1. Specification and System Requirements

1.1. System Requirements

Preparing a suitable computer will improve your scanning experience.
One important notice for PC configuration is the graphic card. It has to be Nvidia card since certain
function from Nvidia is needed for scanning. RTX series card is the best for scanning while Quadro
series CAD card also works but you need a more expensive model comparing to the GTX series to get
a good scan experience.
For your PC with EXScan C software, don't enable power saving mode when scanning objects to avoid
image scanning failure.
Item
Graphics card
USB port
OS
Video memory
RAM
CPU
Screen resolution

1.2. Hardware Installation

Unpack and set up your scanner before getting started with scanning.
1.2.1. Assemble Scanner
1) Open the tripod and place it on the ground. Adjust the tripod's three feet.
2) If the height is still too high or too low, the lock ② can be unscrewed to adjust and fasten
vertical slide rod to an appropriate height, and the lock ② can be screwed after the adjustment.
Insert the scan head assembly into the top groove of the tripod, tighten the screws. See ① to
3)
see if the scanner is placed horizontally.
4) Based on the need, shake the rocker to adjust the device height. Then tighten the latch.
Shining 3D Transcan C_User Manual_V1.4.1
Recommended
NVIDIA GTX1080 or higher
At least one USB 3.0 port
Win10 64 bits
8 GB
≥ 32 GB
i7-8700 or higher
1920*1080 DPI: 100%; 125%
3840*2106 DPI: 100%; 125%; 150%
