Omron CP1E - INTRODUCTION Introduction Manual page 38

3
3-3 Wiring Devices
Wiring Inputs
3
Wiring Outputs
36
SYSMAC CP1L/CP1E Introduction Manual
1.
Wire the inputs as shown, while referring to 2-3 I/O Allocation for the
Shutter Control System.
PB2 SEN1
(0.01) (0.03)
L1 L2/N COM 01 03
00 02 04
PB1 PB3 SEN2
(0.00) (0.02) (0.04)
1.
Wire the outputs as shown, while referring to 2-3 I/O Allocation for the
Shutter Control System.
MO1
(100.00)
+ 00 01
-
COM COM
For details on wiring, refer to 3-5-4 I/O Wiring for CPU Units with 14 I/O Points
of CP Series CP1L CPU Unit User's Manual (W462) or 5-3-3 I/O Wiring of CP
Series CP1E CPU Unit Hardware User's Manual (W479).
LS1
(0.05)
NC
05 07 NC
06 NC NC
LS2
(0.06)
MO2
(100.01)
02 03 04 NC
NC
COM 05
COM
