Development Platform Overview
®
The purpose of the eZ80
oper with a set of tools for evaluating the features of the eZ80
devices, and to be able to develop a new application before building appli-
cation hardware.
The eZ80F92 Development Kit features two primary boards: the eZ80
Development Platform and the eZ80F92 Flash Module. This arrangement
provides a full development platform when using both boards. It can also
provide a smaller-sized reference platform with the eZ80F92 Flash Mod-
ule as a stand-alone development tool.
®
The eZ80 Development Platform is designed to accept a number of
application-specific modules and Z8- and eZ80
including the eZ80F92 Flash Module, which features a real-time clock, an
IrDA transceiver, and the eZ80F92 microcontroller.
®
The eZ80 Development Platform, together with its plugged-in eZ80F92
Flash Module, can operate in stand-alone mode with Flash memory, or
interface via the ZPAKII emulator to a host PC running ZiLOG Devel-
oper Studio II Integrated Development Environment (ZDS IDE) software.
The address bus, data bus, and all eZ80F92 Flash Module control signals
are buffered on the eZ80
drive capability.
®
Development Platform is to provide the devel-
®
Development Platform to provide sufficient
PRELIMINARY eZ80
eZ80F92 Development Kit
User Manual
®
-based add-on modules,
®
Development Platform Overview
3
®
family of
®
