Omron CJ - REFERENCE MANUAL 02-2010 Reference Manual page 77

Instruction Symbol/Operand
Mnemonic
Code
ONE-MS TIMER
TMHH(540)
TMHH
540
(BCD)
TMHHX
N: Timer number
552
S: Set value
(BCD)
(CJ2, CS1-H,
CJ1-H, CJ1M, or
TMHHX(552)
CS1D only)
N: Timer number
S: Set value
TENTH-MS
TIMU(541)
TIMER (CJ1-H-R
and CJ2 only)
TIMU
541
N: Timer number
(BCD)
S: Set value
TIMUX
TIMUX(556)
556
(BCD)
N: Timer number
S: Set value
CS/CJ/NSJ Series Instructions Reference Manual (W474)
TMHH(540)/TMHHX(552) operates a decrementing timer with units of
1-ms. The setting range for the set value (SV) is 0 to 9.999 s for BCD
and 0 to 65.535 s for binary (decimal or hexadecimal).
N
S Timer input
Timer PV
Completion
Flag
N
S
Timer input
Timer PV
Completion
Flag
TIMU(541)/TIMUX(556) operates an decrementing timer with units of
0.1-s. The setting range for the set value (SV) is 0 to 0.999 s for BCD
and 0 to 6,553.5 s for binary (decimal or hexadecimal).
N
S
Timer input
Timer PV
Completion
N
Flag
S
Timer Input Turns OFF before Completion Flag Turns ON
Timer input
Timer PV
Completion
Flag
Note: The timer's present value cannot be accessed for a TENTH-MS
TIMER instruction.
Function
SV
SV
ON
OFF
SV
0
ON
OFF
ON
OFF
SV
0
ON
OFF
2. Summary of Instructions
Location
Execution
condition
Output
Required
Output
Required
Page
223
2
226
41
