4-1 Preparing for Programming
Confirming Installation
4
44
SYSMAC CP1L/CP1E Introduction Manual
Confirm that the driver has been installed properly.
1.
On the desktop, select [Start], and then right-click [My Computer].
A context menu will be displayed.
2.
Select [Properties].
The System Properties dialog box will be displayed.
3.
Select the Hardware tab, and click [Device Manager].
The Device Manager dialog box will be displayed.
4.
Double-click [Universal Serial Bus controllers].
5.
Confirm that [OMRON SYSMAC PLC Device] is displayed.
If so, the USB driver has been installed successfully.
6.
Close the Device Manager dialog box, and then the System Properties
dialog box.
If [OMRON SYSMAC PLC Device] is not displayed, reinstall the USB driver.
For details on reinstalling the USB driver, refer to 1-3-1 Connecting with a
Commercially Available USB Cable of CP Series CP1L CPU Unit User's
Manual (W462) or 4-2-2 Installing the USB Driver of CP Series CP1E CPU Unit
Hardware User's Manual (W479).
