Chapter 2: Jumpers and Connectors
LVDS Inverter Connector
Connector type: 2x3, 6-pin header JST, 2.54mm pitch
Connector location: INVN1
5
1
6
2
Pin
Definition
1
GND
3
+V_INV
5
INV_BKLTEN
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
+V_INV
6
INV_BKLTCTRL
19
Neu-X304 Series User Manual
