JAI Go-X Series User Manual

Cmos digital progressive scan monochrome and color camera
Hide thumbs Also See for Go-X Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing this product.
Be sure to read this manual before use.
This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read
this manual to ensure proper operation.
The contents of this manual are subject to change without notice for the purpose of improvement.
© 2020 JAI
User Manual
GOX-3201M-PGE / GOX-3201C-PGE
GOX-5103M-PGE / GOX-5103C-PGE
CMOS Digital Progressive Scan
Monochrome and color Camera
Document Version: 1.0
GO-X_Series_PGE_Ver.1.0_Dec.2020

Advertisement

Table of Contents
loading

Related Manuals for JAI Go-X Series

Summary of Contents for JAI Go-X Series

  • Page 1 This manual includes important safety precautions and instructions on how to operate the unit. Be sure to read this manual to ensure proper operation. The contents of this manual are subject to change without notice for the purpose of improvement. © 2020 JAI...

  • Page 2: Table Of Contents

    Go-X Series GigE Vision I/F Contents Notice/Warranty/Certifications Blemish Compensation Usage Precautions Shading Correction Features Binning Function Parts Identifications Decimation mode ROI Function (Single ROI) Preparation Pulse Generator Preparation Process Sequencer Function Step 1: Installing the Software Counter And Timer Control Function...

  • Page 3: Notice/Warranty/Certifications

    The material contained in this manual consists of information that is proprietary to JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 4 Go-X Series GigE Vision I/F Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.
  • Page 5 Go-X Series GigE Vision I/F Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 6: Usage Precautions

    Go-X Series GigE Vision I/F Usage Precautions Notes on cable configurations The presence of lighting equipment and television receivers nearby may result in video noise. In such cases, change the cable configurations or placement. Notes on LAN cable connection Secure the locking screws on the connector manually, and do not use a driver.

  • Page 7: Features

    Go-X Series GigE Vision I/F Features Go-X Series GigE Vision interface cameras are industrial progressive scan cameras equipped with a global shutter CMOS image sensor. These provide an attractive combination of high resolution, high speed, and high image quality for machine vision applications.

  • Page 8: Parts Identifications

    Go-X Series GigE Vision I/F Parts Identification ② ④ ⑤ ③ ① ⑥ ⑦ ⑧ ⑨ ① Lens mount（C-mount） Mount a C-mount lens, microscope adapter, etc. here. ❖ Before mounting a lens, be sure to refer to “Step 2:Connecting Devices” and confirm the precautions for attaching a lens and the supported lens types.
  • Page 9 Go-X Series GigE Vision I/F ③ POWER/TRIG LED Indicates the power and trigger input status. LED status and camera status Light Status POWER/ （Lit amber） Camera initializing. TRIG LED （Lit green） Camera in operation. （Blinking green） During operation in trigger mode, trigger signals are being input.
  • Page 10 Go-X Series GigE Vision I/F ■ Recommended external input circuit diagram (reference example) Opto In + (Pin2) Opto In - (Pin3) ■ Recommended external output circuit diagram (reference example) Opto Out + (Pin4) Opto Out - (Pin5) OPTO-In circuit characteristics Technical notes —...
  • Page 11 Go-X Series GigE Vision I/F Characteristics of the recommended circuits for Opto OUT OUTPUT LINE RESPONSE TIME Camera Output Signal Output Line Voltage For the operating conditions of applied voltage (User Power) +12V, load resistance 10kΩ, and cable length 1m, the timing is shown in the table below.

  • Page 12: Preparation

    When using the camera for the first time, install the software for configuring and controlling the camera (eBUS SDK for JAI) on the computer. ❖ When you install eBUS SDK for JAI, eBUS SDK for JAI player will also be installed. Download the eBUS SDK for JAI from the JAI website.

  • Page 13: Step 2: Connecting Devices

    Go-X Series GigE Vision I/F Step 2: Connecting Devices (or direct connection) Camera body ④ Network card ③ LAN cable ①Lens ⑤ Computer ② Direct connection (or MP-43 tripod adapter plate) Switching hub ⑥ DC IN/trigger IN connection cable To external trigger ⑦...
  • Page 14 Go-X Series GigE Vision I/F Note The following formula can be used to estimate the focal length. Focal length ＝ WD /（1 ＋ W/w） WD ：Working distance （distance between lens and object） ：Width of object ：Width of sensor ② Direct connection（or MP-43 tripod adapter plate）...

  • Page 15: Step 3: Verifying Camera Operation

    Verifying the Connection between the Camera and PC Verify whether the camera is properly recognized via Control Tool. Connecting the Camera to Control Tool Startup eBUS Player for JAI eBUS Player for JAI eBUS Player for JAI startup screen appears. — 15 —...
  • Page 16 Go-X Series GigE Vision I/F eBUS Player for JAI File Tools Help Connection Disconnect Select / Connect IP address MAC address GUID Vendor Model Name Acquisition Control Source Mode Play Stop Parameters and Controls Communication control Device control Image stream control Select the camera you want to configure.
  • Page 17 Go-X Series GigE Vision I/F Check that the settings of the selected camera are displayed. eBUS Player for JAI File Tools Help Connection Disconnect Select / Connect IP address MAC address GUID XXXXXXXXXXX Vendor JAI Corporation GOX-3201C-PGE Model JAI_DEMO Name...

  • Page 18: Step 5: Changing The Camera Settings

    Go-X Series GigE Vision I/F Step 5: Changing the Camera Settings This section explains how to change settings by describing the procedure for changing the output format as an example. Configuring the Output Format Configure the size, position, and pixel format of the images to be acquired.

  • Page 19: Step 6: Adjusting The Image Quality

    Go-X Series GigE Vision I/F Step 6: Adjusting the Image Quality Display the camera image and adjust the image quality. Displaying the Image Display the image captured by the camera. When you push [Play] button, the camera image appears in right area.
  • Page 20 Go-X Series GigE Vision I/F Adjusting the Gain Adjust the image quality using the gain and white balance* functions. *) Color model only To adjust the image quality The Visibility must be changed from [Beginner] to [Guru]. Adjust the sensitivity via the analog gain (i.e., master gain).

  • Page 21: Step 7: Saving The Settings

    *) Color model only Step 7: Saving the Settings The setting values configured in the player (eBUS SDK for JAI) will be deleted when the camera is turned off. By saving current setting values to user memory, you can load and recall them whenever necessary.
  • Page 22 Go-X Series GigE Vision I/F Select [UserSetSave], and click [Execute ‘UserSetSave’ Command]. The current setting values are saved as user settings. ■ To load user settings Stop image acquisition. User settings can only be loaded when image capture on the camera is stopped.

  • Page 23: Main Functions

    Go-X Series GigE Vision I/F Main Functions Acquisition Control This camera has three Acquisition modes (SingleFrame, MultFrame, Continuous). Use [AcquisitionControl] settings to perform operations and settings for image capture. SingleFrame When the [AcquisitionStart] command is executed, one frame of image is captured.

  • Page 24: Exposure Mode

    Go-X Series GigE Vision I/F Exposure Mode This camera has three Exposure modes (Off, Timed, TriggerWidth). Use [AcquisitionControl] settings to perform operations and settings for exposure. ExposureMode = Off Exposure control is not performed (free-running operation). The exposure time is the longest possible time within the operating conditions such as the frame rate.

  • Page 25: Trigger Control

    Go-X Series GigE Vision I/F Trigger Control The camera allows the following controls to be performed via external trigger signals. TriggerSelector Description AcquisitionStart Start image acquisition in response to the external trigger signal input. AcquisitionEnd Stop image acquisition in response to the external trigger signal input.

  • Page 26: Pixel Format

    Go-X Series GigE Vision I/F Pixel Format Selectable PixelFormat is as follows. Color model : BayerRG8, BayerRG10, BayerRG10Packed, BayerRG12, BayerRG12Packed, BayerGB8, BayerGB10, BayerGB10Packed, BayerGB12, BayerGB12Packed, BayerGR8, BayerGR10, BayerGR10Packed, BayerGR12, BayerGR12Packed, BayerBG8, BayerBG10, BayerBG10Packed, BayerBG12, BayerBG12Packed Monochrome model : Mono8, Mono10, Mono10Packed, Mono12, Mono12Packed Note In color model, the Bayer array is changed by the image flip function.

  • Page 27: Gpio (Digital Input/Output Settings)

    Go-X Series GigE Vision I/F GPIO (Digital Input/Output Settings) The unit can input/output the following signals to and from external input/output connectors. External output Line2 : Opt Out DC IN / TRIG IN connector (6-pin round) External input Line5 : Opt In...

  • Page 28: Videoprocessbypassmode

    Go-X Series GigE Vision I/F VideoProcessBypassMode The video process bypass mode is a function that bypasses internal video processing on the camera. When bypass is enabled, the sensor output and camera output data can be set to the same bit depth.

  • Page 29: Calculate The Maximum Frame Rate

    Go-X Series GigE Vision I/F Calculate the maximum frame rate (approximate) This section describes how to calculate the maximum frame rate (approximate). The maximum frame rate is as follows depending on the sensor’s scanning range and the GigE bandwidth. ■ The maximum frame rate (GigE bandwidth) Interface_FR[Hz] = BandwidthPerPixelFormat ÷...
  • Page 30 Go-X Series GigE Vision I/F ■ During Continuous operation ([Frame Start] trigger is [Off]) FR_Cont[Hz] = MIN(Interface_FR, Sensor_FR) ■ When [TriggerMode] is [On] ([Frame Start] trigger is [On]) First, calculate the maximum OverlapTime value for the shortest trigger cycle. MaxOverlapTime_TrOlrd[us] = (1000000/FR_Cont) - (14 x H_period) ・When ExposureTime ≦...

  • Page 31: Timing Chart (Gox-3201Mc-Pge)

    Go-X Series GigE Vision I/F Timing chart (GOX-3201MC-PGE) ■ When [ExposureMode] is [Timed] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled Next trigger disabled Trigger Sensor Exposure Exposure Exposure time Active Readout Period From Trigger start edge to...
  • Page 32 Go-X Series GigE Vision I/F ■ When [ExposureMode] is [TriggerWidth] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled (Next trigger disabled) Trigger Sensor Exposure Exposure ExposureTime Active Readout Period From Trigger start edge Period From Trigger end to...

  • Page 33: Timing Chart (Gox-5103Mc-Pge)

    Go-X Series GigE Vision I/F Timing chart (GOX-5103MC-PGE) ■ When [ExposureMode] is [Timed] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled Next trigger disabled Trigger Sensor Exposure Exposure Exposure time Active Readout Period From Trigger start edge to...
  • Page 34 Go-X Series GigE Vision I/F ■ When [ExposureMode] is [TriggerWidth] • FrameStartTrigger On A (Frame Period) Next trigger Input enabled (Next trigger disabled) Trigger Sensor Exposure Exposure ExposureTime Active Readout Period From Trigger start edge Period From Trigger end to...

  • Page 35: Gain Control

    Go-X Series GigE Vision I/F Gain Control Adjust the [AnalogAll] (master gain) setting first, and then adjust the [AnalogRed], [DigitalRed]. Color model Digital Red Digital Blue Analog All 15dB 15dB x 16 24dB -7dB -7dB 15dB 15dB x 1.0 -7dB...

  • Page 36: White Balance

    Go-X Series GigE Vision I/F White Balance To adjust the white balance automatically, set [BalanceWhiteAuto] to Once (automatic adjustment only once) or Continuous (automatic adjustment always). The metering area can be limited for automatic adjustment. To limit the metering area, specify each of the 16 areas with [AWBAreaSelector] and set [AWBAreaEnable] to True or False.

  • Page 37: Alc (Automatic Level Control) Function

    Go-X Series GigE Vision I/F ALC (Automatic Level Control) Function The ALC (automatic level control) function combines the automatic gain control (AGC/Auto Gain Control) and automatic exposure control (ASC/Auto Shutter Control) functions, and is capable of handling various changes in brightness.The function operates as follows in response to changes in brightness.

  • Page 38: Gamma Function

    Go-X Series GigE Vision I/F Gamma Function The gamma function corrects the output signals from the camera beforehand (reverse correction), taking into consideration the light-emitting properties of the monitor display. As the light-emitting properties of the monitor are not linear, the entire image may be darker or the gradation in the dark areas may be less noticeable when camera outputs are displayed without processing.

  • Page 39: Lut (Lookup Table)

    Go-X Series GigE Vision I/F LUT (Lookup Table) The LUT function is used to generate a non-linear mapping between signal values captured on the sensor and those that are output from the camera. You can specify the output curve using 257 setting points (indexes).

  • Page 40: Blemishcompensation

    Go-X Series GigE Vision I/F BlemishCompensation Multiple defective pixels that are not adjacent to each other can occur on conventional CMOS sensor cameras. This camera features a function that interpolates defective pixels using the surrounding pixels. Up to 256 pixels can be corrected. Pixel interpolation can be performed via automatic detection or point-by-point manual settings.

  • Page 41: Shading Correction

    Go-X Series GigE Vision I/F Shading Correction The ShadingCorrection function corrects non-uniformity (i.e., shading) in the amount of light generated by the lens and lighting equipment. Using this function allows correction even if top, bottom, left, and right shading is not symmetrical in relation to the center of the screen (H, V).

  • Page 42: Binning Function

    Go-X Series GigE Vision I/F ■ To use the shading correction function Configure the settings as follows. Item Setting value Description ShadingCorrectionMode FlatShading, ColorShading Select the shading correction mode. ShadingMode User1, User2, User3, Off Select the user area to which to save the shading correction value.

  • Page 43: Roi Function (Single Roi)

    Go-X Series GigE Vision I/F ROI Function (Single ROI) The ROI (region of interest) function allows you to output images by specifying the areas to scan. Specify the area to scan by specifying width, height, and horizontal/vertical offset values under [ImageFormatControl].

  • Page 44: Pulse Generator

    Go-X Series GigE Vision I/F Pulse Generator By using this function, any signal can be generated inside the camera. The following is an example of signal generation. Settings PulseGeneratorStartPoint = 2 PulseGeneratorEndPoint = 6 PulseGeneratorLength = 10 PulseGeneratorPulseWidth = 4...

  • Page 45: Sequencer Function

    Go-X Series GigE Vision I/F Sequencer Function The Sequencer function lets you define up to 32 index combinations of exposure time, gain, ROI, and other settings which can be stepped through each time a trigger is received.This is particularly useful for quickly capturing multiple exposures of objects under inspection to adjust for areas or components with significantly different levels of reflectance.
  • Page 46 Go-X Series GigE Vision I/F Sample TriggerSequencer mode operation User-defined Indexes (up to 32) Triggers/ Image Frames Specify "1" in [SequencerSetStart], and start TriggerSequencer mode with index 1. Capture a 2-frame image with the first and second triggers. For the next index, configure index 3 specified in [SequencerSetNext], and capture an image with the number of frames (number of triggers) specified in [SequencerFrameNumber].

  • Page 47: Counter And Timer Control Function

    Go-X Series GigE Vision I/F Counter And Timer Control Function This camera supports only the counter function. The counter function counts up change points in the camera’s internal signals using the camera’s internal counter, and reads that information from the host side. This function is useful for verifying error conditions via the count value using internal camera operations.
  • Page 48 Go-X Series GigE Vision I/F ■ Internal camera blocks Counter0 Counter Event detection FrameStartTrigger At event occurrence or count up Counter1 Counter Event detection ExposureStart At event occurrence or count up Counter2 Counter Event detection SensorReadOut At event occurrence or count up...

  • Page 49: Chunk Data Function

    Go-X Series GigE Vision I/F Chunk Data Function The Chunk Data function adds camera configuration information to the image data that is output from the camera. Embedding camera configuration information in the image data allows you to use the serial number of the camera as a search key and find specific image data from among large volumes of image data.

  • Page 50: Event Control Function

    Go-X Series GigE Vision I/F Event Control Function The Event Control Function is a function that outputs a signal change point inside the camera as information indicative of an event occurrence (event message) by using GVCP (GigE Vision Control Protocol).

  • Page 51: Action Control Function

    Go-X Series GigE Vision I/F Action Control Function The Action Control Function is a function that executes the pre-configured action when the camera receives action commands. Action commands can send both unicast and broadcast messages and give instructions for actions to multiple cameras simultaneously by broadcasting them.

  • Page 52: Ptp (Precision Time Protocol)

    Go-X Series GigE Vision I/F PTP (Precision Time Protocol) Function The camera can work as the slave for Precision Time Protocol defined in IEEE 1588. When the IEEE 1588 master clock exists in the network where the camera is connected, this function synchronizes the camera to the time of the master clock.

  • Page 53: Setting List

    Go-X Series GigE Vision I/F Setting List This camera complies with GenICam. Each setting item name conforms to GenICam SFNC (Standard Features Naming Convention). (There are some JAI-specific setting items). Each setting item is an integer type (IInteger), a real type (IFloat), an element...

  • Page 54: Feature Properties

    Go-X Series GigE Vision I/F Feature Properties Item Setting range Default value Description a) DeviceControl Display/configure information related to the device. DeviceVendorName ー "JAI Corporation" Display the manufacturer name. DeviceModelName ー ー Display the model name. DeviceManufacturerInfo ー See the possibilities Display the manufacturer information.
  • Page 55 Go-X Series GigE Vision I/F Item Setting range Default value Description b) ImageFormatControl Configure image format settings. SensorWidth GOX-3201MC-PGE : 2064 ー Display the maximum image width. GOX-5103MC-PGE : 2464 SensorHeight GOX-3201MC-PGE : 1544 ー Display the maximum image height.
  • Page 56 Go-X Series GigE Vision I/F Item Setting range Default value Description c) AcquisitionControl Configure image capture settings. AcquisitionMode 0:SingleFrame 2:Continuous Select the image capture mode. 1:MultiFrame 2:Continuous AcquisitionStart ー ー Start image capture. AcquisitionStop ー ー Stop image capture. AcquisitionFrameCount 1〜65535...
  • Page 57 Go-X Series GigE Vision I/F Item Setting range Default value Description d) EventControl Configure settings for event control. EventSelector ー AcquisitionTrigger Select the event to send the event message. [setting range] 0:AcquisitionTrigger, 1:FrameStart, 2:FrameEnd, 5:ExposureStart, 6:ExposureEnd EventNotification Off, On Sets whether or not to send an event message when an event selected by [EventSelector] occurs.
  • Page 58 Go-X Series GigE Vision I/F Item Setting range Default value Description e) AnalogControl Configure analog control settings. GainSelector 0:AnalogAll Select the gain to configure. AnalogAll, 1:DigitalRed, (DigitalRed and DigitalBlue are color model only) 2:DigitalBlue Gain AnalogAll, x1.0 Set the gain value for the gain setting selected in [GainSelector].
  • Page 59 Go-X Series GigE Vision I/F Item Setting range Default value Description f) DigitalIOcontrol Configure settings for digital input/output. LineSelector 21:Line2 21:Line2 Select the input/output to configure. 24:Line5 60:Nand0 In1 61:Nand0 In2 62:Nand1 In1 63:Nand1 In2 255:TimestampReset LineSource ー ー Select the line source signal for the item selected in [LineSelector].
  • Page 60 Go-X Series GigE Vision I/F Item Setting range Default value Description g) PulseGenerator Configure pulse generator settings. ClockPreScaler 1〜4096 Set the division value for the prescaler (12 bit) using PixelClock as the base clock. PulseGeneratorClock (MHz) 0.0181274〜74.25 0.45 Set the clock used for the pulse generator.
  • Page 61 Go-X Series GigE Vision I/F Item Setting range Default value Description j) TransportLayerControl Display information on transport layer control. PayloadSize 48 〜 67109240 12288 Display the payload size. (Include ChunkData) (unit: bytes) GevCurrentPhysicalLinkConfigration SingleLink SingleLink Display the LinkConfiguration status. (Fixed at [SingleLink] on this camera) GevSupportedOptionSelector ー...
  • Page 62 Go-X Series GigE Vision I/F GevStreamChannelSelector 0 (Fixed) Selects the stream channel to control. GevSCCFGPacketResendDestina True, False False Sends a test packet. When this feature is set, the device will fire one test tion packet. GevSCCFGAllInTransmission True, False False GevSCCFGUnconditionalStreami...
  • Page 63 Idle Allows confirmation of the AGC, ASC, and AWB convergence status. [Status] 1:ExecutingASC, 2:ExecutingAGC, 3:ExecutingASCandAGC, 4:ExecutingAWB 5:ExecutingASCandAWB, 6:ExecutingAGCandAWB, 7:ExecutingASCandAGCandAWB, 8:Convergent, 9:ConditionError, 255:Idle o) BlemishControl Configure settings for JAI white blemish correction. BlemishEnable True, False True Enable/disable blemish correction. BlemishDetect ー...
  • Page 64 Go-X Series GigE Vision I/F Item Setting range Default value Description SequencerControl Configure sequencer settings. SequencerMode Off, On Enable/disable [SequencerMode]. SequencerModeSelect 0:TriggerSequencerMode, TriggerSequencerMode Select the sequencer mode. 1:CommandSequencerMode SequencerSetSelector 1〜32 Select the index number to configure. SequencerWidth ー ー Set the width of the selected SequencerIndex.

  • Page 65: Miscellaneous

    Go-X Series GigE Vision I/F Miscellaneous Troubleshooting Check the following before requesting help. If the problem persists, contact your local JAI distributor. ■ Power supply and connections The POWER/TRIG LED remains lit amber and Camera initialization may not be complete due does not turn green, even after power is to lack of a power.

  • Page 66: Specifications

    Go-X Series GigE Vision I/F Specifications Item Monochrome Color Scanning system Progressive scan, 1 tap Synchronization Internal Interface 1000BASE-T Ethernet (GigE Vision 2.0), IEEE 802.3af Image Ssensor Monochrome CMOS Bayer color CMOS GOX-3201MC-PGE:   1/1.8-inch 7.07mm(H) x 5.3mm(V) : 8.83mm(diagonal) image size (effective image) GOX-5103MC-PGE:   2/3-inch 8.45mm(H) x 7.07mm(V) : 11.01mm(diagonal)
  • Page 67 Go-X Series GigE Vision I/F Acquisition Mode Continuous / SingleFrame / MultiFrame（1 〜 65535） Acquisition AcquisitionStart / AcquisitionEnd Trigger Exposure FrameStart Selector Transfer AcquisitionTransferStart（Delayed readout） Off(Default), 10μs, 100μs, 500μs, 1ms, 3ms, 5ms, 7ms, 10ms, 15ms, Opto filter 20ms, 25ms, 30ms, 35ms, 40ms...
  • Page 68 Go-X Series GigE Vision I/F Vibration resistance 10G（20 Hz 〜 200 Hz X-Y-Z direction） Impact resistance DC ＋ 10 V 〜＋ 25 V （Via input terminal） Input range 2.7. W（typ.）(at 12 V input, default setting, 25 ℃ environment) 6-pin Connector Consumption 3.4 W（max.）...

  • Page 69: Spectral Response (Gox-3201Mc-Pge)

    Go-X Series GigE Vision I/F Spectral Response (GOX-3201MC-PGE) — 69 —...

  • Page 70: Spectral Response (Gox-5103Mc-Pge)

    Go-X Series GigE Vision I/F Spectral Response (GOX-5103MC-PGE) — 70 —...

  • Page 71: Dimensions

    Go-X Series GigE Vision I/F Dimensions Dimenstional tolerance: ± 0.3mm Unit: mm — 71 —...

  • Page 72: Comparison Of The Decibel Display And Multiplier Display

    Go-X Series GigE Vision I/F Comparison of the Decibel Display and Multiplier Display Decibels[db] Multipliers[x] Remarks 0.501 0.562 0.631 0.708 0.794 0.891 1.122 1.259 1.413 1.585 1.778 1.995 2.239 2.512 2.818 3.162 3.548 3.981 4.467 5.012 5.623 6.31 7.079 7.943 8.913...

  • Page 73: User's Record

    Model name: …………… Revision: …………… Serial No: …………… Firmware version: …………… For camera revision history, please contact your local JAI distributor. Trademarks • Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

  • Page 74: Index

    Go-X Series GigE Vision I/F Index 6-pin round Lens Lens mount Acquisition Lookup Table Adjusting the Black Level Adjusting the Gain Parts Identification Pixel format Binning Function POWER/TRIG LED Blemish Compensation Camera locking screw holes Connecting Devices Counter And Timer Control...

  • Page 75: Revision History

    Go-X Series GigE Vision I/F Revision history Revision Date Changes Dec 2020 — 75 —...
