06-USB Input supply voltage +4.5 to 5.0 Power consumption 2.0 (typically)
  • Page 35 Technical Specifications 11.2 Model-specific Data Specification Unit Value Model PMA.Evolution EVO1Y Weighing capacity 7500/999.95 Readability 0.1/0.05 Tare range (subtractive) -7500 External adjustment weight / 1, 2, 5 / accuracy class F2 or better Size of weighing pan d mm Net weight 11.3 Verified Models with EC Type Approval Certificate: Model-specific Specifications Specification...
  • Page 36 Technical Specifications 11.4 Device Dimensions Model EVO1Y1 11.5 USB Interface (PC Port) 11.5.1 Purpose This device can be connected to a PC via the USB interface. A virtual serial interface (virtual COM port) is set up on the PC as a device type via the USB port.
  • Page 37 Technical Specifications 11.5.3 Installing the Software Driver (via CD) Ensure that the scale is not connected to the PC. Insert the supplied CD into the PC. If the Installation Wizard does not start automatically after you insert the CD, then manually start driver installation via Setup.bat located on the CD. Follow the instructions that appear.
  • Page 38 Serial Number Coding 12 Serial Number Coding The manufacture date of this device is encoded in the serial number. The format is as follows: YMM x x x x x Year 2014-2020 2021-2027 2028-2034, etc. The Y column indicates the year group, which covers a period of 7 years. Within each year group, the months (M M) are counted up from 13.
  • Page 39 − 1 kg, accuracy class F2 YCW614-AC-00 14 Sartorius Service Sartorius Service is at your disposal for queries regarding the device. For information about the service addresses, services provided or to contact a local representative, please visit the Sartorius website (www.sartorius.com).

  • Page 40: Conformity & Licenses

    Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 41 Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 42 Conformity & Licenses Schilder und Marken / Plates and Markings / Plaques et marques / Placas y Marcas / Etichette e Sigilli Typ Waage / Type weighing instrument / Type d’instrument de pesage / Tipo del instrumento de pesaje / Tipo di strumento per pesare: PMA-EV, PMA-HD EG Baumusterprüfbescheinigung / EC type-examination certificate / Certificat d’examen UE de type / Certificado de examen UE de tipo / Certificato di esame UE del tipo : UK3066 EVO1Y1 Operating Instructions...
  • Page 43 Conformity & Licenses Schale / Pan / Plateau de pesée / Plato de pesaje / Piatto di pesata Unterschale / Subpan / Plateau inférieur / Plato inferior / Piatto inferiore Libelle / Bubble level / Nivelle sphérique / Nivel de burbuja / Livella Segmentiertes LCD-Display / Segmented LCD display / Afficheur à...
  • Page 44 Conformity & Licenses Non-hazardous area Hazardous area Zone 2 Gas group IIB, temperature class T4 Ambient temperature: 0°C to +40°C Device Power Supply e.g. Sartorius YPS06-USB USB plug Cable clamp Alternative Device connections USB plug Cable clamp USB cable Display unit USB cable EVO1Y..-..
  • Page 45 If your equipment needs to be repaired, use only original spare parts supplied by the manufacturer! Any tampering with the equipment by anyone, other than repair work done by authorized Sartorius service technicians, will result in the loss of EX conformity and in the forfeiture of all claims under the manufacturer's warranty.
  • Page 46 FM15ATEX0008X Equipment or protective system: PMA.Evolution EVO1Yab-c and LAB1Yab-c (Type Reference and Name) Name of Applicant: Sartorius Lab Instruments GmbH & Co. KG Address of Applicant: Otto-Brenner-Straße 20 Göttingen 37079 Germany This equipment or protective system and any acceptable variation thereto is specified in the schedule to this certificate and documents therein referred to.
  • Page 47 Conformity & Licenses SCHEDULE to Type Examination Certificate No. FM15ATEX0008X Description of Equipment or Protective System: The PMA.Evolution EVO1Yab-c and LAB1Yab-c are designed for the measurement of weight in the hazardous location. The PMA.Evolution contains the processing circuitry and has a touch enable LCD display with backlight facility.
  • Page 48 Conformity & Licenses SCHEDULE to Type Examination Certificate No. FM15ATEX0008X Schedule Drawings A list of the significant parts of the technical documentation is annexed to this certificate and a copy has been kept by FM Approvals Ltd. Certificate History Details of the supplements to this certificate are described below: Date Description July 2015...
  • Page 49 Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 50 Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 51 Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 52 Conformity & Licenses EVO1Y1 Operating Instructions...
  • Page 53 Sartorius Lab Instruments GmbH & Co. KG Otto-Brenner-Strasse 20 37079 Goettingen, Germany Phone: +49.551.308.0 Fax: +49.551.308.3289 www.sartorius.com The information and figures contained in these instructions correspond to the version date specified below. Sartorius reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.

Table of Contents
