OWNER´S MANUAL
US
Koala
Power Wheelchair

Advertisement

Table of Contents
loading

Related Manuals for Permobil Koala

Summary of Contents for Permobil Koala

  • Page 1 OWNER´S MANUAL Koala Power Wheelchair...
  • Page 3 6961 Eastgate Blvd. Lebanon, TN 37090 Phone: 800-736-0925 Fax: 800-231-3256 Email: info@permobilusa.com Head Office of the Permobil group Permobil AB Box 120 861 23 Timrå Sweden Tel: +46 60 59 59 00 Fax: +46 60 57 52 50 E-mail: info@permobil.se...
  • Page 4 Koala Power Wheelchair Produced and published by Permobil AB, Sweden Version no.: 5 - 2009-03 Art. no.: 201182-US-0...

  • Page 5: Table Of Contents

    Owner´s manual Koala Contents Contents Important information about the owner´s manual ..6 General information ....... . . 7 Technical support .

  • Page 6: Important Information About The Owner´s Manual

    It is also possible to obtain information concerning our products from our home page on the Internet. You can find us at www.permobil.com. All information, pictures, illustrations and specifications are based upon the product information that was available at the time that these operating instruc- tions were printed.

  • Page 7: General Information

    Owner´s manual Koala Technical support, warranty, etc. TECHNICAL SUPPORT In the event of technical problems, you should contact your dealer or Permobil Inc USA at 1-800-736-0925. Always state the chassis serial number when contacting Permobil to ensure that the correct information is provided.

  • Page 8: Safety Rules

    Permobil is not responsible for personal injuries or property damage resulting from any person’s failure to follow the warnings and instructions in this manual. Permobil is not responsible for injuries or damage resulting from failure to exer- cise good judgment.
  • Page 9 • that all products ordered are included in the delivery, incuding operating instructions and possible other documentation. If you suspect that something is missing, then contact your supplier or Permobil for more information as soon as possible. • that no transport-related or other damages have occurred to the wheelchair and its accessories.

  • Page 10: Safety Instructions

    Safety Instructions WARNING Operation Permobil recommends the use of wheelchair lights at all times user is riding near public rights of way. Use extreme caution when driving near unprotected ledges, drop-offs or on elevated surfaces. Unintended movement or excessive speed in these areas can lead to personal injury or property damage.
  • Page 11 Permobil products. Weight Limitations The maximum user weight for your Permobil is set forth in the specification section of the supplied Owner´s Manual for current seat model. Operation of the wheelchair by users who exceed the maximum allowable user weight can lead to personal injury and property damage, including damage to the wheel- chair, as well as voiding any applicable warranty to the wheelchair.
  • Page 12 Owner´s manual Koala Safety instructions Safety Instructions NOTE Operation - Inclines When driving downhill, select the slowest speed and proceed with caution. Driving down an incline in a front wheel drive wheelchair can shift the user’s center of gravity forward. If the wheelchair rolls faster than you would like, stop the wheelchair by releasing the joystick and begin descending again at a slower speed.
  • Page 13 Owner´s manual Koala Safety instructions Safety Instructions WARNING Operation - Inclines Do not drive the wheelchair where the sideways gradient is more than indicated in the technical specifications section of the manual. There is a risk of tipping over. Do not drive up or down ramps that are not equipped with proper edge protection along the sides of the ramp to prevent the wheelchair from falling off of the ramp.
  • Page 14 In order to prevent the wheelchair from rolling away, ensure that the wheelchair is on a level and dry surface before releasing the brakes. In order to avoid personal injury do not use your Permobil in freewheel mode without an attendant present. Do not attempt to put the wheelchair in freewheel mode by yourself while seated in it.
  • Page 15 Driving in Extreme Climate Conditions Permobil's wheelchairs are designed to withstand most adverse weather con- ditions, however to minimize the risk of being caught in difficult situations you should avoid using the wheelchair outdoors during, for example, severe cold, heavy rain or thick snow.
  • Page 16 Owner´s manual Koala Safety instructions Safety Instructions WARNING Driving with Seat Lift/Seat Tilt/Backrest Recline Be careful in making sure that nothing gets stuck between the chassis and the seat when the seat lift/seat tilt is operated. Operating the seat lift,seat tilt/ back- rest recline changes the center of gravity and increases the risk of tipping over.
  • Page 17 Safety Instructions WARNING Positioning Belt Permobil positioning belts are designed to position the user only and will not protect you in an accident. You may even receive further injury from the belts. Support Wheels If your wheelchair is equipped with support wheels, they must always be mounted when the wheelchair is being driven.
  • Page 18 Owner´s manual Koala Safety instructions Safety Instructions WARNING Passengers The wheelchair is not intended to transport passengers, regardless of the age of the passenger. The Maximum User Weight stated in the Owner's Manual for your seating includes the user and any personal effects. The Maximum limit should not be exceeded.
  • Page 19 Use Prohibited in Motor Vehicles Permobil recommends that users NOT be transported in any kind of vehicle while in their wheelchair, unless the user is in an approved Permobil wheelchair configuration, has secured the wheelchair using a Permolock C, and is using a seatbelt attached to the vehicle.
  • Page 20 Failure to do so can lead to personal injury. Do not use parts or accessories not authorized by Permobil. Use of unap- proved ”aftermarket” accessories and parts may cause changes in the wheel- chair, which may make the wheelchair unstable or uncontrollable.
  • Page 21 Safety Instructions WARNING Safety Circuits Permobil products are equipped with safety circuits. Inhibit circuits prevent the wheelchair from driving under certain conditions. Speed reduction circuits limit the wheelchair’s maximum speed under certain conditions. Limit switch circuits limit the wheelchair’s functions under certain circumstances. Overload protec- tion circuits shut the wheelchair off in case of an overload.
  • Page 22 Permobil and tighten the bolt to the recommended torque. Also, inspect the drive axle and wheel rim for any damage. Damage to either part can cause the wheel bolt to loosen or fracture. Permobil recommends that wheel bolts be used only one time.
  • Page 23 The limit values for Electromagnetic Compatibility (EMC) with respect to elec- trical wheelchairs is set in the harmonized standards for the EU in the Medical Devices Directive, No. 93/42/EEC. Permobil's electronic wheelchair’s comply with these limit values. Also see Important Information about Electromagnetic Interference (EMI) on page 56-57.

  • Page 24: Design And Function

    Owner´s manual Koala Design and Function Design and Function General 1. Seat 5. Control panel 2. Chassis 6. Battery cover 3. Rear wheel 7. Chassis cover 4. Drive wheel Fig.1. Koala. -24-...

  • Page 25: Seat

    See enclosed seat instructions. Seat lift/seat adjustment Koala is fitted with an electrically controlled seat lift. A position adjuster operated from the control panel allows continuous adjustment of the seat to any height between 15-24 inches, permitting simple matching with table, seat heights etc.

  • Page 26: Wheels

    Owner´s manual Koala Design and Function 1. Position adjuster 2. Safety switch Fig. 3 Seat lift. Wheels The front wheels of the wheelchair, the drive wheels, have pneumatic tires. The swivel-mounted rear wheels have solid rubber tires. Reflectors The standard wheelchair has no lighting but is fitted with reflectors.

  • Page 27: Electrical System

    Owner´s manual Koala Design and Function Electrical system The wheelchair batteries are situated under the battery cover in the center of the chassis. The batteries are maintenance-free (gel-type), so there is no need to check fluid levels. Fig. 5. Batteries.

  • Page 28: Charging Fuse

    Owner´s manual Koala Design and Function Main circuit-breaker You can reset the main circuit-breaker if it trips. It is on the underside of the chassis, over the right, rear wheel, see fig. 7. The main circuit-breaker is protected from dirt and water by a rubber flap, which you can easily fold back.

  • Page 29: Control Panel

    You can also have a seat control panel fitted to your wheelchair. You can then choose whether you want to adjust the electrical seat functions from the seat control panel. Fig. 8. Control panel Koala Fig. 9. Adjusting the control panel. A. Sideways adjustment 1.
  • Page 30 Owner´s manual Koala Design and Function Security key The security key can be used to lock the wheelchair to prevent unauthorized use. To lock the wheelchair it must be switched on, the key should then be inserted into and withdrawn from the panel outlet, the wheelchair will now be locked.
  • Page 31 Owner´s manual Koala Design and Function Battery voltage indicator The window display on the control panel (fig.13) shows the following indicator lights (from bottom to top) : Red+Yellow+Green = Fully charged Red+Yellow = Half charged = Charge the batteries Fig.13. Battery voltage indicator...
  • Page 32 Owner´s manual Koala Design and Function Lights Lights Press the switch to turn on the lights Indicators of the wheelchair. Indicators Pressing the right or left arrow acti- vates the chair’s indicators. Fig.16. Light/indicator switches Warning horn Press the button to sound the horn and attract attention.
  • Page 33 Owner´s manual Koala Design and Function Leverman (Joystick manager) With the help of the Leverman, you can use the joystick to control the speed of the chair (5 positions), and the seat lift. Operating the Leverman 1. Switch the start button on the control panel to ”on”.

  • Page 34: Seat Control Panel

    Owner´s manual Koala Design and Function Seat control panel The seat control panel is attached to the right or left-hand armrest behind the control panel. The picture below show the function of the seat control panel. Seat lift, fig. 20:1...
  • Page 35 Owner´s manual Koala Design and Function Joystick The joystick is used to regulate the speed of the wheelchair forwards or back- wards, to turn and to brake. Speed The speed is regulated proportionally by moving the joystick forwards or back- wards.
  • Page 36 Owner´s manual Koala Design and Function Turning and braking The wheelchair is turned by moving the joystick to the left or right. The wheelchair is braked by moving the joystick back to the neutral position or letting it go. Fig 22. Turning speed...

  • Page 37: Accessories

    Accessories Accessories We are constantly developing accessories for our wheelchairs. Contact your nearest Permobil retailer for more information about the accessories available for your wheelchair. Tool bag The wheelchair is supplied with a tool bag which contains the following tools.

  • Page 38: Handling

    Owner´s manual Koala Handling Handling General This wheelchair is designed for use both inside and outside. When driving inside, take normal care. Outside you must remember to drive very slowly on steep downhill slopes and not to drive over curbs and other obstacles higher than 2.5 inches.
  • Page 39 Owner´s manual Koala Handling 2. Set a suitable speed range by first pressing the MODE button and then use the joystick to select the speed, until the desired indicator lamp comes on for your type of driving. Increase speed = Step to the right.
  • Page 40 Owner´s manual Koala Handling 4. The speed of the wheelchair is regulated proportionally by moving the joy stick forwards or backwards to different extents. The wheelchair's electronics make it possible to move slowly over curbs and other obstacles. You can drive up to the curb or obstacle and then carefully drive over it.

  • Page 41: Releasing The Brakes

    Owner´s manual Koala Handling Releasing the brakes In order to avoid the wheelchair rolling away, ensure that the wheelchair is on a level and dry base before releasing the brakes. The brakes can be released to make it possible to move the wheelchair manually.

  • Page 42: Driving Rules

    Owner´s manual Koala Handling Driving rules High curbs and other obstacles Do not drive the wheelchair over curbs and other obstacles higher Max 2.5 inches than 2.5 inches. Fig. 29. High curbs and other obstacles Downhill slopes When driving downhill, select the slo- west speed and proceed with caution.
  • Page 43 Owner´s manual Koala Handling Driving up hill If you drive up slopes steeper than , there is a risk that the wheelchair cannot be maneuvered safely. Do not drive up slopes steeper than 10 degrees. Max 10° Fig. 31. Driving up hill...

  • Page 44: Charging The Batteries

    Owner´s manual Koala Handling Charging the batteries The batteries must be charged in a well-ventilated room, not in a closet. Do not charge the batteries in a bathroom or wet room. Take care when using metal objects in connection with work on the batte- ries.
  • Page 45 Owner´s manual Koala Handling When should the batteries be charged? As a general rule, you should recharge your batteries as frequently as possible to assure the longest possible life and to minimize the required charging time. Plan to recharge them when you do not anticipate using the chair for a long period of time.

  • Page 46: Transport

    Transport We recommend that Permobil wheelchairs are transported tied down at all times. The Permobil can be locked in place with loading belts attached to the supplied tie-down points on the front panel and at the side by the bumper.

  • Page 47: Transporting By Air

    Owner´s manual Koala Transport Air transport When transporting your chair by air, you should be aware of three things above all: the batteries, the dimensions and weight of the wheelchair and that the seat can be damaged when handled, as it is placed together with luggage and other goods in a narrow space.

  • Page 48: Maintenance And Repairs

    Owner´s manual Koala Maintenance Maintenance Before working on the wheelchair's electrical system the connection to the negative pole of the battery must always be removed. Be careful with any metal objects when working on the battery. A short circuit could easily cause an explosion. Always wear safety gloves and goggles.
  • Page 49 NB! The temperature in the place of storage must not fall below 41 degrees f. The Permobil Koala has maintenance-free gel-type batteries. This means there is no need to check fluid levels. Battery life depends entirely on regular charging.

  • Page 50: Repairs

    Owner´s manual Koala Repairs Repairs Resetting the main fuse/battery cut-out The main fuse also functions as a battery cut-out but is still referred to as the main fuse in the user instruction. NB! First switch off the power on the maneuvering panel before switching the power off at the circuit breaker.
  • Page 51 Owner´s manual Koala Repairs Raising/lowering the seat manually 1. When you are raising the seat, remove the cushion and screw out the three screws that holds the seat, when lowering, go straight to point 2. 2. Remove the screw that holds the positioning-motor cylinder bar in the seat lift, see fig.
  • Page 52 Owner´s manual Koala Repairs Changing batteries 1. Place the wheelchair on a level base.. 2. Raise the seat lift to its full height. 3. Switch off the main switch. 4. Loosen the battery cover and disengage the terminal protection connector.

  • Page 53: Changing An Inner Tube

    Owner´s manual Koala Repairs Changing an inner tube 1. Set up the wheelchair on blocks and let out the air. 2. Lever the tire out of the rim. 3. Replace the defective inner tube. 4. Replace the tire on the rim and reinflate.

  • Page 54: Technical Specifications

    Owner´s manual Koala Specification Data General Name ........... Koala Size and weight Length..........39" Width............ 22" Seat height .......... 15"-24" Smallest transport size, lxwxh ..... 28" x 22" x 26" Weight incl. batteries......203 lbs(incl.Miniflex-seat.) Maximum weight of user ..... See user manual for accompanying seat.

  • Page 55: Important Information (Only For The Us Market)

    Owner´s manual Koala Important information Electrical system Electronics PM80 Pilot+ Control panel JSM-L 7key Pilot+ Batteries Recommended battery type ....M40-12 SLD G Battery capacity ........2 x 38Ah Charging time ........8 hours Fuses Charging fuse ........15A Main fuse ..........63A...
  • Page 56 Owner´s manual Koala Important information CAUTION! It is very important that you read this information regarding the possible effects of electromagnetic interference on your powered wheelchair. Electromagnetic Interference (EMI) From Radio Wave Sources Powered wheelchairs and motorized scooters (in this text, both will be referred...
  • Page 57 Owner´s manual Koala Important information Long-range transmitters and transceivers, such as commercial broadcast transmitter (radio and TV broadcast antenna tower) and amateur (HAM) radios. NOTE! Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, and casette players, and small appliances, such as electric shavers and hair dryers, so far we know, are not likely to cause EMI problems to your powered wheelchair.
