Appendix A: Power Consumption

a a: P
PPendIx
Power Consumption Management
Purpose
This chapter is to measure the maximum momentary current.
Test Equipment
1. GWInstek PSW 30-36 360W DC power supply
Device Under Test
DUT: Neu-X304-Q670W
Test Procedure
1. Use DC power supply to measure the power consumption.
2. Full-Loading Test program: Win 10 x64 with BurnIn Test V10.2 (1007)
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower onsumPtIon
Test Data
Mode Test
S3 Mode Current (A)
Total Watts(W)
Idle Mode Current (A)
Total Watts(W)
Full-Loading Mode Current (A)
Total Watts(W)
BurnIn Item
2D Graphic
3D Graphic
CPU
Disk(M.2)
GPGPU
(Connect load Device)
Memory(RAM)
64
+12V +24V
0.26A 0.17A
3.12W 4.08W
1.7A 0.8A
20.4W 19.2W
8.0A 4.0A
96.0W 96.0W
Test BurnIn Item
V Network
V Serial Port
V Sound
V Video Playback
V USB Port x6
V
V
Neu-X304 Series User Manual
Test
V
V
V
V
V
