Scan - Shining 3D Transcan C User Manual

Note: Objects in regular shapes such as sphere and square are not suitable for this mode. With
feature align, need to make sure the object will not move when turntable rotates. And the objects
need to have enough features for the software to recognize.
During the "verifying" steps, the software calculates the position of the turntable
Global Markers Alignment
When there is an object global marker file and the position (where global markers are located on the
object) is not changed, global markers can be used for alignment.
How it works: Align by imported global marker files and markers stuck on the object. At least four
markers are required.
Ensure global markers size is consistent with object size.

6.3. Scan

6.3.1. Start Scanning
Click the button or press Space key to start scanning.
Click the pause button, and the scanning will pause; Click again to resume scanning.
When the scan is completed, the data is automatically saved in the project file. Make sure the relative
position does not change during the scan.
When auto scan mode is scanning, you can click the button to stop the current scan. The
current data will be deleted directly.
