Aero Z and ZRA
Owner's Manual
Dealer/Supplier
This manual must be given to the user of this wheelchair
Operator (Individual or Caregiver)
Before using this wheelchair, you must read this manual
in its entirety and save it for future reference
Serial Number___________________________________________
Customer Service +1-800-545-2266

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aero Z 2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Permobil Aero Z 2 Series

Summary of Contents for Permobil Aero Z 2 Series

  • Page 1 Aero Z and ZRA Owner’s Manual Dealer/Supplier This manual must be given to the user of this wheelchair Operator (Individual or Caregiver) Before using this wheelchair, you must read this manual in its entirety and save it for future reference Serial Number___________________________________________ Customer Service +1-800-545-2266...
  • Page 2 DEPARTMENT OF TRANSPORTATION HAS NOT APPROVED ANY TIE-DOWN SYSTEM FOR TRANSPORTATION OF A USER WHILE IN A WHEELCHAIR IN A MOVING VEHICLE OF ANY TYPE. IT IS PERMOBIL MANUAL’S POSITION THAT USERS OF WHEELCHAIRS SHOULD BE TRANSFERRED INTO APPROPRIATE VEHICLE SEATING FOR TRANSPORTATION AND SHOULD USE THE RESTRAINTS MADE AVAILABLE BY THE AUTO INDUSTRY.

  • Page 3: Table Of Contents

    J. PNEUMATIC TIRES ....................1-12 K. REAR WHEEL LOCKS ....................1-13 L. PUSH HANDLES ......................1-13 M. FASTENERS ......................1-13 N. POWER DRIVE ......................1-13 O. UNAUTHORIZED PARTS AND ACCESSORIES ............1-13 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 4 (TITANIUM OR ALUMINUM) ......................4-4 Adjusting the Depth ......................4-4 BOLT-ON PUSH HANDLES ......................4-5 Mounting ..........................4-5 Removing ........................... 4-6 ADJUSTABLE HEIGHT PUSH HANDLES ..................4-6 Mounting ..........................4-6 Removing ........................... 4-7 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 5 Replacing the Upholstery ....................7-5 SEAT CUSHIONS ......................... 7-5 VELCRO -STYLE ADJUSTABLE SEAT BELT ................7-5 ® Installation .......................... 7-6 Adjustment ......................... 7-7 Safety Check ........................7-7 Maintenance ........................7-7 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 6 GLIDE FORKS ..........................11-6 Replacing Casters - Standard Forks ................11-6 Replacing Casters - Slipstream Single-Sided Forks ............11-6 Replacing the Elastomer ....................11-6 Replacing Glide Forks - Standard Sided ................11-7 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 7 SECURING THE OCCUPANT; POSITIONING THE RESTRAINT BELTS ......... 14-6 VEHICLE-ANCHORED BELTS ....................14-7 CORRECT POSITIONING OF BELTS ..................14-8 SEATING OPTIONS ........................14-11 WARRANTY MODIFICATION ....................14-11 CONFIGURATIONS TESTED CHAIRS ..................14-11 STATEMENT OF COMPLIANCE ....................14-12 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 8 All features may not be available with some device setups or in conjunction with other device features. Please consult your supplier for more information. Your authorized supplier can also provide you with information on accessories. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 9: General Warnings

    BEFORE using the chair. 3. ALWAYS have your chair completely inspected and serviced by an authorized Permobil supplier at least once a year. 4. ALWAYS perform your safety inspections and any maintenance or adjustments while the chair is unoccupied (unless this Manual expressly states otherwise).

  • Page 10: Preventing Accidents And Injuries

    WARNING 1. Riding your Permobil Manual wheelchair on wet, icy or other slick surfaces increases the risk of losing control of the wheelchair or tipping over. Use extra care if you must ride your chair on any such surface. If you have any doubt about your ability to negotiate a particular surface, ALWAYS ask for assistance.

  • Page 11: Terrain

    The additional weight could exceed the weight limit for the chair and damage the chair. If you intend to engage in weight training, Permobil Manual recommends that you utilize weight training equipment with built-in seating and that you transfer to that seating rather than using your chair.

  • Page 12: Warnings For Safe Use Of Your Wheelchair

    B. CLIMBING A FLIGHT OF STAIRS WARNING DO NOT climb a flight of stairs with the user in the wheelchair. However, Permobil Manual recognizes that wheelchair users may, on occasion, have no other choice. Only if you have no alternative, you should follow these steps to climb up a flight of stairs. 1. NEVER attempt to negotiate more than one step unless you have two (2) able-bodied adult assistants.

  • Page 13: Descending A Curb Or Single Step

    D. DESCENDING A FLIGHT OF STAIRS WARNING DO NOT descend a flight of stairs with the user in the wheelchair. However, Permobil Manual recognizes that wheelchair users may, on occasion, have no other choice. Only if you have no alternative,you should follow these steps to descend a flight of stairs. 1. NEVER attempt to negotiate more than one step unless you have two (2) able-bodied adult assistants.

  • Page 14: Transferring In And Out Of Your Wheelchair

    WARNING Most falls or tip-overs occur when you go beyond the center of gravity of you and your wheelchair. Permobil Manual wheelchairs are designed to remain stable and upright in normal daily use and activities so long as you do not exceed the center of gravity.

  • Page 15: Bending/Leaning/Reaching

    12. ALWAYS rotate the casters until they are trailing forward. This will make the chair more stable. NOTE: To get your casters to trail forward, first move your chair forward past the object you want to reach and, second, back up alongside the object. By moving backward, your casters will rotate and trail forward. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 16: Obstacles

    12. Ramps at your home and work must meet all legal requirements for your area, including building codes. If you are having a ramp installed at your home or work, ALWAYS make sure it complies with local legal requirements. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 17: Escalators

    4. even if you are an experienced rider in your Permobil Manual chair but your physical condition has changed. In order to properly use your anti-tips, please follow the following rules: 1. Your anti-tips should be between 4 cm to 5 cm off the ground when they are locked in place in the “down” position.

  • Page 18: Seat Slings/Cushions

    Permobil Manual also offers a limited number of seat cushions manufactured by other manufacturers. However, the selection of any of these products is a decision to be made by you and your doctor or therapist. Permobil Manual has NO information about your medical condition and assumes no responsibility should you choose the wrong seating system for your medical needs.

  • Page 19: Positioning Or Seat Belts

    E. POSITIONING OR SEAT BELTS WARNING Permobil Manual hook & loop, non-padded seat belts and offered third party positioning belts are optional equipment, are intended ONLY for use as a positioning aid for simple positioning needs, such as posterior pelvic tilt. These belts will not be sufficient for persons with more involved positioning needs. Only your health care advisor can determine the proper...

  • Page 20: Rear Wheels

    Stainless quick-release axles are a standard Permobil Manual wheelchair component. Other axle types are optional equipment. All Permobil Manual axles are designed to make your rear wheels easy to remove quickly. However, if not used properly, they can be dangerous.

  • Page 21: Rear Wheel Locks

    Standard rear wheel locks are available on all Permobil Manual wheelchairs as a no-charge option. Scissor locks and uni-locks are optional equipment. Permobil Manual wheel locks are NOT designed to slow or stop a moving wheelchair - they are NOT brakes.Wheel locks are ONLY designed to keep the rear wheels from rolling when your chair is at a complete stop.
  • Page 22 Permobil Aero Z & ZRA Owner’s Manual 1-14 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 23: Chapter 2: Safety Inspection, Maintenance & Troubleshooting

    CHAPTER 2: SAFETY INSPECTION, MAINTENANCE & TROUBLESHOOTING Introduction Your Permobil Manual wheelchair is designed, engineered and built to provide you with years of exceptional performance. However, proper maintenance and regular safety inspections are essential in order to make sure your wheelchair is operating properly, safely and at maximum efficiency. In addition, proper maintenance and regular safety inspections will extend the...
  • Page 24 Anti-tips • Inspect anti-tip wheel for cracks and wear √ √ • Inspect to ensure that anti-tip receiver is securely attached √ √ Frame √ √ • Inspect for cracks Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 25: Cleaning And Disinfecting

    2. Always fully inspect your chair after it has been stored for any period of time before riding in it. See the chart under “Safety Inspections and Maintenance” on pages 2-1 to 2-2. 3. If you store your chair for more than three (3) months, have your chair inspected by an authorized Permobil Manual supplier.

  • Page 26: Troubleshooting

    A calf strap or heel loop is offered as an option with each wheelchair to prevent your feet from slipping backwards off of the footrest. Permobil Manual recommends that you purchase our calf strap or our heel loops with your wheelchair.

  • Page 27: Chapter 3: Footrests

    10 cm squares of self-adhesive Safe Tread. Safe Tread provides a more slip-resistant surface than the footrest of your chair. Use of the Safe Tread is optional, but Permobil Manual recommends you use it in order to reduce the likelihood of your feet slipping off the footrest during use of your chair. If you choose to apply the Safe Tread to your footrest, follow the following instructions: 1.

  • Page 28: Replacing

    Do not detach the footrest clamps from the frame. 2. If replacing the footrest, remove the old footrest and insert the new footrest tubes through the covers and clamps and into the frame. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 29: Angle Adjustable Footrest

    2. Adjust the footrest to desired angle. 3. Tighten the Allen screws, making sure the screws and the locknuts are secure and will not permit the footplate to move up or down under weight. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 30: Adjusting The Height/Replacing

    Allen screws) are secure and will not permit the footplate to rotate up or down under weight. Figure 3-7 Figure 3-8 Angle Adjustable High Mount Footrest Angle Adjustable High Mount Footrest with Extension Tubes Allen Screws Extension Tubes Locknuts Allen Screws Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 31: Adjusting The Height/Replacing

    “Titanium Footrest (ZRA)” on pages 3-2 and 3-3 or “Titanium Footrest (Aero Z)” on page 3-3. Figure 3-10 Adjusting the Angle Footplate Footrest Extension Tube Allen Screws Stop Clamp Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 32: Buckle Adjustable Calf Strap

    ® The Adjustable Calf Strap and Padded Adjustable Calf Straps are Figure 3-12 shown in Figure 3-12. Install the calf straps as shown in Figure 3-12. Padded Adjustable Calf Strap Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 33: Chapter 4: Backrests And Push Handles

    Open End wrench. See Figure 4-2. Pivot 2. Repeat the procedure on each side of the chair until the Bolt desired tightness is achieved. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 34: Changing The Backrest Angle

    ® a locking and sealing coating, to reduce the possibility that they will become loose. You should be able to adjust the backrest height approximately four times without reapplying thread lock to these screws. Permobil requires that you reapply Vibra-TITE VC-3 after every fourth adjustment.

  • Page 35: Replacing The Backrest

    5. Install the new backrest and securely tighten the two Allen screws. 6. Install the backrest sleeves in the new backrest. 7. Reinstall the backrest posts. 8. Reinstall the backrest upholstery. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 36: Folding Adjustable Depth, Height & Angle Backrest (Titanium Or Aluminum)

    The threads on the Allen screws that secure the backrest posts to the backrest have been treated with a Vibra-TITE VC-3, ® a locking and sealing coating, to reduce the possibility that they will become loose. Permobil requires that you reapply Vibra-TITE VC-3 each time your backrest is replaced.

  • Page 37: Bolt-On Push Handles

    If you ignore this Warning, the removable parts, such as the Bolt-On Push Handles, could detach from the wheelchair causing you to fall, tip over or lose control of the wheelchair and seriously injure yourself or others or damage the wheelchair. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 38: Removing

    If you ignore this Warning, the removable parts, such as the Adjustable Height Push Handles, could detach from the wheelchair causing you to fall, tip over or lose control of the wheelchair and seriously injure yourself or others or damage the wheelchair. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 39: Removing

    Quick Release Snap Button Cam Lock Removing Tools Needed: • 5 mm Allen Wrench 1. Remove the four Allen screws. See Figure 4-12. 2. Remove the clamp and cam lock. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 40 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 41: Swing Away Armrest

    4. Make sure the locking block teeth are fully engaged with the Receiver Block teeth on the receiver, and securely tighten the nylock nuts. 5. Repeat this procedure on the other side of the chair. Nylock Nuts Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 42: Adjusting The Height

    2. While holding the release lever, lift the desk arm assembly to remove it from the desk arm mount. See Figure 5-5. Replacing Slide the desk arm housing into the desk arm mount. See Figure 5-5. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 43: Swing Away Flip-Back Armrest

    Note: The Swing Away Armrests pivot on nylon sleeves located inside the armrest receiver. If the armrest does not rotate properly, check the sleeves for wear. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 44: Adjusting The Armrest Height

    3. Reassemble the armrest stop in the desired location on the armrest upright (in 13 mm increments). 4. Securely tighten the Allen screw. 5. Reinstall the armrest in the receiver. Figure 5-7 Adjusting the Armrest Height Armrest Upright Allen Screw Washer Armrest Stop Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 45: Adjusting The Armrest Angle

    If you ignore this Warning, you could fall, tip over or lose control of the wheelchair and seriously injure yourself or others or damage the wheelchair. Figure 5-8 Adjusting the Armrest Angle Stop Clamp Allen Screw Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 46 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 47: Chapter 6: Side Guards

    Allen screws in the side guard mount. See Figure 6-2. Either type of Rigid Side Guard can be made “non-removable” by firmly tightening the two Allen screws in the side guard mount while the side guard is installed. Figure 6-2 Adjusting/Removing/Reinstalling Bracket Allen Screw Dowel Side Guard Mount Clamp Allen Screws Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 48: Removing

    5 mm Allen Wrench 1. Remove the two Allen screws that secure the two halves of the side guard clamp. See Figure 6-3. 2. Remove the Fold-Down Side Guard clamp assembly. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 49: Reinstalling

    Note: You may need to adjust the Tension Adjustable Seat Sling to gain access to the seat tube placement you desire. If this is necessary, see “Adjusting the Tension” on pages 7-3 and 7-4. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 50 You should be able to adjust the cams and/or sideguards approximately four times without reapplying the coating to these screws. If you repeatedly adjust the cams or remove the sideguard, Permobil requires that you reapply Vibra-TITE VC-3 after every fourth adjustment.

  • Page 51: Adjusting

    VC-3 after every fourth adjustment. ® If you ignore this Warning, you could fall, tip over or lose control of the wheelchair and seriously injure yourself or others or damage the wheelchair. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 52 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 53: Chapter 7: Back Upholstery, Seat Upholstery

    8. Align the top of the padded back with the two backrest ears to ensure that the top of the back upholstery is even with the top of the backrest. 9. Reinstall the strap(s) and adjust to the desired tautness. 10. Securely attach the padded back to the backrest ears and lower the back flap back into position in front of the rigidizer bar. 11. Replace the seat cushion. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 54: Tension Adjustable By Straps Back Upholstery

    4. Align the top of the padded back with the two backrest ears. 5. If desired, adjust the tension on the strap(s). 6. Securely attach the padded back to the backrest ears and lower the back flap back into position in front of the rigidizer bar. Figure 7-4 Adjusting Tension Adjustable Back Upholstery Back Flap Ear Straps Backrest Ears Strap Backrest Padded Back Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 55: Replacing

    5. Repeat Step 4 for each succeeding tension adjustable strap until you have achieved the desired tension in each strap. 6. Place the chair onto all four wheels. 7. Reattach the back upholstery to the seat upholstery and replace the seat cushion and anti-tips (if applicable). Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 56: Replacing The Upholstery

    -style material. ® 5. Retighten the Allen screws that attach the seat upholstery to the frame. 6. Reattach the back upholstery to the seat upholstery and replace the seat cushion. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 57: Replacing The Upholstery

    Velcro -Style Adjustable Seat Belt ® WARNING Installation of the Velcro -Style Seat Belt must be performed by an authorized Permobil Manual dealer or qualified ® technician. If you ignore this Warning, serious injury may result. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 58: Installation

    Installation The seat belt will be installed as shown in Figures 7-8. Figure 7-9 Figure 7-8 Proper Belt Position for Belt with D-Ring Velcro -Style Seat Belt with D-Ring ® Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 59: Adjustment

    3. Position: if too high or too low, adjust anchor points. 4. Interference with other devices: relocate anchor points as necessary. 5. Move chair through full range of motion, including folding, and rolling. Check for any interference. Maintenance Check periodically for signs of wear in the stitching and webbing. If significant wear is found, contact your supplier for qualified repair or replacement by Permobil Manual. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 60 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 61: (Center Of Gravity; Rear Seat Height)

    (CENTER OF GRAVITY; REAR SEAT HEIGHT) Permobil Aero Z and ZRA wheelchairs are equipped with a camber tube. By adjusting the position of the camber tube, you can adjust the center of gravity of your chair. This Chapter explains the various adjustments that are possible. The same adjustment will apply whether you have an aluminum, titanium or carbon fiber camber tube.

  • Page 62: Adjusting The Center Of Gravity

    5. Check the toe-in/toe-out and adjust as needed and square the casters as needed. See pages 8-3 and 8-4. Figure 8-2 Adjusting the Center of Gravity Camber Mount Clamp Allen Screws Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 63: Replacing The Camber Tube

    10. Check the toe-in/toe-out and adjust as needed and square the casters. See pages 8-3 and 8-4. Figure 8-3 Replacing the Camber Tube Camber Camber Clamp Tube Allen Screw Flats Bumper Washer Assembly Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 64: Adjusting Toe-In/Toe-Out

    22 mm Open End wrench forward to toe-in the rear wheels. Continue adjusting the camber tube until these two measurements are equal. See Figure 8-7. 13. Securely tighten the Allen screws in the camber tube mount. 14. Square the casters to the floor. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 65 Do not attempt any of the procedures in this chapter when the chair is occupied. If you ignore this Warning, you may fall, tip over or lose control of the wheelchair and seriously injure yourself or others or damage the wheelchair. Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 66 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 67: Chapter 9: Axles

    WARNING Quick-Release Axles are pre-adjusted to permit minimal “play” in the axle. Permobil Manual recommends that you do not adjust the axle. Improperly adjusting the axle could cause it to malfunction—too much “play” can cause the axle to bend and become stuck in the axle sleeve or Zero Play camber tube;...
  • Page 68 Axle Adjustment Zero Play Camber Tube Collar Locking Balls Quick-Release Nut Axle Quick-Release Handle Set Screw 1 (Locked Position) Axle Set Screw 3 Set Screw 2 Quick-Release Handle (Unlocked Position) Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 69: Adjusting The "Play

    WARNING Quick-Release Axles are pre-adjusted to permit minimal “play” in the axle. Permobil Manual recommends that you do not adjust the axle. Improperly adjusting the axle could cause it to malfunction—too much “play” can cause the axle to bend and become stuck in the axle sleeve or Zero Play camber tube;...
  • Page 70 Permobil Aero Z & ZRA Owner’s Manual OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 71: Chapter 10: Wheel Locks

    CHAPTER 10: WHEEL LOCKS WARNING Permobil Manual recommends that you remove the wheel locks from your chair frame prior to engaging in any contact sport. If you ignore this Warning, you may seriously injure yourself or others or damage the wheelchair.

  • Page 72: Replacing

    All of the adjustments set forth under “Compact Push to Lock and Compact Pull to Lock” on pages 10-1 to 10-2 apply to the Compact Push to Lock and Compact Pull to Lock Wheel Locks with Extension Handles. Permobil Aero Z & ZRA Owner’s Manual 10-2...

  • Page 73: Composite Scissor Lock

    2. Adjust the position of the wheel lock clamp on the frame so the wheel stop embeds at least 5 mm into the tire when engaged in the locked position. 3. Securely tighten the two Allen screws that secure the wheel lock clamp to the frame. Permobil Aero Z & ZRA Owner’s Manual 10-3 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 74: Replacing

    2. Remove the Socket Head Cap screw and reposition it to either the “Pull to Lock” or “Push to Lock” position, as desired. See Figure 10-7. 3. Securely tighten the Socket Head Cap screw. Permobil Aero Z & ZRA Owner’s Manual 10-4 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 75: Repositioning The Handle Of The Uni-Lock Wheel Lock

    The Uni-Lock ships with the handle in Standard Position 3. If you desire to switch to Standard Positions 1 or 2, follow the procedures below. Tools Needed: • 3 mm Allen Wrench • 8 mm Open End Wrench Permobil Aero Z & ZRA Owner’s Manual 10-5 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 76: Uni-Lock With Extension Handles

    4. Securely tighten all screws and locknuts. Uni-Lock with Extension Handles All of the adjustments set forth under “Uni-Lock” on pages 10-3 to 10-6 apply to the Uni-Lock with Extension Handles. Permobil Aero Z & ZRA Owner’s Manual 10-6 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 77: Aluminum Scissor Lock

    3. Slide the new Aluminum Scissor Lock into the wheel lock clamp, but do not tighten the two Allen screws. 4. Follow the procedure under “Aluminum Scissor Lock - Adjusting” on page 10-6 to position and secure the new Aluminum Scissor Lock. Permobil Aero Z & ZRA Owner’s Manual 10-7 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 78 Permobil Aero Z & ZRA Owner’s Manual 10-8 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 79: Chapter 11: Casters, Forks And Caster Pin Locks

    Fork. 5. Reinstall the Casters. See “Standard Forks – Replacing Axle C Spring Washer Casters” above. Allen Screw Spacer 2 Spacer 1 Caster Permobil Aero Z & ZRA Owner’s Manual 11-1 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 80: Adjusting The Front Seat Height With Standard Forks

    4. Tighten the Allen Screw through the Caster Wedges to 25 Nm using the 6 mm Socket Bit and Torque Wrench. See Figure 11-2 or 11-3. 5. Repeat steps 2 through 4 for the opposite side caster. 6. Recheck flat edge of the Forks to be certain they are perpendicular to the level surface before riding. Permobil Aero Z & ZRA Owner’s Manual 11-2 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 81 INTERPRET DRAWING DIMENSIONS SIZE: DWG. NO. REV. PER ASME Y14.5-2009 APPROX. WEIGHT (g): SCALE: SHEET THIRD ANGLE PROJECTION DIMENSIONS APPLY AFTER PLATING CAD FILE: Caster Wedge Assy 1 OF 1 Permobil Aero Z & ZRA Owner’s Manual 11-3 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 82: Slipstream Single-Sided Forks

    3. Remove the old fork and install the replacement fork on the fork stem. 4. Replace the nylock nut and washer and securely tighten. 5. Reinstall the casters. See “Slipstream Single-Sided Forks – Replacing Casters” on page 11-4. Permobil Aero Z & ZRA Owner’s Manual 11-4 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 83: Adjusting The Front Seat Height - Standard Forks

    The full range of adjustability will not be available with 13 cm or 15 cm casters. Additional adjustability may be achieved with different forks or casters or with fork stem extensions. Contact Permobil Manual Customer Service for assistance.

  • Page 84: Glide Forks

    Allen Wrench. Note: If your chair has 10 cm or 13 cm Permobil LiteSpeed casters, make sure that Spacer 2 (which is wider than Spacer 1) is positioned on the recessed side of the caster, which should be oriented outwards when the casters are in the trailing position.

  • Page 85: Replacing Glide Forks - Standard Sided

    WARNING Spacer Do not attempt any of the procedures in this chapter if the chair is occupied. If you ignore this Warning, serious injury to the occupant will occur. Permobil Aero Z & ZRA Owner’s Manual 11-7 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 86 Permobil Aero Z & ZRA Owner’s Manual 11-8 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 87: Chapter 12: Rear Wheels

    3. Insert the axle all the way into axle sleeve. 4. Lock the lever on the Quad Quick-Release Axle. 5. Pull firmly on the wheel (without unlocking the lever) to make sure the wheel is locked securely in place. Permobil Aero Z & ZRA Owner’s Manual 12-1 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 88: Handrims

    Presta Valve Presta Schrader Valve Valve Knurled Nut Solid Tires WARNING Replacement of solid tires requires specialized equipment. Therefore, if your solid tires need replacement, you must have this done by an authorized Permobil Manual dealer or qualified technician. Permobil Aero Z & ZRA Owner’s Manual 12-2 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 89: Rear Wheel Spacers

    4. Using a torque wrench, tighten the axle sleeve to 26 N-m. Figure 12-5 Adjusting the Rear Wheel Spacing Camber Plug Washer Lock Washer Camber Axle Sleeve Tube 13 mm Spacer 6 mm Spacer Permobil Aero Z & ZRA Owner’s Manual 12-3 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 90 Permobil Aero Z & ZRA Owner’s Manual 12-4 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 91: Chapter 13: Anti-Tips

    Release Button Mounting the Anti-Tip Receiver WARNING Only an authorized Permobil Manual dealer or qualified technician should install the anti-tip receiver. Note: Unless you ordered anti-tips when you originally ordered your Permobil Manual wheelchair, you will need to order replacement Allen screws when ordering your anti-tips. Tools Needed: • 4 mm Allen Wrench •...

  • Page 92: User-Friendly Anti-Tips

    CHAPTER 13: ANTI-TIPS Figure 13-2 Mounting Allen Screw Washer Nylock Nut Camber Clamp Camber Tube Receiver Allen Screw User-Friendly Anti-Tips The configuration of the User Friendly Anti-Tip is shown in Figure 13-3. Figure 13-3 Engaging the Anti-Tip Anti-Tip Mount Release Lever Receiver Permobil Aero Z & ZRA Owner’s Manual 13-2 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 93: Engaging

    Figures 13-4. Figure 13-4 Engaging Disengaging To disengage the User-Friendly Anti-Tip, grip the anti-tip receiver firmly and pull it downward, away from the anti-tip mounting plate, and raise it until it re-engages in the mounting plate in the position shown in Figure 13-5. Figure 13-5 Disengaging Permobil Aero Z & ZRA Owner’s Manual 13-3 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 94: Adjusting

    Only an authorized Permobil Manual dealer or qualified technician should install the anti-tip receiver. WARNING Do NOT disassemble the anti-tip mounting assembly (see Figure 13-7). Note: Unless you ordered User-Friendly Anti-Tips when you originally ordered your Permobil Manual wheelchair, you will need to order replacement Allen screws when ordering User-Friendly Anti-Tips. Tools Needed: •...
  • Page 95 Before sitting in the chair, make sure the anti-tips are operating properly. To do this, place the unoccupied chair on a level surface, engage the anti-tips and tip the chair backward until the anti-tips are supporting the weight of the chair. Apply sufficient pressure to ensure that the anti-tips are operating properly. Permobil Aero Z & ZRA Owner’s Manual 13-5 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 96 Permobil Aero Z & ZRA Owner’s Manual 13-6 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 97: Chapter 14: Transportation Options

    CHAPTER 14: TRANSPORTATION OPTIONS TRANSPORTATION OPTIONS The Permobil ZRA and Aero Z are available with a Transit Tie-Down Option, which is only available as a factory-installed option. The Transit Tie-Down Option, has been crash-tested in accordance and complies with RESNA WC-4:2012, Section 19 (“WC19”) and ISO 7176-19:2008 (“ISO 7176-19”).

  • Page 98: General Warnings

    WARNING Do not ride in a Permobil ZRA or Aero Z in a motor vehicle if your weight, together with the weight of all items attached to the wheelchair (such as backpacks, seat pouches, etc.) is more than the Maximum User Weight listed in Table 14-1 on page 14-11.

  • Page 99: Warnings Regarding Wtors And Proper Set-Up

    WARNING Your Permobil ZRA or Aero Z wheelchair MUST be used with WTORS that meet the requirements of SAE J2249. Do NOT use WTORS that are designed to rely on the wheelchair structure to transfer occupant restraint loads to the vehicle. Do NOT use your Permobil ZRA or Aero Z wheelchair with a WTORS unless the WTORS has been installed fully in accordance with the instructions of the manufacturer of such restraints and SAE J2249.

  • Page 100: Warnings Regarding Use Of Components And Accessories

    FMVSS201 placed between the tray or other accessory and the occupant. WARNING Do not modify or alter your wheelchair or add accessories that have not been authorized by Permobil. Do not make alterations or substitutions to the wheelchair securement points or to structural or frame parts or components. Any significant modification or substitution to the wheelchair’s securement points, structural or frame parts or components could significantly alter the chair’s performance during a collision.

  • Page 101: Securing The Wheelchair To The Vehicle

    The two rear Tie-Down Brackets (see Figure 14-3) may be removed ONLY if it is necessary to adjust the seat depth and an authorized Permobil dealer must ALWAYS perform such adjustment. If such an adjustment is made, the bolts and nuts that originally shipped with your wheelchair must ALWAYS be used.

  • Page 102: Securing The Occupant; Positioning The Restraint Belts

    SAE J2249 must be used to secure the occupant within the wheelchair. WARNING The Permobil ZRA and Aero Z wheelchairs with the Transit Tie-Down Option are intended for use by adults and children weighing 52 lbs. (23 kg) or more.

  • Page 103: Vehicle-Anchored Belts

    VEHICLE-ANCHORED BELTS In accordance with WC19 Annex C, the Permobil ZRA and Aero Z were evaluated with regard to lateral stability. The test for lateral stability is shown in Figure 14-7 below. The average test results for point “P” were as follows: •...

  • Page 104: Correct Positioning Of Belts

    25-mm high block 45° REAR VIEW In accordance with WC19 Annex E, the Permobil ZRA and Aero Z were evaluated with regard to the ability to accommodate vehicle-anchored pelvic and shoulder belts: • The Permobil ZRA received a rating of “Good” with respect to the ease of optimizing proper pelvic belt placement and an overall score of “Excellent”...
  • Page 105 Permobil Aero Z & ZRA Owner’s Manual 14-9 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 106 Figure 14-10 Illustration of Improper Belt-Restraint Fit Belt restraints must not be held away from the body by wheelchair components such as armrests or wheels. Permobil Aero Z & ZRA Owner’s Manual 14-10 OM0004-ENGLISH_Rev E_Aero Z_ZRA...

  • Page 107: Seating Options

    RESNA WC-4: 2012, Section 20. WARRANTY MODIFICATION A copy of the Permobil Limited Warranty was enclosed with your new wheelchair when it was shipped from our factory. Our warranty is also available on our website, www.Permobil.com. That Limited Warranty applies to your Permobil wheelchair with the Transit Tie-Down Option, with the following modification: The warranty is void if the wheelchair is involved in a collision or is otherwise damaged as a result of transit use.

  • Page 108: Statement Of Compliance

    CHAPTER 14: TRANSPORTATION OPTIONS STATEMENT OF COMPLIANCE Permobil ZRA and Aero Z wheelchairs equipped with the Transit Tie-Down Option conform to the requirements of WC19. Specifically, they have been tested in accordance with Section 5.3 (Frontal Impact), Section 5.4 (Clear Paths for Four-Point, Strap-Type Tie-Downs), Section 5.5 (Lateral Stability) and Section 5.7 (Accommodation of Vehicle-Anchored Three-point Belt Restraints).
  • Page 109 Permobil Aero Z & ZRA Owner’s Manual 14-13 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 110 Permobil Aero Z & ZRA Owner’s Manual 14-14 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
  • Page 111 Permobil Aero Z & ZRA Owner’s Manual 14-15 OM0004-ENGLISH_Rev E_Aero Z_ZRA...
