eZ80L92 Development Kit
User Manual
10

Operational Description

eZ80L92 Module Interface

Operational Description
®
The eZ80 Development Platform can accept any eZ80
modules, provided that the module interfaces correctly to the eZ80
Development Platform. The purpose of the eZ80
is to provide the application developer with a tool to evaluate the features
of the eZ80L92 device and to develop an application without building
additional hardware.
The eZ80L92 Module interface provides easy connection of the eZ80L92
Module. It also provides easy connection for any eZ80
designed to this interface. This includes modules using future eZ80
devices, and user-developed modules using current eZ80
The eZ80L92 Module interface consists of two 50-pin receptacles, JP1
and JP2.
Peripheral Bus Connector
Figure 6 illustrates the pin layout of the Peripheral Bus Connector in the
50-pin header, located at position JP1 on the eZ80
form. Table 2 describes the pins and their functions.
PRELIMINARY
®
-core-based
®
®
Development Platform
®
-based module
®
®
devices.
®
Development Plat-
UM012906-0103
