Pairing The Computer With The Camera (New Link) - OM SYSTEM OM-1 Mark II Instruction Manual

Pairing the Computer with the Camera (New
Link)
The camera and computer must be paired in order to connect. Up to four computers can be paired
with the camera at a time. To pair a computer with the camera, connect it via USB. Pairing need only be
performed once per computer.
1.
After confirming that the camera is off, connect it to the computer using the USB cable.
When attaching the USB cable, using an optional cable protector and cable clip helps
prevent damage to the connectors and disconnection of the table.
Cable Protector (CP-2)" (P.486)
USB port
1
USB cable (supplied)
2
USB connector
3
The locations of USB ports vary from computer to computer. See the documentation
provided with the computer for information on USB ports.
If the USB port on the computer is Type A port, use the optional CB-USB11 cable.
2.
Turn the camera on.
The camera will display a message prompting you to identify the device to which the USB
cable is connected.
If the message is not displayed, select [Select] for
B
If the batteries are very low, the camera will not display a message when connecting to a
C
computer. Be sure the batteries are charged.
1
[USB Mode]
Pairing the Computer with the Camera (New
439
"Cable Clip (CC-1) /
g
3
2
(P.405).
Link)
