eZ80F92 Development Kit
User Manual
10

Operational Description

eZ80F92 Flash Module Interface

Operational Description
Downloaded from
Elcodis.com
electronic components distributor
®
The eZ80
Development Platform can accept any eZ80
modules, provided that the module interfaces correctly to the eZ80
Development Platform. The purpose of the eZ80
is to provide the application developer with a tool to evaluate the features
of the eZ80F92 Flash MCU, and to develop an application without build-
ing additional hardware.
The eZ80F92 Flash Module interface provides easy connection of the
eZ80F92 Flash Module. It also provides easy connection for any eZ80
based module designed to this interface. This includes modules using
®
future eZ80
devices, and user-developed modules using current eZ80
devices.
The eZ80F92 Flash Module interface consists of two 50-pin receptacles,
JP1 and JP2.
Peripheral Bus Connector
Figure 6 illustrates the pin layout of the Peripheral Bus Connector in the
50-pin header, located at position JP1 on the eZ80
form. Table 2 describes the pins and their functions.
PRELIMINARY
®
-core-based
®
®
Development Platform
®
Development Plat-
UM013904-0203
®
-
®
