12
15
11
1. Unit cover
2. ISU housing
3. Reflector
4. Transparent material
5. Mirror A
6. Mirror B
7. Mirror C
8. Mirror D
7
3 14
4
10
Figure 2-1-12 Image scanner unit (ISU)
2-1-12
13
1
5
6
9. Mirror E
10. ISU lens
11. CCD PWB (CCDPWB)
12. DriverPWB (DRPWB)
13. LED PWB (LEDPWB)
14. LED
15. Home position sensor (HPS)
2PZ
8
2
9
