Operating Concept
4.8 Displays in the Operating Display
Symbol Name
[Sign] display
[Zero] display
[Percent] display
[Computed value]
display
[Net] display
[Gross] display
[PC connection]
display
[Second display]
display
[Printer] display
[USB] display
[Invalid weight
value] display
4.9 Navigating the Menus
Procedure
To modify the parameters in an application:
t
Select an application in Application Management.
16 Entris II Advanced Line Operating Instructions
®
Description
Indicates whether the value being displayed is positive or negative.
For some conformity-assessed devices: Indicates that the device has been zeroed.
Indicates that a percentage value is being displayed.
If the "Conversion" or "Peak hold" application is active: Indicates that a calculated
value or frozen value is being displayed.
Indicates that a net value is being displayed.
Indicates that a gross value is being displayed.
Indicates that a PC has been detected at the USB-PC port.
Indicates that an FTDI cable or a second display has been detected at the USB
port.
Indicates that a printer has been detected at the USB port.
Indicates that a USB stick has been detected at the USB port.
Indicates that the display does not contain a weight value, but is instead the
calculated result of an application, e.g., for the "Totalizing" application.
In order to navigate
t
within a display,
e.g., in the settings
or application
management:
Swipe the operating
display in the
desired direction,
e.g., upwards or
downwards.
Press the application
t
toolbar (1).
The display containing
y
the application-
specific parameters
opens.
1
