Menu mode, and state of the Control Panel

Main menu
•
Top Line of the Display Screen
Menus and menu items are displayed here.
•
Bottom Line of the Display Screen
The selected item is displayed. Other items are available if "→" is displayed at right. Lower levels are
available if "↓" is displayed at right. If other items and lower levels are both available, "↓" and "→" are
displayed alternately. (→P.34)
Menu items and settings
•
Top Line of the Display Screen
Menu items are displayed here.
•
Bottom Line of the Display Screen
Menu items or settings are displayed here. An equals sign "=" displayed at left indicates that this is
the current value. (→P.34)
Submenu mode, and state of the Control Panel
When submenus are displayed
Information on ink and paper is shown on the top line of Display Screen and bottom lines of the Display
Screen. (→P.62)
30 Printer Parts
Paper Settings
Chk Remain.Roll
Chk Remain.Roll
= On
Ink
█ █ █ █ █ █ █
