GOX-2402M-PGE
GOX-3201M-PGE
GOX-5103M-PGE
GOX-8901M-PGE
GOX-12401M-PGE
Thank you for purchasing this product.
Be sure to read this documentation before use.
This documentation includes important safety precautions and instructions on how to operate the unit. Be sure to read this documentation to ensure
proper operation.
The contents of this documentation are subject to change without notice for the purpose of improvement.
© 2023 JAI
GOX-2402C-PGE
GOX-3201C-PGE
GOX-5103C-PGE
GOX-8901C-PGE
GOX-12401C-PGE
CMOS Digital Progressive Scan
Monochrome and Color Camera with GigE Interface
Document Version: 1.5
Date: 2023-12-01
Advertisement
Table of Contents
Related Manuals for JAI GOX-2402M-PGE
Summary of Contents for JAI GOX-2402M-PGE
- Page 1 This documentation includes important safety precautions and instructions on how to operate the unit. Be sure to read this documentation to ensure proper operation. The contents of this documentation are subject to change without notice for the purpose of improvement. © 2023 JAI...
-
Page 2: Table Of Contents
User Manual (Ver. 1.5) - Table of Contents GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Table of Contents Table of Contents About Technical Note Notice/Warranty Notice Warranty Certifications CE Compliance Warning China RoHS Usage Precautions Notes on Cable Configurations Notes on LAN Cable Connection Notes on Attaching the Lens Phenomena Specific to CMOS Image Sensors... - Page 3 User Manual (Ver. 1.5) - Table of Contents GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Preparation Step 1: Install the Software (First Time Only) Step 2: Connect Devices ① Lens ② Mounting (or Use MP-43 Tripod Adapter Plate) ③ LAN Cable ➃...
- Page 4 User Manual (Ver. 1.5) - Table of Contents GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Timing Chart Exposure Mode = Timed GOX-2402MC-PGE GOX-3201MC-PGE GOX-5103MC-PGE GOX-8901MC-PGE GOX-12401MC-PGE Exposure Mode = TriggerWidth (Overlap Readout) GOX-2402MC-PGE GOX-3201MC-PGE GOX-5103MC-PGE GOX-8901MC-PGE GOX-12401MC-PGE Gain Control Automatic Gain Level Control White Balance Color Temperature...
- Page 5 User Manual (Ver. 1.5) - Table of Contents GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Single ROI - Example Pulse Generator Sequencer Function TriggerSequencer Mode Sample TriggerSequencer Mode Operation CommandSequencer Mode Counter and Timer Control Function Counter Occurrence Diagram Internal Camera Blocks To Use the Counter Function Chunk Data Function...
-
Page 6: About Technical Note
Revision History About Technical Note Some additional technical information is provided on the JAI website as Technical Notes. In this manual, if a technical note is available for a particular topic, the above icon is shown. Please refer to the following URL for Technical notes. -
Page 7: Notice/Warranty
The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan, and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein. -
Page 8: Warning
기자재명칭: Industrial Camera 기자재명칭: Industrial Camera 모 델 명: GOX-2402M-PGE 모 델 명: GOX-2402C-PGE 제조자 및 제조국가: JAI Ltd., Japan / JAPAN 제조자 및 제조국가: JAI Ltd., Japan / JAPAN R-R-JAi-GOX-12401C-PGE R-R-JAi-GOX-12401C-PGE 상 호: JAI Ltd. Japan 상 호: JAI Ltd. Japan 기자재명칭:... - Page 9 JAI Ltd. Japan 기자재명칭: Industrial Camera 기자재명칭: Industrial Camera 모 델 명: GOX-12401M-PGE 모 델 명: GOX-12401C-PGE 제조자 및 제조국가: JAI Ltd., Japan / JAPAN 제조자 및 제조국가: JAI Ltd., Japan / JAPAN R-R-JAi-GOX-12401C-PGE R-R-JAi-GOX-12401C-PGE 제조년월은 제품상자의 라벨을 참조하십시오. - 9 -...
-
Page 10: China Rohs
User Manual (Ver. 1.5) - Notice/Warranty GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE China RoHS The following statement is related to the regulation on “Measures for the Administration of the Control of Pollution by Electronic Information Products “, known as “China RoHS“. The table shows contained Hazardous Substances in this camera. -
Page 11: Usage Precautions
User Manual (Ver. 1.5) - Usage Precautions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Usage Precautions Notes on Cable Configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. Notes on LAN Cable Connection Secure the locking screws on the connector manually, and do not use a driver. -
Page 12: Phenomena Specific To Cmos Image Sensors
User Manual (Ver. 1.5) - Usage Precautions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Phenomena Specific to CMOS Image Sensors The following phenomena are known to occur on cameras equipped with CMOS image sensors. These do not indicate malfunctions. Aliasing: When shooting straight lines, stripes, and similar patterns, vertical aliasing (zigzag distortion) may appear on the monitor. -
Page 13: Features
ROI, binning, etc. Model Name Image Sensor Active Pixels Pixel Size Max Frame Rate GOX-2402M-PGE Mono GOX-2402M-PGE-CS Type 1/2.3 1920 x 1200 3.45 μm x 3.45 μm 49.9 fps... -
Page 14: Feature Overview
User Manual (Ver. 1.5) - Features GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Feature Overview Compliance with GigE Vision Ver.2.0 and GenICam standards Global Shutter high resolution CMOS sensor Lens mount: C-mount, CS-mount 8/10/12-bit output in choice of monochrome or raw Bayer color models. ROI settings for added flexibility Horizontal/vertical image flip function, plus blemish correction and shading compensation Sequencer function and Automatic Level Control (ALC) for dynamic lighting conditions... -
Page 15: Parts Identification
User Manual (Ver. 1.5) - Parts Identification GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Parts Identification Note: Above is an external view of the C-mount model; for an external view of the CS-mount model, see the CS-Mount Model page. -
Page 16: ③ Power/Trig Led
User Manual (Ver. 1.5) - Parts Identification GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ③ POWER/TRIG LED Indicates the power or trigger input status. Status Lit amber Camera initializing Lit green Camera in operation During operation in trigger mode, trigger signals are being input. Blinking Note: The blinking interval is not related to the actual input interval of the external green... -
Page 17: ⑥ Dc In/Trig Connector (6-Pin Round)
User Manual (Ver. 1.5) - Parts Identification GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ⑥ DC IN/TRIG Connector (6-Pin Round) Connect the cable for a power supply (optional) or for DC IN / trigger IN here. Camera Side: HR10A-7R-6PB (Hirose Electric or equivalent) Cable Side: HR10A-7P-6S (Plug) (Hirose Electric or equivalent) Pin No. -
Page 18: Recommended Circuit Diagram (Reference Examples)
User Manual (Ver. 1.5) - Parts Identification GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Recommended Circuit Diagram (Reference Examples) Related Setting Items: DigitalIOControl OPTO-In Circuit Characteristics Recommended External Input Circuit Diagram Recommended External Output Circuit Diagram (Reference Example) - 18 -... -
Page 19: Characteristics Of The Recommended Circuits For Opto Out
User Manual (Ver. 1.5) - Parts Identification GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Characteristics of the Recommended Circuits for Opto OUT OUTPUT LINE RESPONSE TIME For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below. -
Page 20: Preparation
Read this section to learn how the camera connects to devices and accessories. The preparation process is described below. Step 1: Install the Software (First Time Only) Install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. Step 2: Connect Devices Verify whether the camera is turned on and ready for use. -
Page 21: Step 1: Install The Software (First Time Only)
When using the camera for the first time, install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. Note: When you install eBUS SDK for JAI, eBUS Player for JAI will also be installed. 1. Download the eBUS SDK for JAI from the JAI website (https://www.jai.com/support-software/jai-... -
Page 22: ① Lens
Note: If using a C-mount lens on the CS-mount model, use a 5mm lens adapter ring. To prevent vignetting and to obtain the optimal resolution, use a lens that will cover the image sensor size. Model Name Image Sensor GOX-2402M-PGE Mono GOX-2402M-PGE-CS Type1/2.3 6.62 mm x 4.14 mm (7.81 mm diagonal) -
Page 23: ② Mounting (Or Use Mp-43 Tripod Adapter Plate)
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Model Name Image Sensor GOX-5103M-PGE Mono GOX-5103M-PGE-CS Type2/3 8.45 mm x 7.07 mm (11.01 mm diagonal) GOX-5103C-PGE Color GOX-5103C-PGE-CS GOX-8901M-PGE Mono Type1 14.13 mm x 7.45 mm (15.97 mm diagonal) GOX-8901C-PGE Color GOX-12401M-PGE... -
Page 24: ③ Lan Cable
When supplying power via PoE, connect to a PoE-compatible switching hub or a PoE- compatible network card. Note: JAI does not recommend using a PoE injector. If a PoE injector is used, the camera may not be able to transmit images properly. -
Page 25: Step 3: Verify Camera Operation
③ POWER/TRIG LED section. Step 4: Verify the Connection between the Camera and PC Verify whether the camera is properly recognized via Control Tool. 1. Launch eBUS Player for JAI eBUS Player for JAI startup screen appears. - 25 -... - Page 26 User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE 2. Select the camera you want to configure. Click the Select / Connect button. 3. The connected camera is listed. Please select one camera and click OK. - 26 -...
- Page 27 User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE 4. Check that the settings of the selected camera are displayed. 5. Click the Device control button. The screen shown below will be displayed. In this window, you can adjust various settings of the camera.
-
Page 28: Step 5: Change The Camera Settings
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Step 5: Change the Camera Settings This section explains how to change settings by describing the procedure for changing the output format as an example. Configure the Output Format Configure the size, position, and pixel format of the images to be acquired. -
Page 29: Step 6: Adjust The Image Quality
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Step 6: Adjust the Image Quality Related Setting Items: AnalogControl Display the camera image and adjust the image quality. Display the Image Display the image captured by the camera. When you click the Play button, the camera image appears in the right area. -
Page 30: Adjust The Gain
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Adjust the Gain Adjust the image quality using the gain and white balance functions. The Visibility must be changed from Beginner to Guru. Note: For details on the Gain control, see Gain Control in the Main Functions chapter. -
Page 31: Adjust The White Balance
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Adjust the White Balance Adjust the white balance using the automatic adjustment function. Note: The white balance is only supported on color models. Automatic White Balance Adjustment 1. -
Page 32: Adjust The Black Level
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Adjust the Black Level 1. Expand AnalogControl, and select the black level you want to configure in BlackLevelSelector. All (master black), Red* (digital R), and Blue* (digital B) can be configured. Note: *Color models only. -
Page 33: Step 7: Save The Settings
Related Setting Items: UserSetControl The setting values configured in eBUS SDK for JAI will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary. You can save up to three sets of user settings in the camera. (User Set1 to 3) Notes: Changes to settings are not saved to the computer (eBUS SDK for JAI). -
Page 34: To Save User Settings
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE To Save User Settings 1. Stop image acquisition. 2. Expand UserSetControl and select the save destination (UserSet1 to UserSet3) in UserSetSelector. Note: The factory default setting values are stored in Default and cannot be overwritten. Caution: Settings can only be saved when image acquisition on the camera is stopped. -
Page 35: To Load User Settings
User Manual (Ver. 1.5) - Preparation GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE To Load User Settings 1. Stop image acquisition. User settings can only be loaded when image capture on the camera is stopped. 2. Select the settings to load (UserSet1 to UserSet3) in UserSetSelector. 3. -
Page 36: Main Functions
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Main Functions This chapter describes the camera's main functions. Acquisition Control Related Setting Items: AcquisitionControl This camera has three Acquisition modes (SingleFrame, MultiFrame, Continuous). Use the AcquisitionControl settings to perform operations and settings for image capture. -
Page 37: Changing The Frame Rate
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Changing the Frame Rate When TriggerMode is disabled, you can change the frame rate in AcquisitionFrameRate. Notes: The shortest frame period varies depending on the ROI, pixel format, and binning mode selected. -
Page 38: Actual Exposure Time
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Actual Exposure Time Related Setting Items: AcquisitionControl The actual exposure time will consist of the image sensor’s offset duration (refer to the table below) added to the setting configured on the camera. -
Page 39: Trigger Control
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Trigger Control Related Setting Items: AcquisitionControl The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. AcquisitionEnd Stop image acquisition in response to the external trigger signal input. -
Page 40: When Using The Framestart Trigger
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE When Using the FrameStart Trigger When AcquisitionStart is executed and a FrameStart trigger is received before the AcquisitionStop command is executed, one frame is acquired. The source signals that can be set for the AcquisitionStart, AcquisitionEnd, FrameStart, and AcquisitionTransferStart triggers are as follows: Software, PulseGenerator 0, UserOutput 0 ~ 3, Action 1 ~ 2, Line5 Opt In 1, NAND0 Out, and... -
Page 41: Pixel Format
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Pixel Format Related Setting Items: ImageFormatControl Pixel Format Alignments for GigE Vision Selectable PixelFormat is as follows. BayerRG8 (default), BayerRG10, BayerRG10Packed, BayerRG12, BayerRG12Packed, BayerGR8*, BayerGR10*, BayerGR10Packed*, BayerGR12*, BayerGR12Packed*, BayerGB8*, BayerGB10*, BayerGB10Packed*, BayerGB12*, BayerGB12Packed*, Color models BayerBG8*, BayerBG10*, BayerBG10Packed*, BayerBG12*, BayerBG12Packed*... -
Page 42: Image Flip Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Image Flip Function Related Setting Items: ImageFormatControl Using this function, you can output the image by inverting it horizontally and/or vertically. In the ImageFormatControl settings, To reverse the image horizontally, set ReverseX to True. -
Page 43: Gpio (Digital Input/Output Settings)
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GPIO (Digital Input/Output Settings) Related Setting Items: DigitalIOControl The camera can input/output the following signals to and from external input/output connectors. External Output Line2 : Opt Out DC IN / TRIG IN Connector (6-pin round) Internal Output Line5 : Opt In... -
Page 44: Videoprocessbypassmode
When bypass is enabled, the sensor output and camera output data can be set to the same bit depth. When in 12-bit Pixel Format, VideoProcessBypassMode is forced to On. Functions Available in VideoProcessBypassMode Gain[AnalogAll], BlemishCompensation GOX-2402M-PGE: BinningHorizontal/BinningVertical. For more information, see Binning Function. - 44 -... -
Page 45: Calculate The Maximum Frame Rate (Approximate)
(Number of pixels and number of lines before Binning). In GOX-2402M-PGE, 2x2 binning is processed on the image sensor. Therefore, the maximum sensor frame rate can be increased. In this case, for the values of Width-S and Height-S, specify the number of pixels and the number of lines after Binning. - Page 46 21.738 GOX-12401MC-PGE 21.738 Note: *In GOX-2402M-PGE, 2x2 binning is processed on the image sensor. Therefore, the maximum sensor frame rate can be increased. When the 2x2 binning is used, the value of HMAX_ Period is 5.98 instead of 10.586. During Continuous operation (Frame Start trigger is Off)
-
Page 47: Timing Chart
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Timing Chart Related Setting Items: AcquisitionControl This section shows the timing charts under the following conditions on each model when FrameStartTriger is set to On. Exposure Mode = Timed This section shows the timing charts when FrameStartTrigger is set to On. -
Page 48: Gox-2402Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-2402MC-PGE Period From Trigger start edge to PixelFormat Frame Period [A] (usec) Exposure start [B] (usec) Binning Off Mono8 20080 32.8 Mono10/Mono12 40161 62.4 Mono10Packed/Mono12Packed 30121 62.4... -
Page 49: Gox-3201Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-3201MC-PGE Period From Trigger start edge to PixelFormat Frame Period [A] (usec) Exposure start [B] (usec) Binning Off Mono8 27397 35.2 Mono10/Mono12 54945 66.5 Mono10Packed/Mono12Packed 41153 66.6... -
Page 50: Gox-5103Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-5103MC-PGE Period From Trigger start edge to PixelFormat Frame Period [A] (usec) Exposure start [B] (usec) Binning Off Mono8 43669 41.2 Mono10/Mono12 87720 79.2 Mono10Packed/Mono12Packed 65790 79.4... -
Page 51: Gox-8901Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-8901MC-PGE Period From Trigger start edge to PixelFormat Frame Period [A] (usec) Exposure start [B] (usec) Binning Off Mono8 77520 66.2 Mono10/Mono12 156251 Mono10Packed/Mono12Packed 116280 132.1 Bayer8... -
Page 52: Gox-12401Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-12401MC-PGE Period From Trigger start edge to PixelFormat Frame Period [A] (usec) Exposure start [B] (usec) Binning Off Mono8 107528 66.1 Mono10/Mono12 217393 Mono10Packed/Mono12Packed 161.291 Bayer8 107528... -
Page 53: Exposure Mode = Triggerwidth (Overlap Readout)
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Exposure Mode = TriggerWidth (Overlap Readout) This section shows the timing charts when FrameStartTrigger is set to On, and ExposureMode is set to TriggerWidth (Overlap Readout). Frame Period [A] (usec) Period From Trigger start edge to Exposure start [B] (usec) Period From Trigger end to Exposure end [C] (usec) -
Page 54: Gox-2402Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-2402MC-PGE Period From Period From Period From Frame Period [A] Trigger start edge Trigger end to Exposure end to PixelFormat (usec) to Exposure start Exposure end [C] next Trigger start [B] (usec) -
Page 55: Gox-3201Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-3201MC-PGE Period From Period From Period From Frame Period [A] Trigger start edge Trigger end to Exposure end to PixelFormat (usec) to Exposure start Exposure end [C] next Trigger start [B] (usec) -
Page 56: Gox-5103Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-5103MC-PGE Period From Period From Period From Frame Period [A] Trigger start edge Trigger end to Exposure end to PixelFormat (usec) to Exposure start Exposure end [C] next Trigger start [B] (usec) -
Page 57: Gox-8901Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-8901MC-PGE Period From Period From Period From Frame Period [A] Trigger start edge Trigger end to Exposure end to PixelFormat (usec) to Exposure start Exposure end [C] next Trigger start [B] (usec) -
Page 58: Gox-12401Mc-Pge
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE GOX-12401MC-PGE Period From Period From Period From Frame Period [A] Trigger start edge Trigger end to Exposure end to PixelFormat (usec) to Exposure start Exposure end [C] next Trigger start [B] (usec) -
Page 59: Gain Control
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Gain Control Related Setting Items: AnalogControl Adjust the overall gain with AnalogAll (master gain) and adjust the white balance by changing DigitalRed and DigitalBlue. Color Model Monochrome Model Automatic Gain Level Control... -
Page 60: White Balance
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE White Balance Related Setting Items: AnalogControl To adjust the white balance automatically, set BalanceWhiteAuto to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. -
Page 61: Color Temperature
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Color Temperature The adjustable range of white balance for this camera is 3000K to 9000K. Please refer to the figure below for an overview of the relationship between various lighting types and color temperature. -
Page 62: Alc (Automatic Level Control) Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ALC (Automatic Level Control) Function Related Setting Items: AutoLevelControl The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions and is capable of handling various changes in brightness. -
Page 63: Gamma Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Gamma Function Related Setting Items: AnalogControl The Gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing. -
Page 64: Lut (Lookup Table)
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE LUT (Lookup Table) Related Setting Items: LUTControl The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 257 setting points (indexes). -
Page 65: Blemishcompensation
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE BlemishCompensation Related Setting Items: BlemishControl Multiple defective pixels that are not adjacent to each other can occur on CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 256 pixels can be corrected. -
Page 66: Manual Configuration
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Manual Configuration 1. Select the index in BlemishCompensationIndex. You can select from 1 to 256. However, configure the indexes in order starting with the smallest index. If you skip indexes while configuring settings, interpolation may not be performed. -
Page 67: Shading Correction
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Shading Correction Related Setting Items: ShadingControl The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V). -
Page 68: To Use The Shading Correction Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Cautions: For FlatShading and ColorShading, the maximum amount of correction gain for all pixels is limited to 8 times the amount of gain before correction. (The amount of gain cannot be increased to more than 8 times the amount of gain from before correction.) If the area in the screen with the highest brightness level is 175 LSB or less (during 10-bit video output), proper correction is not possible. -
Page 69: Binning Function
This camera supports the following Binning mode. BinningHorizontal, BinningVertical: Performs Horizontal x2 and/or Vertical x2 digital binning (Sum or Average) on the FPGA. Note: GOX-2402M-PGE processes 2x2 binning in the image sensor and is fixed to Sum mode. How to Configure... -
Page 70: Decimation Mode
VideoProcessBypassMode is On, except GOX-2402M-PGE. When using GOX-2402M-PGE, this function can be used with VideoProcessBypassMode but BinningHorizontal and BinningVertical cannot be set individually. If VideoProcessBypassMode is changed from On to Off, the BinningHorizontal and BinningVertical settings will not be restored. -
Page 71: Roi Function (Single Roi)
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ROI Function (Single ROI) Related Setting Items: ImageFormatControl The ROI (region of interest) function allows you to output images by specifying the areas to scan. Specify the area to scan by specifying width, height, and horizontal/vertical offset values under ImageFormatControl. -
Page 72: Single Roi - Example
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Single ROI - Example Binning Off Binning On [BinningHorizontal]: 1, [BinningVertical] : 1 [BinningHorizontal]: 2, [BinningVertical] : 2 - 72 -... -
Page 73: Pulse Generator
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Pulse Generator Related Setting Items: PulseGenerator Tips for using the Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. -
Page 74: Sequencer Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Sequencer Function Related Setting Items: SequencerControl The Sequencer function lets you define up to 32 index combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received. This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance. -
Page 75: Triggersequencer Mode
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE When using SequencerWidth / SequencerHeght, set the Width and Height to the default values in advance. TriggerSequencer Mode With this mode, the Sequencer Trigger “pattern” is predetermined by the user. The user defines up to 32 different “indexes.”... -
Page 76: Sample Triggersequencer Mode Operation
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Sample TriggerSequencer Mode Operation User-Defined Indexes (Up to 32) 1. Specify "1" in SequencerSetStart and start TriggerSequencer mode with index 1. 2. Based on the SequencerFrameCount setting (= 2), capture a 2-frame image with the first and second triggers. -
Page 77: Commandsequencer Mode
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE CommandSequencer Mode As with TriggerSequencer mode, you can define up to 32 indexes beforehand in this mode. Set SequencerCommandIndex to point to one of your preconfigured indexes. This index will be executed on each trigger, until it is changed to point to a different index, typically by your vision application. -
Page 78: Counter And Timer Control Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Counter and Timer Control Function Related Setting Items: CounterAndTimerControl Note: This camera supports only the Counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter and reads that information from the host side. -
Page 79: Internal Camera Blocks
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Internal Camera Blocks To Use the Counter Function Configure the settings as follows. Four counters are available. Specify a counter (Counter0 to Counter3), and configure the settings. Setting Value Item Description... -
Page 80: Chunk Data Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Chunk Data Function Related Setting Items: ChunkDataControl The Chunk Data function adds camera configuration information to the image data that is output from the camera. In addition, when images are shot with a single camera in sequence under multiple setting conditions, you can search for images by their setting conditions. -
Page 81: Action Control Function
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Action Control Function Related Setting Items: ActionControl How to use GigE Vision Action Commands The Action Control Function is a function that executes the pre-configured action when the camera receives action commands. -
Page 82: Action Control Example
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Action Control Example Assume that the following settings have been pre-configured on the camera. ActionDeviceKey : 0x00001001 ActionGroupMask[1] : 0x00000011 ActionGroupKey[1] : 0x00000001 ActionGroupMask[2] : 0x00000111 ActionGroupKey[2] : 0x00000002 When the camera receives action commands (ActionDeviceKey:0x00001001, ActionGroupMask:0x00000011, ActionGroupKey: 0x00000002), Action2 is executed. -
Page 83: Ptp (Precision Time Protocol)
User Manual (Ver. 1.5) - Main Functions GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE PTP (Precision Time Protocol) Related Setting Items: TransportLayerControl The camera can work as the slave for Precision Time Protocol defined in IEEE 1588. When the IEEE 1588 master clock exists in the network where the camera is connected, this function synchronizes the camera to the time of the master clock. -
Page 84: Setting List (Feature Properties)
Setting List (Feature Properties) This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element enumeration type (IEnumeration), a character string (IString), a logical type (IBoolean), and a category type (ICategory) or a command type (ICommand) for executing the function. -
Page 85: Devicecontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE DeviceControl Display/configure information related to the device. Device Control Items Setting Range Default Description "JAI DeviceVendorName Display the manufacturer name. Corporation" DeviceModelName Display the model name. See the DeviceManufacturerInfo Display the manufacturer information. - Page 86 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Device Control Items Setting Range Default Description Indicates the minor version number of the device's Transport DeviceTLVersionMinor 0 (Fixed) Layer. Indicates the sub minor version number of the device's Transport DeviceTLVersionSubMinor 1 (Fixed) Layer.
-
Page 87: Transportlayercontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE TransportLayerControl Display information on transport layer control. TransportLayerControl Items Setting Range Default Description Display the payload size. (Include ChunkData) (unit: PayloadSize 48 ~ 67109240 12288 bytes) GigEVision... - Page 88 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE TransportLayerControl Items Setting Range Default Description 0:None 1:PersistentIP GevIPConfigurationStatus 2:DHCP 2:DHCP Display the current IP configuration status. 3:LLA 4:ForceIP GevPersistentIPAddress 192.168.0.100 Set the persistent IP address. GevPersistentSubnetMask 255.255.255.0 Set the persistent subnet mask.
- Page 89 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE TransportLayerControl Items Setting Range Default Description Controls the device access privilege of an application. 0: Open Access:Access rights have not been obtained 0: Open by the application.
- Page 90 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE TransportLayerControl Items Setting Range Default Description The state of this feature is copied into the "do not 0: False fragment" bit of IP header of each stream packet. It can be GevSCPSDoNotFragment 1: TRUE used by the application to prevent IP fragmentation of...
-
Page 91: Imageformatcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ImageFormatControl Configure image format settings. Image Format Control Items Setting Range Default Description Display the maximum image width. GOX-2402MC-PGE: 1936 GOX-3201MC-PGE: 2064 SensorWidth GOX-5103MC-PGE: 2464 GOX-8901MC-PGE: 4112... - Page 92 Monochrome models only. 0:Sum 0:Sum Related Topic: Binning 1:Average Note: GOX-2402M-PGE processes 2x2 binning in Function the image sensor and is fixed to Sum mode. Set the number of pixels in the horizontal direction for BinningHorizontal 1 ~ 2 which to perform binning. Monochrome models only.
- Page 93 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Image Format Control Items Setting Range Default Description If set to 2, Pixels (50%) are thinned out horizontally. DecimationHorizontal 1: None Note: DecimationHorizontal and DecimationVertical 2: Pixels are 1: None Related Topic:...
- Page 94 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Image Format Control Items Setting Range Default Description Set the pixel format. Mono Model 0x01080001: Mono8 (Default) 0x01100003: Mono10 0x010C0004: Mono10Packed 0x01100005: Mono12 0x010C0006:Mono12Packed Color Model 0x01080009: BayerRG8 (Default)
-
Page 95: Acquisitioncontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE AcquisitionControl Configure image capture settings. Acquisition Control Setting Range Default Description Items AcquisitionMode 0:SingleFrame 1:MultiFrame 2:Continuous Select the image capture mode. Related Topic: 2:Continuous Acquisition Control AcquisitionStart... - Page 96 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Acquisition Control Setting Range Default Description Items 0: Low 1: High 2: Software PulseGenerator0 TriggerSource 14-17: 21: Line5 Opt In Select the trigger signal source. UserOutput0-3 18-19: Action0-1 21: Line5 Opt In1...
-
Page 97: Digitaliocontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Acquisition Control Setting Range Default Description Items 0: Off Set whether to enable auto exposure. When set to Once, the ExposureAuto 1:Once 0: Off automatic adjustment will be performed only once, and then automatically switched to Off. - Page 98 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Digital IO Control Setting Range Default Description Items Enable/disable polarity inversion for the selected input signal or output signal. 0: False LineInverter 0: False 1: True Note: Line5 Opt In1 is fixed to "0".
- Page 99 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Digital IO Control Setting Range Default Description Items 0: Off 1: 10us 2: 100us 3: 500us 4: 1ms 5: 3ms 6: 5ms OptInFilterSelector 7: 7ms 0: Off...
-
Page 100: Pulsegenerator
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE PulseGenerator Configure pulse generator settings. Related Topic: Pulse Generator Pulse Generator Items Setting Range Default Description Set the division value for the prescaler (12 bit) using ClockPreScaler 1 ~ 4096 PixelClock as the base clock. - Page 101 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Pulse Generator Items Setting Range Default Description Set the start point of the Low interval as a clock count. PulseGeneratorEndPoint 1 ~ 1048575 464063 When the counter reaches this value, the output will be Set the start point of the Low interval in milliseconds.
-
Page 102: Analogcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Pulse Generator Items Setting Range Default Description PulseGeneratorClear 0:Async Mode 0:Async Mode Select the sync mode for the count clear input signal. SyncMode 1:Sync Mode AnalogControl... - Page 103 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Analog Control Items Setting Range Default Description Select the area for which to configure AWBAreaEnable. 14: High 13: High 15: HighLeft 12: HighRight MidLeft MidRight 11: MidHigh...
-
Page 104: Lutcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Analog Control Items Setting Range Default Description 0: Off LUTMode 1: Gamma 0:Off Select the LUT mode. 2: LUT LUTControl Configure LUT settings. Related Topic: LUT (Lookup Table) LUT Control Items... - Page 105 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Auto Level Control Setting Range Default Description Items Select the area for which to configure ALCAreaEnable. 14: High 13: High 15: HighLeft 12: HighRight MidLeft MidRight...
-
Page 106: Imagingcontrol
Max: (GainAutoControlMax - 1) Set the maximum value for the GainAuto(ASC) control range. AutoGainControl 12600 Min: GainAutoControlMin +1 GainRawMax Max: 12600 ImagingControl Configure other JAI functions. Imaging Control Items Setting Range Default Description VideoProcessBypassMode 0: Off 0: Off Enable/disable VideoProcessBypass mode. -
Page 107: Shadingcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ShadingControl Configure shading correction settings. Related Topic: Shading Correction Setting Shading Control Items Default Description Range 0: Flat Select the shading correction method. Shading 0: Flat ShadingCorrectionMode... -
Page 108: Blemishcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE BlemishControl Configure settings for JAI white blemish correction. Related Topic: BlemishCompensation Blemish Control Items Setting Range Default Description 0: False BlemishEnable Enable/disable blemish correction. -
Page 109: Sequencercontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Blemish Control Items Setting Range Default Description BlemishCompensation Delete detected or specified blemish information selected in DataClear BlemishCompensationIndex. BlemishCompensationNumber 0 ~ 256 Display the number of target blemishes. - Page 110 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Sequencer Control Items Setting Range Default Description SequencerFrameCount 1 ~ 255 Set the FrameCount of the selected SequencerIndex. Set the ExposureTime of the selected SequencerIndex. SequencerExposureTime Note: The setting range and the default value are the same as the ExposureTime (AcquisitionControl).
-
Page 111: Counterandtimercontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE CounterAndTimerControl Configure counter settings. This camera only supports the counter functions. Related Topic: Counter and Timer Control Function Counter And Timer Setting Range Default Description Control Items... -
Page 112: Actioncontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ActionControl Configures action control settings. Related Topic: Action Control Function Action Control Items Setting Range Default Description 0x00000000 ~ An action command is executed if this ActionDeviceKey matches the ActionDeviceKey 0x00000000 0xFFFFFFFF... - Page 113 User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Event Control Items Setting Range Default Description EventAcquisitionTriggerFrameID 0 (Fixed) Displays the FrameID value when an event occurs. When the event AEventFrameStartData occurs, the EventFrameStartData following three data can be checked.
-
Page 114: Chunkdatacontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE ChunkDataControl Configure Chunk Control settings. Related Topic: Chunk Data Function Setting Chunk Data Control Items Default Description Range 0: Off ChunkModeActive 0: Off Set whether to enable ChunkData. -
Page 115: Testcontrol
User Manual (Ver. 1.5) - Setting List (Feature Properties) GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Setting Chunk Data Control Items Default Description Range Displays the SequencerSet number currently set in TriggerSequenceMode or CommandSequencerMode. (1 is displayed in ChunkSequencerSetActive Normal Mode.) (SequencerControl) ChunkID: 0x0000200C... -
Page 116: Miscellaneous
GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. Power Supply and Connections Issue: The POWER/TRIG LED remains lit amber and does not turn green, even after power is supplied to the camera. -
Page 117: Specifications
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Specifications Note: GOX-2402MC-PGE, GOX-3201MC-PGE, and GOX-5103MC-PGE include the CS-Mount models. Item Description Scanning System Progressive scan, 1 tap Synchronization Internal Interface 1000BASE-T Ethernet (GigE Vision 2.0), IEEE 802.3af Monochrome: Monochrome CMOS Image Sensor Color:... - Page 118 User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Item Description Model Name 8-bit 10/12-bit Packed 10/12-bit Unpacked GOX-2402MC-PGE 49.9 fps 33.2 fps 24.9 fps GOX-3201MC-PGE 36.5 fps 24.3 fps 18.2 fps Max Acquisition Frame Rate GOX-5103MC-PGE 22.9 fps...
- Page 119 User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Item Description GOX-2402MC-PGE:0 ~ 1192(596), step 2(1) GOX-3201MC-PGE: 0 ~ 1528(764), step 2(1) GOX-5103MC-PGE:0 ~ 2040(1020), step 2(1) Digital image output GOX-8901MC-PGE: 0 ~ 2152(1076), step 2(1) format GOX-12401MC-PGE:0 ~ 2992(1496), 2 step 2(1) ROI OffsetY...
- Page 120 User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Item Description Default Level: 8LSB@8bit DigitalAll (Mono/Color): -133 ~ +255 LSB @12bit Black Level DigitalRed (Color): -64 ~ +64 LSB @12bit Adjustment DigitalBlue (Color): -64 ~ +64 LSB @12bit Resolution Adjustment: 1LSB@12bit Manual Adjustment Range AnalogAll (Mono/Color): 0db ~ 42dB...
-
Page 121: Package Contents
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Item Description 5°C ~ + 45°C / 20% ~ 80% (non-condensing) Verified Performance Temperature / Note: It may change depending on the installation environment. Please refer to the Caution (Package Humidity Contents). -
Page 122: Spectral Response: Gox-2402M-Pge, Gox-2402C-Pge
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Spectral Response: GOX-2402M-PGE, GOX-2402C-PGE Note: Including CS-mount models. - 122 -... -
Page 123: Spectral Response: Gox-3201M-Pge, Gox-3201C-Pge
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Spectral Response: GOX-3201M-PGE, GOX-3201C-PGE Note: Including CS-mount models. - 123 -... -
Page 124: Spectral Response: Gox-5103M-Pge, Gox-5103C-Pge
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Spectral Response: GOX-5103M-PGE, GOX-5103C-PGE Note: Including CS-mount models. - 124 -... -
Page 125: Spectral Response: Gox-8901M-Pge, Gox-8901C-Pge
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Spectral Response: GOX-8901M-PGE, GOX-8901C-PGE - 125 -... -
Page 126: Spectral Response: Gox-12401M-Pge, Gox-12401C-Pge
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Spectral Response: GOX-12401M-PGE, GOX-12401C-PGE - 126 -... -
Page 127: Dimensions
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Dimensions Standard Model (C-Mount) Notes: Dimensional tolerance: ± 0.3mm Unit: mm - 127 -... -
Page 128: Cs-Mount Model
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE CS-Mount Model Notes: Dimensional tolerance: ± 0.3mm Unit: mm - 128 -... -
Page 129: Comparison Of The Decibel Display And Multiplier Display
User Manual (Ver. 1.5) - Miscellaneous GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Comparison of the Decibel Display and Multiplier Display Decibels [dB] Multipliers [X] Remarks 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239 2.512 2.818... -
Page 130: User's Record
63.096 70.795 79.433 89.125 112.202 125.893 User's Record Camera type: Go-X Series Global Shutter GigE interface Model name: …………… Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. - 130 -... -
Page 131: Revision History
User Manual (Ver. 1.5) - Revision History GOX-2402MC-PGE | GOX-3201MC-PGE | GOX-5103MC-PGE | GOX-8901MC-PGE | GOX-12401MC-PGE Revision History Device Revision Date Changes Version Changed the layout of the manual, and corrected errors. Added the KC certification information. 2023/12/01 DV0110 Updated topics including the China RoHS, Trigger...
Need help?
Do you have a question about the GOX-2402M-PGE and is the answer not in the manual?
Questions and answers
