Example Timer and Counter Applications
Example 1: Long-term Timers
The following program examples show three ways to create long-term timers with standard TIM and
CNT instructions.
1) Two TIM Instructions
In this example, two TIM instructions are combined to make a 30-minute timer.
0.00
T0001
T0002
2) TIM and CNT Instructions
In this example, a TIM instruction and a CNT instruction are combined to make a 500-second timer.
TIM 0001 generates a pulse every 5 s and CNT 0002 counts these pulses. The set value for this
combination is the timer interval
With this combination, the long-term timer's PV is actually the PV of a counter, which is maintained
through power interruptions.
100.00
0.01
0.00 100.00
Start Count up
3) Clock Pulse and CNT Instruction
In this example, a CNT instruction counts the pulses from the 1-s clock pulse to make a 700-second
timer.
If the First Cycle Flag (A200.11) is ORed with the counter's reset input (CIO 0.01), the counter's PV will
be reset to the SV (0700) when program execution begins rather than resuming the count from the
previous PV.
P_1s (1-s clock)
0.00
0.01
A20011
C0001
