Chapter 2: Jumpers and Connectors

LVDS/eDP Panel Connector

Connector type: 1x40-pin connector, 0.5mm pitch
Connector location: LVDS_EDP1
1 40
LVDS
Pin Definition
1 LVDS_DAT3P
3 LVDS_DAT3N
5 LVDS_DAT2P
7 LVDS_DAT2N
9 LVDS_DAT1P
11 LVDS_DAT1N
13 LVDS_DAT0P
15 LVDS_DAT0N
17 LVDS_DAT7P
19 LVDS_DAT7N
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 LVDS_DAT6P
4 LVDS_DAT6N
6 LVDS_DAT5P
8 LVDS_DAT5N
10 LVDS_DAT4P
12 LVDS_DAT4N
14 GND
16 +V_PANEL
18 +V_PANEL
20 +V_PANEL
Pin Definition
21 GND
23 +V_PANEL
25 GND
27 GND
29 GND
31 LVDS_CLK1P
33 LVDS_CLK1N
35 GND
37 GND
39 GND
20
Pin Definition
22 Hot-Plug Detect
24 INV_BKLTEN
26 INV_BKLTCTRL
28 LVDS_CLK2P
30 LVDS_CLK2N
32 +V_INV
34 +V_INV
36 +V_INV
38 +V_INV
40 N.C.
Continued on next page
