Chapter 2: Jumpers and Connectors
Jumpers & DIP Switches

Clear CMOS

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: CLRCMOS
1 3
Pin Settings
1-2 On Normal (default)
2-3 On Clear CMOS
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.

COM2 RI Select

Connector type: 1x5-pin header, 2.0mm pitch
Connector location: JP1
1 5
Pin Settings
1 RI (Default)
2 COM2_RI (Default)
3 +5V
4 COM2_RI
5 +12V
10
