eZ80

Functional Description

UM013904-0203
Downloaded from Elcodis.com electronic components distributor
®
Development Platform
This section describes the eZ80
components and its interfaces, including detailed programmer interface
information such as memory maps, register definitions, and interrupt
usage.
®
The eZ80 Development Platform consists of seven major hardware
blocks. These blocks, listed below, are diagrammed in Figure 4.
•
eZ80F92 Flash Module interface (2 female headers)
•
Power supply for the eZ80
Flash Module, and application modules
•
Application Module interface (2 male headers)
•
GPIO and LED matrix
•
RS232 serial communications ports
•
Embedded modem interface
• 2
I C devices
®
Development Platform hardware, its key
®
Development Platform, the eZ80F92
PRELIMINARY
eZ80F92 Development Kit
User Manual
®
eZ80 Development Platform
7
