A-4 CP1L Programming Examples
A
138
SYSMAC CP1L/CP1E Introduction Manual
3.
Double-click [D] in the data area workspace.
The PLC data table will be displayed.
4.
Input the values for the DM addresses.
5.
Click [Save in Project].
The settings will be saved.
6.
Transfer the data from the computer to CP1L.
1)Confirm that the computer is online with CP1L.
2)Select [Online] - [Transfer to PLC] from the menu.
The Transfer to PLC dialog box will be displayed.
3)Select the area and its region for the transfer. Click [Transfer to PLC].
The data will be transferred.
