3.1.1. Scanner Adjustment 150 mm
Rotate the screw
the camera position. Place the "position" of the camera within the 150 mm scanning range. After the
adjustment is complete, tighten screw
Note:
For top view of the scanner shown by the image above,
under the guide rail.
Place devices according to the following figure.
Shake the rocker
the calibration board, and tighten the lock.
Adjust the distance between the device and the calibration board so that the distance between
the front end of the device and the calibration board is about 260 mm. The scanning head where
cameras are located should be kept level, and the calibration bracket should be kept in the third slot
of the calibration board (count from front to back when you face the calibration board).
Rotate the screw shown in figure
projector covers the entire calibration board and that the black cross is aligned with the center of the
calibration board. After the adjustment, tighten the screw.
Shining 3D Transcan C_User Manual_V1.4.1
(as shown in the images below) next to the left and right camera to move
.
, roughly adjust the height of the equipment, make the light projected on
to adjust the scanner angle to ensure that the optical
hexagonal screwdrivers are hidden
18
