Omron CP1E - INTRODUCTION Introduction Manual page 94

5
5-2 Adjusting/Debugging Online
5
Monitoring Specific Addresses
92
SYSMAC CP1L/CP1E Introduction Manual
(1) Window divider
Drag the window divider to split the diagram workspace. The workspace can be
split in up to 4 sections.
I/O values can be monitored by specifying their address.
1.
Select [PLC] - [Monitor] - [Monitoring] from the main menu.
2.
Select [View] - [Windows] - [Watch] from the main menu.
3.
Input an address.
The I/O value will be displayed. For Boolean values, "0" indicates OFF.
