4-5 Inputting Programs
4
72
SYSMAC CP1L/CP1E Introduction Manual
5.
Input " Car detection sensor " as the I/O comment. Press the [Enter] key.
A contact representing input from the car detection sensor will be displayed as an
OR circuit.
6.
Double-click contact " 003 " .
The Edit Contact dialog box will be displayed.
7.
Click [Detail].
8.
Select [Up] for Differentiation. Click [OK].
