OPERATION GUIDE
FS-1100
TASKalfa 180/220
FS-1300D

Advertisement

Table of Contents
loading

Related Manuals for Kyocera TASKALFA FS-1100

Summary of Contents for Kyocera TASKALFA FS-1100

  • Page 1 OPERATION GUIDE FS-1100 TASKalfa 180/220 FS-1300D...
  • Page 2 Introduction Thank you for your purchase of Taskalfa 180/220. This Operation Guide is intended to help you operate the machine correctly, perform routine maintenance and take a simple troubleshooting action as necessary, so that you can always use the machine in good condition. Please read this Operation Guide before you start using the machine, and keep it close to the machine for easy reference.

  • Page 3: Table Of Contents

    CONTENTS Names of Parts ... 1-1 Main Body ...1-1 Preparations ... 2-1 Loading Paper ...2-1 Loading Paper into the Cassette ...2-2 Cassette Size Detection ...2-4 Setting Paper in the Multi Purpose Tray ...2-4 Loading postcards or envelopes in the MP tray ...2-7 MP Tray Size and Media Type ...2-8 Selecting a Size from Regular Sizes ...2-8 Selecting a Size from Other Regular Sizes ...2-8...
  • Page 4 Optional Equipment ... 5-1 Document Processor ... 5-1 Paper Feeder ... 5-2 Duplex Unit ... 5-2 Key Counter ... 5-3 Printer Kit / Printer Server ... 5-3 Additional Memory ... 5-3 Maintenance ... 6-1 Cleaning the Machine ... 6-1 Replacing the Toner Container and the Waste Toner Box ... 6-5 Troubleshooting ...
  • Page 5 Notice The information in this guide is subject to change without notification. Additional pages may be inserted in future editions. The user is asked to excuse any technical inaccuracies or typographical errors in the present edition. No responsibility is assumed if accidents occur while the user is following the instructions in this guide.
  • Page 6 Energy Saving Contol Function The device comes equipped with a Low Power Mode where energy consumption is reduced after a certain amount of time elapses since the device was last used, as well as a Sleep Mode where printer and fax functions remain in a waiting state but power consumption is still reduced to a minimum when there is no activity with the device within a set amount of time.
  • Page 7 Please read this Operation Guide before using this machine. Keep it close to the machine for easy reference. Please read this Operation Guide before using this machine. Keep it close to the machine for easy reference. The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine.
  • Page 8 symbol indicates that the related section includes information on actions which must be performed. Specifics of the required action are indicated inside the symbol. [Alert of required action] [Remove the power plug from the outlet] [Always connect the machine to an outlet with a ground connection] Please contact your service representative to order a replacement if the safety warnings in this Operation Guide are illegible or if the guide itself is missing.

  • Page 9: Caution Labels

    IMPORTANT! PLEASE READ FIRST. CAUTION LABELS Caution labels have been attached to the machine at the following locations for safety purposes. Be sufficiently careful to avoid fire or electric shock when removing a paper jam or when replacing toner. Label 2 High temperature inside.

  • Page 10: Installation Precautions

    INSTALLATION PRECAUTIONS Environment Caution Avoid placing the machine on or in locations which are unstable or not level. Such locations may cause the machine to fall down or fall over. This type of situation presents a danger of personal injury or damage to the machine. Avoid locations with humidity or dust and dirt.

  • Page 11: Precautions For Use

    If the floor is delicate, when this product is moved after installation, the floor material may be damaged. During copying, some ozone is released, but the amount does not cause any ill effect to one's health. If, however, the machine is used over a long period of time in a poorly ventilated room or when making an extremely large number of copies, the smell may become unpleasant.

  • Page 12: Other Precautions

    Do not damage, break or attempt to repair the power cord. Do not place heavy objects on the cord, pull it, bend it unnecessarily or cause any other type of damage. These types of situations present a danger of fire or electrical shock. Never attempt to repair or disassemble the machine or its parts as there is a danger of fire, electrical shock or damage to the laser.

  • Page 13: Handling Of Plastic Bags

    Do not touch electrical parts, such as connec damaged by static electricity. Do not attempt to perform any operations not explained in this handbook. Caution: Use of controls or adjustments or per Do not look directly at the light from the scanning painful.

  • Page 14: Safety Of Laser Beam

    SAFETY OF LASER BEAM 1. Safety of laser beam This machine has been certified by the manufacturer to Class 1 level under the radiation performance standards established by the U.S.DHHS (Department of Health and Human Services) in 1968. This indicates that the product is safe to use during normal operation and maintenance.

  • Page 15: Radio Tag Technology

    Safety Instructions Regarding the Disconnection of Power Caution: The power plug is the main isolation device! Other switches on the equipment are only functional switches and are not suitable for isolating the equipment from the power source. Attention: Le débranchement de la fiche secteur est le seul moyen de mettre l’appareil hors tension. Les interrupteurs sur l’appareil ne sont que des interrupteurs de fonctionnement: ils ne mettent pas l’appareil hors tension.
  • Page 16 DECLARATION OF CONFORMITY 89/336/EEC, 73/23/EEC and 93/68/EEC We declare under our sole responsibility that the product to which this declaration relates is in conformity with the following specifications. Limits and methods of measurement for immunity characteristics of information technology equipment Limits and methods of measurement for radio interference characteristics of information technology equipment Limits for harmonic currents emissions...
  • Page 17 Guide to this Operation Guide This operation guide has the following chapters. The content of these chapters is summarized below to be used as a reference. 1 Names of Parts This chapter contains explanations on the names and functions of the parts of the machine and its operation panel.

  • Page 18: Conventions In This Guide

    Conventions in This Guide The following conventions are used depending on the nature of the description. Convention [Bold] Indicates the operation panel keys or a computer screen. Italic Indicates a message displayed on the touch panel. Used to emphasize a key word, phrase or references to additional information.

  • Page 19: Originals And Paper Sizes

    Originals and Paper Sizes This section explains the notation used in this guide when referring to sizes of originals or paper sizes. As with A4, B5 and Letter, which may be used either in the horizontal or vertical direction, horizontal direction is indicated by an additional letter R in order to indicate the orientation of the original/paper.

  • Page 20: Names Of Parts

    Names of Parts Main Body Original cover — Open/close this cover when setting the original on the platen. Output tray — Finished copies or printouts are stored on this tray. The output tray has a storage capacity of 250 sheets of standard paper (80 g/m²). Operation panel —...
  • Page 21 11 Platen — Set an original here for copying. Be sure to lay the original face-down and align the edge of the original flush up against the left rear corner of the platen. 12 Original size indicator plates — Be sure to set an original along these plates when setting it on the platen.
  • Page 22 Names of Parts 19 Main power switch — Turn this switch on ( | ) before using this machine. 20 Main power switch cover — Open to operate the main power switch. 21 Handles for transport — Hold the four recessed portions at the right and left when transporting this machine.

  • Page 23: Operation Panel

    Names of Parts Operation Panel US model Start Key (Indicator) Stop/Clear Key Reset Key Energy Saver Key Numeric keys Interrupt Key Logout Key OK Key /Auto%100% Key Paper Supply Indicator Paper Selection Key Paper Supply Level Indicator Paper Misfeed Indicator MP Indicator No.
  • Page 24 European model Attention Indicator Error Indicator Add Toner Indicator Maintenance Indicator Image Quality Selection Key Printer Key (Indicator) Press this to switch the message display between copier mode and printer mode, when the optional printer kit is installed. 2-sided Key Mixed Original Size Key Combine Key Split Key...

  • Page 25: Message Display

    Names of Parts Message Display The message display on the operation panel shows: • Status information, the messages listed below which are displayed during normal operation. • Error codes, when the printer requires the operator’s attention, refer to chapter „Troubleshooting“. Status Information Message The copier is performing self-diagnostics after power-up.

  • Page 26: Automatic Cassette Switching Function

    Names of Parts Automatic Cassette Switching Function If multiple cassettes contain the same size paper and the paper in one cassette runs out during copying, the automatic cassette switching function will switch paper feed from the empty cassette to the other cassette that still contains paper.
  • Page 27 Names of Parts...

  • Page 28: Preparations

    Preparations Loading Paper Paper can be loaded into either the cassette or the multi-purpose tray. Note for Adding Paper After taking new paper out of its packaging, be sure to fan through the paper a few times to separate the sheets before loading that paper into the cassette or the multi-purpose tray.

  • Page 29: Loading Paper Into The Cassette

    Loading Paper into the Cassette Standard paper, recycled paper, and colored paper can be loaded into the cassette. Up to 300 sheets of standard paper (80 g/m²) or 100 sheets of thick paper (90 to 105 g/m²) can be set. Paper sizes that can be loaded are: A3, B4, A4, A4R, B5, B5R, A5R, Folio, 11 ×...
  • Page 30 Grasp the paper length adjusting tab and adjust the length guide to the paper size. Important! • Make sure that the length guide is flush against the paper. If there is space between the guide and the paper, set the length guide again. •...

  • Page 31: Cassette Size Detection

    Affix the label supplied so that the paper size set in the cassette can be identified from the front of the cassette. Gently push in the cassette. Important! When the machine will not be used for a long period of time, remove the paper from the cassette, put it in a storage bag, and seal the bag in order to protect the paper from moisture.
  • Page 32 Open the multi-purpose tray. Note Pull out the multipurpose tray extension to match the paper size. Adjust the sliders to the width of the paper to be set. Set the paper along the sliders and put it in until it stops.
  • Page 33 Important! • Always straighten out postcards and other types of thick paper that are curled before using them. The paper may not be fed depending on the paper quality. • When loading paper into the multi-purpose tray, set it with the side which faced the top of its packaging facing down.

  • Page 34: Loading Postcards Or Envelopes In The Mp Tray

    Loading postcards or envelopes in the MP tray When loading a postcard or envelope, open the paper stopper shown in the figure. For landscape envelopes, close the flap. Insert the envelope all the way along the width guides, keeping the printing side face-down and the edge with the flap facing towards you.

  • Page 35: Mp Tray Size And Media Type

    MP Tray Size and Media Type Adjust the paper in the MP Tray, register the paper size using the Operation Panel and specify the media type. Selecting a Size from Regular Sizes Press the Paper Selection key for 3 seconds. The System Menu will be displayed.

  • Page 36: Specifying Custom Paper Size

    Specifying Custom Paper Size Select the Customized Size. (Refer to Selecting a Size from Regular Sizes on page 2-7.), and press the OK key. Press 297(mm): The range in which setting is possible, and press the OK key. Press to 432(mm): The range in which setting is possible, and press the OK key.

  • Page 37: Loading Originals

    Loading Originals Follow the steps below to load originals for copying or sending. Placing Originals on the Platen You may place books or magazines on the platen in addition to ordinary sheet originals. In addiiton, When copying from an original which cannot be set in the document processor, open the document processor and set the original directly on the platen.

  • Page 38: Loading Originals In The Document Processor

    Loading Originals in the Document Processor The optional document processor automatically scans each sheet of multiple originals. Both sides of two-sided originals are scanned. Originals Supported by the Document Processor The document processor supports the following types of originals. • Sheet originals only •...

  • Page 39: How To Load Originals

    How to Load Originals Before loading originals, be sure that there are no originals left on the original eject table. Originals left on the original eject table may cause the new originals to jam. Adjust the original width guides to fit the originals. Note Before setting originals, make sure that there are no originals remaining on the original eject table.

  • Page 40: Turning Power On

    Turning Power On To turn machine power on: Open the main power switch cover located on the right side of the machine and turn the main power switch on ( | ). The machine starts to warm up. Once warm-up is completed, the Start indicator lights up green. 2-13...

  • Page 41: User Interface Language

    User Interface language You can select the language that is used in the message display. Display the System Menu. Press the Press the 2-14 key or the key to select 02.Language. Press the OK key. key or the key to select the language. Press the OK key.

  • Page 42: Basic Operation

    Basic Operation This chapter explains the following operations. • Basic Copying Procedure • Zoom Copying • Duplex Copying • Collated Copying • Combined Copying • Interrupt Copying • Low Power Mode • Auto Sleep Basic Copying Procedure Turn the main power switch on ( | ). At the end of warm-up, the Start indicator lights up green.
  • Page 43 Image quality mode Text + Photo Text Photo Adjust the copy density either manually (manual density mode) or automatically (auto density mode) with automatic detection of the contrast of the original. Press the numeric keys to set the desired number of copies (Up to 999). Press the Start key to start copying.

  • Page 44: Zoom Copying

    Zoom Copying Copied images can be reduced or enlarged by zooming. The following modes are available for zoom copying. Mode Auto zoom ratio selection mode Zoom mode Preset zoom mode Note When the magnification ratio is larger than 201%, the images will be rotated 90° counter-clockwise prior to copying.

  • Page 45: Manual Zoom

    Manual Zoom The zoom ratio can be manually set between 25 % and 400 % in 1 % increments. Set the original. Press the Press the OK key to confirm the zoom ratio. Press the Start key. Copying starts. key or the key.

  • Page 46: Duplex Copying

    Duplex Copying Duplex (two-sided) copies can be made from a variety of originals including double-page spread or two-sided originals. Note The optional duplex unit must be installed. The following modes are available for duplex copying: Mode 1-sided->2-sided (2-sided copying from 1-sided originals) Description One-sided originals are copied onto the front and back sides of the...
  • Page 47 Mode 2 sided->2 sided (2-sided copying from 2-sided originals) Book->2-sided (2-sided copying from double-page spread originals) Set the original. Press [2-sided], select the type of original and select corresponding display. Enter the number of copies using numeric keys. Press the Start key. Scanning of the original starts. If the originals have been set in the optional document processor, copying starts automatically.

  • Page 48: 2-Sided Copy Reverse Side Rotation Setting

    2-Sided Copy Reverse Side Rotation Setting Follow the procedure below to change the rotation setting for the reverse side when making 2-Sided copies. Press the 2-sided key for 3 seconds. The System Menu for the reverse side setting of 2-Sided Copies will be displayed. Press Rotation Off when it isn't to be rotated, and then press the OK key.

  • Page 49: Split Copying

    Split Copying Copy books, magazines, etc. with two facing pages of an open-faced original onto separate sheets of paper. Two-sided to One-sided Copies each side of a two-sided original onto two individual sheets. The optional document processor is required. Book to One-sided Produces a 1-sided copy of a 2-sided or open book original.

  • Page 50: Collated Copying

    Collated Copying A number of collated copy sets can be produced. Note If the optional document processor is installed, you can select whether or not to turn on the sort mode at a default setting. Set the original. Press the Collate key. Input the number of copies and press the Start key.

  • Page 51: Combined Copying

    Combined Copying Two or four originals are reduced and copied onto a single sheet. Also, borderlines of each original can be marked with solid or dotted lines. Press the Combine key to light up the indicator. Note Both the original size and the copy paper size must be standard size. The following modes are available for combine copying.

  • Page 52: In-1

    2-in-1 The orientations of the originals and the finished copy are shown below. Using the platen: Using the document processor: Original Original Original Original Copy Copy Copy Copy 3-11...

  • Page 53: 4-In-1 (Horizontal)

    4-in-1 (horizontal) The orientations of the originals and the finished copy are shown below. Using the platen: Using the document processor: 3-12 Original Original Original Original Copy Copy Copy Copy...

  • Page 54: 4-In-1 (Vertical)

    4-in-1 (vertical) The orientations of the originals and the finished copy are shown below. Using the platen: Using the document processor: Original Original Original Original Copy Copy Copy Copy 3-13...

  • Page 55: Interrupt Copying

    Interrupt Copying The interrupt mode temporarily stops the output of copy jobs and allows the output of an urgent copy. After the urgent interrupt job is finished, the interrupted job will be automatically resumed. During a copy job press the Interrupt key. The Interrupt indicator will blink Remove the originals of the ongoing copy job.

  • Page 56: Low Power Mode

    Basic Operation Low Power Mode Pressing the Energy Saver key puts the machine into a resting state (low power mode) even when the main power switch is on. During low power mode, the No. of Copies/Zoom display shows '---'. Press the any key to resume copying operations. The recovery time before copies can be made is 10 seconds.

  • Page 57: Auto Sleep

    Auto Sleep This machine is equipped with the auto sleep function that automatically puts this machine into the sleep mode if no operation has been performed on the machine for a preset period of time. The factory default setting time is one minute. Press the Energy Saver key again to resume copying operations.

  • Page 58: Job Accounting

    Job Accounting Overview of Job Accounting Job Accounting allows you to manage the number of copies for each department through the setting of the Department ID Code separately for each department. This copier has the following features available through the Department ID Code. •...

  • Page 59: Job Accounting Operation Procedures

    Job Accounting Operation Procedures Follow the procedures listed below to operate Job Accounting. Press the Exposure Adjustment keys on both sides for 3 seconds while pressing the Logout key. Job Accounting: will be displayed. Press NOTE: Refer to each of the following setting procedures and make the settings. Each of the Modes can be selected by pressing the numeric keys.

  • Page 60: Deleting Department Id Codes

    Deleting Department ID Codes Deleting a registered Department ID Code. Display Job Accounting. (Refer to Job Accounting Operation Procedures on page -2.) Press and then press the OK key. Enter the Department ID Code to be deleted using the numeric keys. NOTE: If a mistake is made during input it can be cleared by pressing the Stop/Clear key and the value reentered.

  • Page 61: How To Set Job Accounting

    How to set Job Accounting Set Job Accounting to enable or disable it. Display Job Accounting. (Refer to Job Accounting Operation Procedures on page -2.) Press 01.JobAccounting, and then press the OK key. Press not be used, and then press the OK key. The display will return to that of Step 2.

  • Page 62: Optional Equipment

    Optional Equipment The following options are available for this machine. • Document Processor • Paper Feeder • Duplex Unit • Key Counter • Printer Kit / Printer Server • Additional Memory Document Processor This equipment automatically feeds and scans multiple-sheet originals one by one. Two-sided originals are automatically turned over so that both sides can be scanned.

  • Page 63: Paper Feeder

    Paper Feeder In addition to the cassette(s) provided with the main body, a paper feeder (with cassettes that can hold 300 sheets each) can be used. • The number of sheets that can be accommodated: 300 sheets (standard paper, 64 to 105 g/m²). •...

  • Page 64: Key Counter

    Key Counter The key counter is used to confirm the amount of usage of the copier functions. It is useful in managing copier usage for each department, section, etc. as well as in the company overall. Setting the Key Counter Set the key counter securely in the key counter slot.
  • Page 65 Optional Equipment Optional Equipment Overview of Optional Equipment The following optional equipment is available for the machine. Document Processor Additional Memory Duplex Unit Printer Kit Paper Feeder Print server (not in all countries) Key Counter...

  • Page 66: Maintenance

    Maintenance Cleaning the Machine For safety purposes, always remove the power plug from the outlet when performing cleaning operations. Cleaning the Original Cover Open the original cover and wipe the back side of the cover with a soft cloth dampened with alcohol or mild neutral detergent.

  • Page 67: Cleaning The Slit Glasses

    Cleaning the Slit Glasses If copies appear soiled, such as black lines appearing on the copy image while using the optional document processor, the slit glasses A and B are dirty. Wipe the slit glasses with a dry soft cloth. Important! Never use water, thinner, organic solvents or alcohol.

  • Page 68: Cleaning The Transfer Roller

    Move the brush from the left side to the right side along the separation needle as shown in the illustration to remove any dirt or dust. Close the left cover. Cleaning the Transfer Roller Open the front cover. Remove the cleaning brush. Pull the left cover handle up to open the cover.
  • Page 69 While turning the left transfer roller gear to turn the roller as shown in the illustration, move the brush from the left side to the right side along the roller to remove any dirt or dust. Close the left cover.

  • Page 70: Replacing The Toner Container And The Waste Toner Box

    Replacing the Toner Container and the Waste Toner Box When message Add toner is displayed on the message display the machine stops. Replace the toner container together with the waste toner box. Notes Add toner only when Add Toner is displayed on the message display. Whenever the toner container is changed, be sure to carry out the procedure described from step 7 on page 6-7 through step 11 on page 6-7.
  • Page 71 Use the cap attached to the center of the old waste toner box to cover the opening. Turn the toner container release lever A to the left to pull out the toner container. Do not attempt to incinerate the toner container or the waste toner box. Dangerous sparks may cause burns.
  • Page 72 While holding the charger cleaner rod, gently pull it out as far as it will go and push it in again. Repeat this operation two or three times. Note Do not use excessive force to pull the rod or attempt to pull it out completely. While pushing the electrical charge section to the right, pull it out approximately 5 cm (2 inches).
  • Page 73 Hold the new toner container vertically and tap the upper part five times or more. Turn the toner container upside down and tap the upper part five times or more. Shake the toner container up and down five times or more.
  • Page 74 Maintenance Close the front cover. After use, always dispose of the toner container and the waste toner box in accordance with Federal, State and Local rules and regulations.
  • Page 75 Maintenance 6-10...

  • Page 76: Troubleshooting

    Troubleshooting If Trouble Occurs If trouble occurs with this machine, carry out the items indicated below. If the trouble persists, contact your service representative. Symptom Items to check Nothing is displayed on the Is the power plug connected to an AC operation panel when the outlet? main power switch is...
  • Page 77 Troubleshooting Symptom Items to check A moire pattern (the Is the original a printed photograph? phenomenon where the dots do not appear to be lined up properly but seem to be grouped together in patterns) appears on the copies. The copies are not clear. Did you select an image quality mode properly according to the type of the original?
  • Page 78 Symptom Items to check Copies are blurred. Is this machine used at high humidity? Perform drum refresh. The copies are curled. Is the copy paper wet? Is Middle 2 set at the Paper type (Paper Weight) setting? (Normally, Middle 2 is set.) Corrective procedure Replace the copy paper with dry, new paper.

  • Page 79: Responding To Error Messages

    Troubleshooting Responding to Error Messages If the touch panel displays any of these messages, follow the corresponding procedure. Alphanumeric Display Add paper in cassette #. Add toner. Cannot copy this orig. size. Cannot duplex this paper size Call service. C#### Close document processor.
  • Page 80 Display Insert key counter. No matching paper available. MainPower Off/On A#### Memory is full. Cannot continue. Memory is full. Press OK. MP tray empty. Add paper. Paper jam Place orig on doc processor Replace waste toner box. Remove paper on top tray;...
  • Page 81 Troubleshooting Display Reseat originals on DP. Return all originals to DP. Set paper cassette. Shake the toner container. Set toner container. The Add Toner indicator blinks on and off. The Periodic Maintenance indicator blinks on and off. The Periodic Maintenance indicator lights up.

  • Page 82: Clearing Paper Jams

    Clearing Paper Jams Stop copying operations when a paper misfeed occurs. When a paper misfeed occurs, the indicator for the location of the paper misfeed will light up on the Operation Panel and either “J” plus a 2-digit number will be displayed as notification of the location of the paper misfeed.

  • Page 83: Notes

    Notes High voltage is present in the charger section. Take sufficient care when working in this area, as there is a danger of electrical shock. The fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned.
  • Page 84 Notes • Check to see if paper is out of position in the cassette. If the paper is out of position, set the paper properly. • If JAM21 is displayed, remove the jammed paper referring to J20 to J50, J52 to J57, J60, J61: Paper Jam in the Left Cover on page 7-10.
  • Page 85 Remove any jammed paper without tearing it. Note If the paper does happen to tear, remove any loose scraps from inside the machine. Push the cassette back in firmly. J10: Paper Jam in the Multi-Purpose Tray Perform the following procedure to remove the jammed paper. Remove all of the paper remaining in the multi-purpose tray.
  • Page 86 Pull the left cover handle up to open the left cover. The fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned. Remove any jammed paper without tearing it. Note If the paper does happen to tear, remove any loose scraps from inside the machine.
  • Page 87 If jammed paper is seen through the paper output slot, pull it out to remove it. Note If the paper does happen to tear, remove any loose scraps from inside the machine. Pull the left cover handle up to open the left cover. Remove any jammed paper without tearing it.
  • Page 88 Open the left cover. Remove any jammed original without tearing it. Note If the original does happen to tear, remove any loose scraps from inside the document processor. Failure to do so may cause another paper jam later. Raise the paper feed unit A. Remove any jammed originals without tearing them.
  • Page 89 Troubleshooting 7-14...

  • Page 90: Appendix

    Appendix Specifications Note Specifications are subject to change without notice to reflect improvements in performance. Main Body Copying system Original types accommodated Copy sizes Cassette Multi Purpose tray Width that cannot be copied Paper feed source capacity Cassette Multi Purpose tray Output tray capacity Warm-up time Memory...

  • Page 91: Copier Functions

    Copier Functions Copying speed Platen (1:1) First copy time Resolution Continuous copying Copying magnification Document Processor (optional) Original feed system Acceptable originals Original sizes Original paper weight Acceptable number of originals Mixed original sizes (auto select) Dimensions (W) × (D) × (H) Weight Paper Feeder (optional) Paper feed system...

  • Page 92: Duplex Unit (Optional)

    Duplex Unit (optional) System Paper sizes Acceptable paper Dimensions (W) × (D) × (H) Weight Environmental Specifications Recovery time from the low power mode Recovery time from Sleep mode Transition time to the low power mode (at time of purchase) Transition time to the sleep mode (at time of purchase) Duplex (2-sided) copying Paper feed...

  • Page 93: System Menu Items

    System Menu The copier will enter the System Menu after warm up has been completed or when the Reset key has been pressed. The settings automatically set for the copier in the System Menu are called the Default Settings. These settings can be freely changed to match the usage of the copier.
  • Page 94 System Menu Items Description 10.Text Density Adjusts the central exposure value for the copier’s manual exposure (Text). 11.ReduceStreaks It is possible to make black streaking less noticeable when it appears when using the optional Document Processor. 12.OptimizePhoto Setting this to Error Diffusion when copying originals with text and photos and Dithering when copying originals with mainly photos will result in clearer images.
  • Page 95 System Menu Items 19.Cassette1Size 20.Cassette2Size 21.Cassette3Size 22.Cassette4Size 23.MPTray Config Appendix-6 Description Automatically detects the paper size in the cassettes (1 to 4). When it is to be detected in inches, set this to AutoDetect inch; when the paper size is to be detected in centimeters, (A⋅B columns) set this to Auto Detect mm and when Oficio 2 , 8K or 16K size is to be used, set this to Oficio 2, 8K or 16K.
  • Page 96 System Menu Items Description 24.Custom Size 1 Sets the size to be set to the Custom size (1 to 2). This makes it possible to set the sizes that do not 25.Custom Size 2 appear on the operation panel. 26.Casst1MedType Specifies the media type to the cassettes (1 to 4).
  • Page 97 System Menu Items 30.CustmMedType1 31.CustmMedType2 32.CustmMedType3 33.CustmMedType4 34.CustmMedType5 35.CustmMedType6 36.CustmMedType7 37.CustmMedType8 38.Hagaki/A6RDet 39.B4R/Folio Det 40.11x15" Detect 41.Copy Limit 42.Duplex 2nd 43.Stitch Width 44.Border Erase 45.4 in 1 Layout 46.Combine Border 47.Rotate/Offset 48.Auto Rotation Appendix-8 Description Sets the paper weights and 2-sided copying to the Custom paper.
  • Page 98 System Menu Items Description 49.Silent mode Shortens the amount of time the internal motor continues to run after the copy is produced. Use this setting in cases when the motor noise is bothersome. 50.Auto Clear Sets the copier so that automatic clearing is executed after a set amount of time has elapsed after the copy is produced.

  • Page 99: System Menu

    System Menu Operation Procedures Follow the procedures listed below to operate in the System Menu. Press Exposure Adjustment keys on both sides for 3 seconds. System Menu will be displayed. Press NOTE: Each of the System Menu Items can be selected by pressing the numeric keys.
  • Page 100 Index Numerics 2 in 1 ...3-11 4 in 1 (horizontal arrangement) 4 in 1 (vertical arrangement) Additional memory Auto Clear function Auto low power function Auto Sleep Auto sleep function Auto zoom ratio selection mode Automatic Cassette Switching Function Bypass tray extension Cassette Charger cleaner rod Cleaning...
  • Page 101 Front cover Grounding the machine How to set job accounting If trouble occurs Image quality mode Interrupt Copying Job accounting Operation procedures Key counter Language setting Left cover Loading paper Loading paper into the cassette Low power mode Main power switch Maintenance Making copies in job accounting mode Multi-purpose tray...
  • Page 102 Paper jam ... 7-7 Jam location indicators ... 7-7 Precaution ... 7-7 Paper jam in the document processor Paper jam in the left cover ... 7-10 Paper jam in the multi-bypass tray Paper jam in the paper output slot Paper jam inside cassette 1 ...

  • Page 103: Index

    Index Index-4...
  • Page 104 MEMO...
  • Page 105 MEMO...
  • Page 106 MEMO...
  • Page 107 For best print results and machine performance, we recommend that you use only KYOCERA original supplies for your KYOCERA products.
  • Page 109 First Edition 2009.6...

This manual is also suitable for:

Taskalfa fs-1300dTaskalfa 180Taskalfa 220
