Summary of Contents for Shining 3D EinScan-Pro Series
- Page 1 USER MANUAL EinScan-Pro series Version 3.0.0.0 - June 2019 SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 2: Table Of Contents
5.2.2. Edit Scan ..................... 45 5.3. Scans & Groups ..................... 47 5.3.1. Create Groups ..................47 5.3.2. Edit scan(s)/group(s) ................48 5.4. Alignment ...................... 48 6. HD Mode ........................50 SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 3 8.4.2. Scale Data ................... 85 8.4.3. Share Data ..................86 8.4.4. Third-party Software ................87 8.4.5. Model Preview ................... 88 9. Color pack ........................ 90 9.1. Hardware ....................... 90 9.1.1. Content....................90 SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 4 11.3.3. Scan with markers ................115 11.3.4. Scan without Features ..............116 11.4. Pause menu ....................117 11.4.1. Auto-save ..................117 11.5. Edit menu ....................118 12. Support and Contact .................... 120 SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 5: About Shining 3D
12.1. User Community ..................120 12.1.1. Log In ....................120 12.1.2. Validate Your Warranty ..............121 12.1.3. Submit a Ticket ................122 12.2. Contact Us ....................124 About SHINING 3D SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 6: Hardware
The components may be different as listed when you purchase other accessories or change any item with your supplier. Please check carefully when opening the package. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 7: Specifications
Able to export watertight 3D model directly to 3D printing Output Data Format OBJ, STL, ASC, PLY, 3MF, P3 Scanner Body 0.8 kg Weight Supported OS Win7/Win8/Win10 64 bit SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 8: Einscan Pro
For the transparent, highly reflective or some dark objects, please spray with powder Object before scanning. Printable Data Output Data Format OBJ, STL, ASC, PLY, 3MF, P3 Scanner Body 0.8 kg Weight Supported OS Win7/Win8/Win10 64bit SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 9: Hardware Introduction
32G or more At least one USB 2.0 or 3.0 2 USB 2.0 Screen display 1920*1080 DPI: 100%; 125% 1920*1080 DPI: 100%; 125% 3840*2106 DPI: 100%; 200% 3840*2106 DPI: 100%; 200% SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 10: Set Up
Device Manager, display of the scanner Other cameras should be disable, Right click > disable device. After the scan, right click > enable device, Windows will run the driver again. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 11 If the drivers are not installed properly, or the Alert “device off-line” keeps coming back. Right click on the “Microview MVC1500MF Camera” and uninstall the driver. Unplug and re-plug the USB, Windows will re-install the drivers by itself. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 12: Software
Step 1: Go to https://www.einscan.com/software-download. Click “EinScan Software Download” to download the latest version software for EinScan. Step 2: Register using the form. All filed with * must be filled in. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 13: Software Installation
Choose the installation language, then click OK. Select installation language If a previous version of EinScan-Pro serires software is found it will need to be unistalled first. Installation conflict SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 14 Follow the instruction on the pop-up window You must accept the agreement to install EXScan Pro. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 15 Click the Checkbox and click Next to approve the Privacy Notice Choose the default installation path or click the Browse button to select the installation path. Default installation path is recommended. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 16 Click the Checkbox and click Finish. The software will start automatically When the installation is completed, there will be a shortcut Icon of the software on the desktop. The shortcut in the Start Menu is shown as below: SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 17 EXScan Pro on the start menu SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 18: Uninstall Software
2.3. Uninstall Software To install upgraded version of EinScan-Pro series in the future, you may need uninstall previous software first. To uninstall the software, when the software is closed, in the start menu Click Uninstall. start menu > Shining3d_EinScan-Pro series > Uninstall Or go to Control Panel >... -
Page 19: Update
Then delete the Shining3D folder and its content in (C:). 2.4. Update Make sure to run the latest version of EinScan-Pro series. If a new version is available, a pop-up will show when you start the software. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 20 Update Reminder Click Yes to update the software version SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 21: Device Activation
If the activation fails, send a request for activation file to einscan_support@shining3d.com and mention your serial number. You can find the serial number from the sticker on the scanner or label on packing box listing as “EinscanXXX-XXXXXXXXXX”. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 22 Connection failed, check your internet connection or do local activation Save the .PLE file on your PC, then on the activation menu. click “ ” to reveal the “Local activation” button SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 23: Interface And Parameter
2.6. Interface and Parameter At first, after opening the software, click on the icon to choose between Pro and Pro+ Selection of scanner type Next the scan mode selection will display. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 24: Navigate
Esc key to exit current pop-up Navigate between different menu by click on the circle. Navigation bar 2.6.2. Settings Click the settings logo from the upper right to open the drop down menu. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 25 To help us improve the quality and user experience of EinScan, we hope to be allowed to collect usage experience information. This information will not contain your personal information or scanned data, and will not be accessible to any third SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 26: Einscan Community
Redirects to the platform for EinScan users to validate the warranty and submit support ticket when necessary. Service live software updates, manual, video download can be accessed in user community. Register your EinScan at community.shining3d.com SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 27: Help Mode
It opens S3D_teamviewer.exe, for online customer support access or display to other screen or portable screen. Share your ID and password to allow our technicians to remote control of your computer during online technical support SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 28: Alerts
In Manage 3D Settings > Program Settings, Add EinScan software. Then change the preferred graphic processor for this program. Select NVIDIA processor. Click Apply to save the settings. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 29 When the device is offline, meaning the scanner is not connected to PC, please check the connection and restart the software. Device offline or connection loose Offline status in navigation bar Mode not available SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 30 Add-on is required for this function SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 31: Calibration
After installation, when you open the software for the first time the software will enter the calibration mode by default. You can also choose Calibration on the navigation bar to enter calibration process later. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 32: Camera Calibration
Then lift the scanner to change the distance between the projector and calibration board according to the software guide. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 33 Do not move the board during the capture When pictures of one position are well collected, the software will turn to the next position with buzzer as below: SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 34 “Next” to move on to the HD calibration or white balance as the software indicates. Or it will go back to the scan mode selection interface if there is no other calibration required. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 35: Hd Calibration (Only Required For Einscan Pro)
On the back side of the calibration board (white) follow the instructions on the video and on the screen to capture the different position. The software will then calculate. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 36: Accuracy Test
Follow the instructions on the video and on the screen to capture the different pictures. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 37: Before Scan
Go back to scan mode selection page by clicking “Next”. Before Scan 4.1. Object EinScan Pro series can scan objects from 30*30*30mm ^3 to 4m length. We do not recommend scanning: SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 38: Preparation
(3) Markers should be stuck on the flat surface area and keep the marker surface flat. (4) Use the markers provided with the device only. Other markers can result bad accuracy or not to be seen. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 39: Select Scan Mode
Markers surrounding the object Before scanning transparent, highly reflective and black objects, you should spray white powder on the surface (see example above). SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 40 The tables above show the details of each scan mode that can be selected. For limitations of each scan mode, refer to the specifications presented previously. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 41: Scan Workflow
4.4. Scan Workflow SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 42: Fixed Mode (Industrial Pack Required)
‘Save’ to enter the scan parameters window. Texture scan is only active when the texture camera (Color Pack) is attached to the scanner. Create a project, fixed scan SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 43: Working Distance
Set up for fixed mode Note: The tripod is NOT included in the Standard Pack, but it is included in Industrial Pack together with a turntable. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 44: Interface
To scan an object with high contrasting texture, such as something white and black, select HDR. Each single scan will take longer to capture. Turn HDR ON to scan contrasting textures SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 45: Scan With Fixed Mode
Ctrl + Left mouse: Deselect selected data. Edit buttons: ①Deselect ②Revert ③Delete ④Undo ⑤Show/Hide texture (for data with color texture only) ⑥Shift + Left mouse: choose data ⑦Ctrl + Left mouse: deselect selected data SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 46 Then change the position of the scanner or the object to scan again. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 47: Scans & Groups
The group can be deleted or split to realign with other group data or single data. Disable texture (color pack) to select scan by left mouse on the 3d view SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 48: Edit Scan(S)/Group(S)
SHIFT + click left mouse button to select at least 3 non-collinear corresponding points in the 3D preview windows for Manual Alignment, as shown below. Ctrl+Z: cancel last point picked SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 49 Click Confirm to validate the modification and go back to the scan interface Click Reset to go back to the scan interface Click Next to continue to align scans SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 50: Hd Mode
‘Save’ to enter the scan parameters window. Feature alignment is only active when the HD Prime pack is attached and the scanned object has enough geometric features. It is only applicable to the EinScan Pro+. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 51 0.2mm to 3.0mm. Global Marker File If you want to use a previously created Global Marker File (GMF), you may click browse to import one as .ASC, .TCT or .P3. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 52 Browse to load a GMF SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 53: Scan
In this mode, you can: ● Check the working distance ● Adjust the brightness sensitivity ● Ensure that the markers are well captured. Exit Preview mode and start the scan or press SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 54: Scan Distance
Adjust the scanner position until the range finder’s color turns green. Pro+ Closer limit (mm) Optimal distance (mm) Upper limit (mm) SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 55: Brightness
Exposure adjustment menu, press +/- or click and drag the cursor Adjust the brightness according to the following illustration: Red means overexposed, black is underexposed, and white or light grey is good. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 56: Start Scan
During scanning make sure to keep the scanner perpendicular to the surface, keep a proper distance from the object, and adjust the brightness depending on the ambient light and texture of the object. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 57: Alignment
(displayed in green). The data is captured along the lines, as shown below. To record the data, a minimum of 4 markers (displayed in red) in each frame (every scanning field of view) has to be captured. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 58: Pause Menu
Note: If you have imported a global marker file, new markers cannot be added during the scan 6.4. Pause Menu In offline mode, the data can be loaded at this step for editing. 6.4.1. Auto Save Enter pause menu or press SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 59: Edit Menu
Click the button or “DELETE” on the keyboard to delete the selected data. Undo You can only undo the most recently deleted data. Note: Handheld scan mode does not support the deletion of markers. End the editing SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 60 Revoke all and exit editing Click Check to End the editing and confirm to save the edition in the project file and go back to the Previous menu. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 61: Rapid Mode
Rapid mode can be used on objects from 30mm to 4m. With Rapid mode, you can achieve a large size scan efficiently. In this example, the statue is 1m*1.5m*1.5m. Scan example with Rapid mode 7.1. Handheld Scanner Key Functions SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 62: Before Scan
7.2.1. Alignment Conditions Marker Alignment (Pro+ or R2 add-on) The surface of the object requires markers. When the scan starts the markers are required, otherwise “Track lost” will be displayed. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 63 GMF (Pro+ or R2 add-on) With Markers and Mixed alignment, you may click browse to import a previously created Global Marker File (GMF) as .ASC, .TCT or .P3. Browse to load a GMF SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 64: Resolution
When importing a project, and continuing to scan, the scanning resolution and alignment mode will be the same as the previous setting of the imported project. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 65: Scan
In this mode, you can: ● Check the working distance ● Adjust the brightness sensitivity ● Ensure that the markers are captured well. Exit Preview mode and start the scan or press SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 66: Scan Distance
Green shows it is a good distance away from the object. Adjust the scanner position until the rangefinder color turns green. Pro+ Closer limit (mm) Optimal distance (mm) Upper limit (mm) SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 67: Brightness
Exposure adjustment menu, Press +/- or drag the cursor Adjust the brightness according to the following illustration: Red means overexposed, Black is underexposed, white or light grey is good. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 68: Start Scan
During scanning, make sure to keep the scanner perpendicular to the surface, keep the distance in a proper range, and adjust the brightness depending on the ambient light and texture of the object. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 69: Alignment
(displayed in red), record data and align with previously collected markers (displayed in green). The green area is the current scan, as shown below. To record data a minimum of 4 markers (display in red) has to be captured. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 70 The software switches between features and marker alignment automatically if at least 4 markers are collected simultaneously. For objects with few geometric features which are difficult for feature alignment, an alert will suggest sticking markers on these areas. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 71: Pause Menu
Or select data to use editing tools. 7.4.2. Edit Menu SHIFT + Left mouse：Select unwanted data, the selected section will be displayed in red, as shown below. Ctrl + Left mouse: Deselect the selected data SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 72: Generate Point-Cloud
When finished editing, an optimized point-cloud will be generated. This step is accessible in Offline mode. When scanning without markers, choose between Quality and Speed priority for the point-cloud optimization and click Apply. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 73 This optimization process consumes memory and takes a long time. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 74: Post Processing
Or select data to enter use Edit menu. 8.1.2. Edit Menu SHIFT + Left mouse：Select redundant area, the selected section will be displayed in red, as shown below. Ctrl + Left mouse: Deselect selected data. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 75 End the editing Revoke all and exit editing Click Check to End the editing and confirm to save the edition in the project file and go back to the Previous menu. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 76: Create Mesh
Processing time is quicker than Watertight. Select the resolution of the mesh for a watertight model. Choose mesh resolution Note: If some data are not connected. Watertight will keep only the biggest data. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 77: Mesh Editing
8.3.1. Data Simplification Enter/Exit the simplification menu Click the Data simplification button to display the simplification menu, click again to close the menu Simplification menu SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 78: Hole Filling
After simplification 8.3.2. Hole Filling Marker Filling Enter/Exit the Marker Filling menu Click the Marker Filling button to display the marker filling menu, click again to close the menu SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 79 In this mode the hole edges are displayed green. It will get red after selected Choose Curvature, Tangent or Flat before picking a hole Click the edge of the hole to fill it Click Cancel to undo the last hole filling SHINING 3D - EinScan-Pro series - User Manual - June 2019...
- Page 80 Click the Auto Fill button to display the Auto Fill menu, click again to close the menu Auto Hole Filling menu Choose the hole filling type: Curvature, Tangent or Flat Input the perimeter of the biggest hole to be filled. Less than 100mm is recommended SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 81: Smooth
Click the Smooth button to display the smooth menu, click again to close the menu Smooth menu Pick High (85%), Medium (50%) or Low (15%) or set the ratio from 1 to 100 Original ↓ SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 82: Sharpen
8.3.4. Sharpen Enter/Exit the sharpen menu Click the Sharpen button to display the menu, click again to close the menu Sharpen menu Pick High, Medium or Low SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 83: Go Back To Scan
You can do more scans, redo editions, or remesh. The mesh data will NOT be saved automatically. Note: Exit the mesh edition mode Click on the navigation bar to exit the edition mode SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 84: Save
◆ Inspection optimized point- scan.asc ◆ Fast export (no post- (whole) cloud processing needed in hand-held mode) ◆ Large data to post process in another SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 85: Scale Data
By default, the scale is 100% and will be exported with millimeters for reference. The value display represents the dimensions of the smallest box containing the data oriented to the reference axis. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 86: Share Data
Upload the data to Sketchfab.com directly, which is a famous online 3D data store. Click Upload after mesh to share data, it will show the dialog as below. Sketchfab uploader window SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 87: Third-Party Software
EinScan Pro series software to open Solid Edge SHINING 3D Edition. The meshed STL data will also be imported to Solid Edge SHINING 3D Edition in a new part project directly. In the USB drive, there are videos for reverse engineering cases of EinScan scan data processed by Solid Edge SHINING 3D Edition. -
Page 88: Model Preview
Open the Model Preview software on the desktop or in the start menu start menu > Shining3d_EinScan-Pro series> Model Preview Drag files into the window for preview. Manipulate the data with the same control as EXScan software Model Preview SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 89 Fail to load the mesh data Note: To load a OBJ textured file make sure to have the MTL and JPG files with the same name and in the same folder than the OBJ SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 90: Color Pack
Screw the color camera into the slot, using the Allen key in clockwise direction (2) Plug the cable into the Camera port of the scanner, the red dot facing up. (3) Power on the scanner and the camera driver will start by itself. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 91 Check the device manager to see if the texture camera will show the following Device manager with EinScan and texture camera connected SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 92: Calibration
On the White side of the calibration board, under the same working lighting environment. Click Start or Press Play, move up and down until you find the optimal distance position. Stay still. While LED and white light are projected SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 93 Similar to taking high-quality picture in the photo studio, the professional lighting environment setting is key to achieve high-quality texture data. If the texture doesn’t give you satisfaction, please optimize the lighting environment and redo White balance. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 94: Fixed Mode
Display Cameras Run the same way that described above. After every single scan, the LED of the texture camera will flash and the texture camera will record one frame data. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 95: Alignment
If the texture is misaligned to the data, check that the camera is well placed and locked. And redo the calibration. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 96: Rapid Mode
During the preview, the texture will not show. During the scan, display the texture camera view by checking the “Texture Camera” Display Cameras Notes: ● The texture is not used to calculate the data alignment. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 97: Alignment
Generate the mesh model from the scanned point cloud data Click Mesh Model to generate the Mesh (watertight or unwatertight). The texture capture is separate from the 3d data capture. If the texture has been captured, it will SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 98: Texture Remapping
Enter the texture remapping menu Click the Texture Remapping to display the Texture menu, click again to close the menu Texture remapping is accessible before saving the data Confirm texture remapping before saving SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 99: Texture Layout Optimization
3 party software. This option has no effect on the texture itself. Click Apply to continue. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 100: Brightness & Contrast
When the mesh model has been generated, use the cursors to change the Brightness and/or contrast of the texture from -100 to +100. Click Reset to return to 0. The default value is 0 for both. Modify texture SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 101: Export Data
How to edit or remove markers on the texture? Use a 3 party software like Photoshop or Gimp, save as OBJ and erase the markers on the matching JPG file. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 102: Industrial Pack
(5). Make sure to check the advice for Fixed Mode when using the turntable [see 5.1]. Check the Device manager. The turntable will be displayed as below. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 103: Scan
In scan setting, on the top right, Check the box to use the turntable, or Uncheck to disable it. Fixed scan with turntable If you plug-in the turntable during a fixed scan project, click Scan Mode selection in the navigation bar, and reopen the project. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 104: Turntable Steps
At least 4 common targets need to be recognized between 2 neighboring scans. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 105: Feature Alignment
An object with simple features like plain, symmetric surface such as a sphere or cylinder is not recommended for this mode. It is better to use markers to facilitate the alignment for an object with few geometry features. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 106: Markers Alignment And Global Markers Alignment
Markers alignment works in a similar way as turntable coded target alignment; the software matches 2 neighboring scans by recognizing at least 4 common markers. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 107 Global Markers is accessible if a Global Marker File has been loaded during the project creation. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 108: Hd Prime Pack
It captures more details than handheld rapid scan mode under HD prime without markers. comparison of scan details captured by Pro Rapid mode and HD Prime 11.1 Hardware 11.1.1. Content SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 109: Specifications
Power on the scanner and the camera driver will start by itself. Check the device manager to see if the Prime will show as the following Device manager with EinScan and HD Prime connected SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 110: Firmware Upgrade
11.2. Before scan When prime is plugged, “HD Scan” becomes “HD Scan with Prime”. Other modes are not using Prime (refer to previous sections for Fixed and Rapid mode). SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 111: Align Mode
The project will be saved with the extension .hd_prj Prime with markers projects can be open under HD scan mode (without Prime) Feature Alignment SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 112: Resolution
When import project, and continue the scan, the scanning resolution and align mode will be in accordance with the previous setting of imported project. Click Apply to validate and enter the Scanning interface SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 113: Hd Prime Scan
Preview mode. In this mode, it will start to show data for preview, but not yet record. Preview with or without markers Check the box “Prime camera” to replace the display of the normal camera(s) with Prime camera(s). SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 114: Brightness
When scanning or in Preview mode Press twice Play button, adjust the brightness by pressing “+/ -” buttons on the scanner, or drag the cursor under the camera preview to left (-) or the right (+). SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 115: Scan With Markers
The software will recognize the markers (display in red), record data and align with previously collected markers (display in green). The data is captured along the lines, as shown below SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 116: Scan Without Features
When start scanning, the data is captured along the lines, previously captured data shows gray as below. To improve the scan efficiency, the movement should be continuous and uniform. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 117: Pause Menu
Track lost alert 11.4. Pause menu In Off-line mode the data can be loaded at this step for editing. 11.4.1. Auto-save Enter pause menu OR press SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 118: Edit Menu
Click the button or “DELETE” in the keyboard to delete selected data. Undo You can only undo the last deleted data. Note: Handheld scan mode does not support the deletion of markers. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 119 End the editing Cancel editions on the data Click Check to End the editing and confirm to save the edition in the project file and go back to the Previous menu. SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 120: Support And Contact
12.1.1. Log In To register a user account, please enter the serial number of the scanner and your contact information including a valid email. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 121: Validate Your Warranty
To validate the warranty of your device, click add new device in My Account. Account page Input the serial number, input the date of purchase and upload the copy of the invoice. SHINING 3D - EinScan-Pro series - User Manual - June 2019... -
Page 122: Submit A Ticket
12.1.3. Submit a Ticket Log in with your Community account. Click New Ticket on the tab bar. Select the serial number among the registered accounts and describe your problem. SHINING 3D - EinScan-Pro series - User Manual - June 2019... - Page 123 Submit a ticket Check your submitted tickets under the account page or the Ticket > My tickets. Opened ticket SHINING 3D - EinScan-Pro series - User Manual - June 2019...
-
Page 124: Contact Us
Add: Panorama, Heilbronner straße 86, 70191, Stuttgart, Germany Americas Region SHINING 3D Technology Inc. San Francisco, United States Phone: +1 415 259 4787 Add: 1740 Cesar Chavez St. Unit D. San Francisco, CA 94124 SHINING 3D - EinScan-Pro series - User Manual - June 2019...
