alternative:
Maxim
MAX6802UR29D3
IRDA_TXD
IRDA_TXD
IRDA_RXD
IRDA_RXD
IRDA_SD
IRDA_SD
904-0203
Downloaded from Elcodis.com electronic components distributor
power supervisor
V3.3
C9
100nF
U4 0603 R3
2k2
0603
2
RESET
open-drain
C10
MAX6328UR29
10nF
SOT-23-L3
0603
IR-transceiver
V3.3
R5 C11
68R
330nF
R6
U5
2R7, 0.25W
5
1206
VCC
(MMA 020 4)
1
LEDA
IRDA_TXD
2
TXD
IRDA_SD
4
SD
IRDA_RXD
3
RXD
6
GND
Figure 27. Schematic Diagram, #6 of 9—IrDA Reset
PRELIMINARY
-RESET
ZHX1810
eZ80F92 Development Kit
User Manual
-RESET
V3.3
VDD
VSS
GND
Schematic Diagrams
69
