Chapter 2: Jumpers and Connectors
Pin Definition
41 PCIE_RXN
43 PCIE_RXP
45 GND
47 PCIE_TXN
49 PCIE_TXP
51 GND
53 CLK_DN
55 CLK_DP
57 GND
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
42 NC
44 NC
46 NC
48 NC
50 RESET(3.3V)
52 CLKREQ#
54 WAKE#
56 NC
58 NC
Pin Definition
59 NC
61 NC
63 NC
65 NC
67 RESET(1.8V)
69 CONFIG1
71 GND
73 GND
75 CONFIG2
23
Pin Definition
60 NC
62 NC
64 NC
66 NC
68 SUS_CLK
70 3.3V
72 3.3V
74 3.3V
