Transferring Programs - Omron CP1E - INTRODUCTION Introduction Manual

5
5-1 Going Online
Program status
I/O refreshing
External I/O status
I/O memory
Operations from
CX-Programmer
5

5-1-3 Transferring Programs

88
SYSMAC CP1L/CP1E Introduction Manual
The following table lists the status and available operations for each mode.
Operating Mode
Non-holding memory
Holding memory
I/O memory monitoring
Program monitoring
Program From PLC
transfer
To PLC
Compiling
PLC setup
Changing program
Force-setting/Force-resetting
Changing timer/counter SV
Changing timer/counter PV
Changing I/O memory PV
*CP1E is not available.
A program created with CX-Programmer can be transferred to CP1L.
1.
Select [PLC] - [Transfer] - [To PLC] from the main menu.
The Download Options dialog box will be displayed.
PROGRAM RUN
Stopped Running
Execute Execute
OFF Depends on
program
Cleared
Depends on
program
Held
OK OK
OK OK
OK OK
OK No
OK No
OK No
OK No
OK No
OK * No
OK No
OK No
MONITOR
Running
Execute
Depends on
program
Depends on
program
OK
OK
OK
No
No
No
OK
OK
OK *
OK
OK
