5-2-3 Changing Timer Settings (Only CP1L)

Timer settings can be changed to better suit operating conditions.
1.
Change CP1L to the MONITOR or PROGRAM operating mode.
2.
Double-click the timer setting to be changed.
The Set Timer/Counter Value dialog box will be displayed.
3.
Input the new value. Click [OK].
The timer setting will be updated.

5-2-4 Searching

Address Reference Tool
The address reference tool displays which instructions are using the address being
pointed to with the cursor. It also allows jumping to another instruction with the
same address.
The address reference tool will display the following items:
• Address at the cursor position
• Variables (local, global)
• Program name, section name
• Program address (step)
• Instruction using the address
