(2) Detaching and refitting the paper feed roller unit

Procedure
1. Remove the retard roller unit (see page
1-5-14).
2. Turn forward the lever of the feed pin to
release the lock.
3. Slide the feed pin.
1
Lever
Feed pin
2
Feed pin
Figure 1-5-23
1-5-16
2PZ
