SETR

Instruction
SET RECORD LOCATION
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
N Table number
R Record number
D Destination Index Register
N: Table number
Indicates the table number. N must be between 0 and 15.
R: Record number
Indicates the record number of the desired record. R must be 0000 to FFFE hexadecimal (0 to 65,534).
Record numbers begin with 0, so the valid record numbers are 0 to NR–1 for a table with NR records.
D: Destination Index Register
Indicates the desired Index Register. D must be IR0 to IR15.
Operand Specifications
Word addresses
Area
CIO WR HR
N --- --- ---
R OK OK OK
D --- --- ---
Flags
Name
Error Flag
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Mnemonic Variations
SETR @SETR
Block program areas Step program areas
OK OK
Description
AR T C DM EM
--- --- --- --- ---
OK OK OK OK OK
--- --- --- --- ---
Label
ER • ON if the specified table number (N) has not been defined with DIM(631).
• ON if the specified record number (R) exceeds the highest record number in the table (NR-1).
• OFF in all other cases.
Function
code
Writes the location of the specified record (the
635 PLC memory address of the beginning of the
record) in the specified Index Register.
SETR
SETR(635)
N: Table number
N
R: Record number
R
D D: Destination Index Register
Subroutines
OK
Data type
---
UINT
WORD
Indirect DM/EM
addresses
Con-
stants
@DM *DM
DR
@EM *EM
--- --- ---
OK
OK OK OK
--- --- --- ---
Operation
3. Instructions
Function
SFC action or
Interrupt tasks
transition programs
OK OK
Size
1
1
2
Registers Flags
Pulse
bits
Indirect
IR TK CF
using IR
---
---
OK --- ---
OK ---
3
TR
bits
--- ---
577
