Device Description
3 Device Description
3.1 Device Overview
Fig. 1: Precision balance (front view)
Pos . Name
1 Weighing pan
2 Shock absorber
3 Manufacturer's ID
label
4 Frame draft shield
5 Control unit
6 Leveling foot
10 Entris II Advanced Line Operating Instructions
®
1
2
3
4
5
6
Description
For placing the sample
on the balance
Attached to the rear of
the device
Used to level the
balance, is manually
adjustable
3.2 Device Connections
1 2
Fig. 2: Precision balance (rear view)
Pos . Name Description
1 Access switch Protects the device from
changes to the device settings.
Is sealed for conformity-
assessed devices.
2 Power supply Connection for power supply
to the device
3 PC-USB USB-C connection, for
connection to a PC
4 USB USB-C connection, for
connection to a printer, USB
stick, FTDI cable, or a second
display.
5 RS232 9-pin, for connection to a
connection printer, PC, or a second display
6 Slot For attaching an anti-theft
device, e.g., a Kensington lock
3.3 Conformity-assessed Devices
Some settings of conformity-assessed models are
protected against user changes, e.g., external calibration
or the "Safety level" in the "Weighing" menu. This
measure is intended to ensure the suitability of the
devices for use in legal metrology.
3 4 5 6
