3. Instructions
(2) Reading the Differentiation Settings Set for I/O Interrupts and Input Interrupts
(Except when Using a C200HS-INT01 Interrupt Input Unit)
Operand
N
Inputs to a CS1W-INT01 or CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
Inputs to a CJ1M-CPU2@ CPU Unit's Built-in
Inputs (4 inputs/Unit)
D
Inputs to a CS1W-INT01 or CJ1W-INT01
Interrupt Input Unit (16 inputs/Unit)
Inputs to a CJ1M-CPU2@ CPU Unit's Built-in
Inputs (4 inputs/Unit)
(3) Reading the Set Value of a Scheduled Interrupt Task's Internal Timer
Operand
N
4: Interrupt task 0 (interrupt task 2)
5: Interrupt task 1 (interrupt task 3)
Note Only scheduled interrupt 0 can be used with the CJ1M-CPU11/21.
D Scheduled interrupt time units
(Set in the PLC Setup.)
Any time unit setting
10 ms
1 ms
0.1 ms
(4) Reading the Present Value of a Scheduled Interrupts Internal Timer (CJ1M and CJ2M CPU
Units Only)
Operand
N
14: Scheduled interrupt 0 (interrupt task 2)
15: Scheduled interrupt 1 (interrupt task 3)
Note Only scheduled interrupt 0 can be used with the CJ1M-CPU11/21.
D Scheduled interrupt time units
(Set in the PLC Setup.)
10 ms
1 ms
0.1 ms
Operand Specifications
Word addresses
Area
CIO WR HR
N --- --- ---
D OK OK OK
716
Interrupt input
Interrupt Input
0 decimal (0000 hex):
Interrupt disabled. (Internal timer stopped.)
1 to 9,999 decimal (0001 to 270F hex):
Interrupt enabled. (Internal timer started with interrupt interval between 10 and 99,990 ms.)
1 to 9,999 decimal (0001 to 270F hex):
Interrupt enabled. (Internal timer started with interrupt interval between 1 and 9,999 ms.)
1 to 9,999 decimal (0001 to 270F hex):
Interrupt enabled. (Internal timer started with interrupt interval between 0.1 and 999.9 ms.)
0 to 9,999 decimal (0000 to 270F hex):
Interrupt timer PV between 0 and 99,990 ms
0 to 9,999 decimal (0000 to 270F hex):
Interrupt timer PV between 1 and 9,999 ms.
0 to 9,999 decimal (0000 to 270F hex):
Interrupt timer PV between 0.0 and 999.9 ms.
Indirect DM/EM
@DM
AR T C DM EM
@EM
--- --- --- --- ---
OK OK OK OK OK OK
Contents
Interrupt identifier
2: Unit number 0 (interrupt tasks 100 to 115)
I/O interrupts 0 to 15 (interrupt tasks 100 to 115)
3: Unit number 1 (interrupt tasks 116 to 131)
I/O interrupts 16 to 31 (interrupt tasks 116 to 131)
10: Interrupt input 0 (interrupt task 140)
11: Interrupt input 1 (interrupt task 141)
12: Interrupt input 2 (interrupt task 142)
13: Interrupt input 3 (interrupt task 143)
Read interrupt input differentiation setting
Range: 0000 to FFFF hex.
Bits 0 to 15 correspond to each interrupt task. The meaning of the individual flags is
as follows:
0: Up-differentiation (Detect rising edge.)
1: Down-differentiation (Detect falling edge.)
0000 hex: Up-differentiation (Detect rising edge.)
0001 hex: Down-differentiation (Detect falling edge.)
Contents
Scheduled Interrupt No.
Scheduled interrupt set time
Contents
Interrupt identifier
Read internal timer PV
addresses
Con-
stants
*DM
DR
*EM
--- --- OK ---
OK --- OK
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Registers Flags
Pulse
bits
Indirect
IR TK CF
using IR
---
--- --- ---
OK
TR
bits
--- ---
