Control Panel

Adjust Printer

Auto Head Adj.
Manual Head Adj
Auto Band Adj.
Manual Band Adj
Adj Far Ed Feed
Adjust Length
56 Printer Parts
Setting Item
Standard Adj.
Advanced Adj.
Auto Print
Standard Adj.
Advanced Adj.
Description, Instructions
Choose Yes to have the printer print and read a test pattern
for automatic adjustment of the Printhead alignment relative to
the printing direction. (→P.581)
Choose Yes to have the printer print and read a test pattern for
the automatic adjustment of Printhead alignment relative to the
nozzle, ink tank, and printing direction.
Six sheets are required when printing on sheets.
(→P.581)
Choose On to have the printer automatically execute the
Advanced Adj. operations after you replace the Printhead.
(→P.581)
Choose Yes to print a test pattern for adjustment of Printhead
alignment relative to the printing direction. Enter the adjustment
value manually based on the resulting pattern. (→P.583)
Choose Yes to have the printer print and read a test pattern
for band adjustment, based on which the printer automatically
adjusts the feed amount. (→P.587)
Choose this option when using paper other than genuine Canon
paper, or paper for purposes other than checking output.
Choose Yes to have the printer print and read a test pattern
for band adjustment, based on which the printer automatically
adjusts the feed amount. Note that this function takes more
time and requires more ink than Standard Adj..
Two sheets are required when printing on sheets.
(→P.587)
Choose Yes to print a test pattern for adjusting the feed amount
based on the paper type.
Two sheets are required when printing on sheets.
(→P.590)
Choose Yes to print a test pattern for adjusting the feed amount
of the trailing edge of paper based on the paper type.
(→P.590)
Choose Yes to print a test pattern for adjustment relative to
paper stretching or shrinkage, after which you can enter the
amount of adjustment. (→P.594)
