9.2. Scale Data

Scaling the volume of scanned data, while the number of triangles, the level of detail of the scan and
size of data will not be actually changed.
By default, the scale is 100% and will be exported with millimeters for reference.
The value display represents the dimensions of the smallest box containing the data oriented to the
reference axis.
Scale result
Scale window

9.3. Measurement

After meshing, the Measurement menu will be available on the top. Or click Measurement on the
navigation bar, and import data.
Go to Measurement.
Open file.
Click Open file, a STL or OBJ file can be imported to edit.
9.3.1. Create Feature
Enter/Exit the Feature menu.
Click the Feature button to display the menu, click again to close the menu.
Shining 3D Transcan C_User Manual_V1.4.1
51
