6.3.3. Right-Click Menu
Right click on the interface and the following right click menu appears.
Function
Select all, deselect, deselect, delete
selected
Suitable view
Set the center of rotation
Reset the center of rotation
Displaying sampling data
Hide cutting plane
Right camera
6.3.4. Cutting Plane
Cutting plane is very useful when a base need to be removed during scanning. You can
orient the plane around X,Y, Z axes. The plane can be rotated, zoom, move.
After setting cut plane, there will be no more data scanned below the cut plane during the
scanning process, preventing irrelevant data getting scanned.

Create Cut Plane
Cut Plane
Click this button to enter the cut plane mode.
Shining 3D Transcan C_User Manual_V1.4.1
Description
Same functions as editing, can be operated by shortcut keys.
Data is centered on the interface and sized appropriately.
The center of rotation can be set on the data with the left mouse
button, and the setting can be exited with the ESC key.
After reset, the center of rotation is in the data center.
For data with a large number of point clouds, you can use this
function to display the data at the selected scale.
After clicking this item, the cut surface on the interface is hidden.
After clicking this item, the corresponding camera viewport is
displayed in the upper left corner of the interface.
