Omron CP1E - INTRODUCTION Introduction Manual page 177

Item
Trace Memory
Clock (RTC)
Address offsets
Number of cyclic tasks
Number of interrupt tasks
Number of subroutines
Jump numbers
Scheduled interrupts
I/O Memory
Item
CIO Area
Work Area (W)
Temporary Area (TR)
Holding Area (H)
Auxiliary Area (A)
Timers (T)
Counters (C)
DM Area (D)
Task Flag Area
Index Registers (IR)
Data Registers (DR)
Trace Memory
CP1L CPU Units
Supported.
Supported.
Not supported.
32
256
256
256
1 interrupt
Time unit: 10ms, 1ms,
0.1ms
CP1L CPU Units
98,304 bits
CIO 0 to CIO 6143
8,192 bits
W0.00 to W511.15
16 bits
TR0 to TR15
24,576 bits
H0.00 to H1535.15
Read-only: 7,168 bits
A0 to A447
Read/write: 8,192 bits
A448 to A959
4,096 timers
T0 to T4095
4,096 counters
C0 to C4095
32K words
D0 to D32767
(All the data of the DM Area
can be backed up to flash
memory as initial values for
use at startup. The data is
backed up when power is
interrupted and then
restored to RAM the next
time power is turned ON
(DM Area initialization
function).)
32
TK0 to TK32
IR0 to IR15
DR0 to DR15
4,000 words
A-5 Comparison between CP1L and CP1E
CP1E E-type CPU Units
Not supported.
Not supported.
Supported.
1
16
128
128
1 interrupt
Time unit: Only 0.1ms
Interrupt intervals are fixed when MSKS instruction is
executed.
Only reset/start can be executed by MSKS instruction.
CP1E E-type CPU Units
4,640 bits
CIO 0 to CIO 289
1,600 bits
W0.00 to W99.15
16 bits
TR0 to TR15
800 bits
H0.00 to H49.15
Read-only: 7,168 bits
A0 to A447
Read/write: 4,896 bits
A448 to A753
256 timers
T0 to T255
256 counters
C0 to C255
2K words
D0 to D2047
(D0 to D1499 can be
backed up to EEPROM by
using the Auxiliary Area
control bits. The data is
restored to RAM when
power is turned ON for the
settings in the PLC Setup.)
1
Not provided.
Not provided.
Not provided.
SYSMAC CP1L/CP1E Introduction Manual
CP1E N-type CPU Units
Supported.
Supported.
1
16
128
128
CP1E N-type CPU Units
8K words
D0 to D8191
(D0 to D6999 can be
backed up to EEPROM by
using the Auxiliary Area
control bits. The data is
restored to RAM when
power is turned ON for the
settings in the PLC Setup.)
A
175
