When interrupt input 0 (CP1E: 4) (contact 0.04) turns ON, the following "interrupt
task 140 (CP1E: 4)" will be executed once. Assignment of interrupt tasks to
interrupt inputs is fixed. Interrupt input 0 (CP1E: 4) will always execute interrupt
task 140 (CP1E: 4).
0.00
Sensor input 1
0.00
Sensor input 1
Interrupt task
140
0.01
(CP1E: 4)
Sensor input 2
0.02
Sensor input 3
A-4 CP1L Programming Examples
0.01 0.02
Sensor input 2 Sensor input 3
SYSMAC CP1L/CP1E Introduction Manual
SET
PASS output
100.00
SET
NG output
sensor input 1
100.02
SET NG output
sensor input 2
100.03
SET
NG output
sensor input 3
100.04
