Chapter 4: BIOS Setup
Advanced
The Advanced menu allows you to configure your system for basic operation.
Some entries are defaults required by the system board, while others, if
enabled, will improve the performance of your system or let you set some
features according to your preference.
Setting incorrect field values may cause the system to malfunc-
tion.
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
USB Power State in S5
Select USB power state in S5.
eDP/LVDS Power State
Select eDP/LVDS controller power state.
State After Power Loss
Specify what state to go to when power is re-applied after a power failure
(G3 State).
Wake on LAN/COM
Enable or disable integrated LAN/COM port RI to wake the system.
42
Neu-X304 Series User Manual
