3.
Click the General tab. Select [Interrupt Task 140 (CP1E: 4)] from the Task
type drop-down list.
o
4.
Close the Program Properties dialog box.
5.
Select [Section1] under [NewProgram2 (Int 140 (CP1E: 4))].
6.
Input the ladder program for the interrupt.
To display the main ladder program, double-click [Section1] under
[NewProgram1(00)] in the project tree.
