- Page 1 Z16F2800100ZCOG ® ZNEO Z16F Series Development Kit User Manual UM020205-0908 ® Copyright ©2008 by Zilog , Inc. All rights reserved. www.zilog.com...
- Page 2 ZNEO is a registered trademark of Zilog, Inc. All other product or service names are the property of their respective owners. UM020205-0908...
- Page 3 Description Page No September Updated Introduction section. 2008 September Updated Title, Schematics. Implemented Zilog Style 2007 Guide. June 2006 03 Added note on the ZNEO development board 16-bit bus and programming external Flash memory. May 2006 Updated all schematics. Jan. 2006...
-
Page 4: Table Of Contents
Installation ..........1 ZNEO Z16F Series Development Board ..... . 2 Introduction . -
Page 5: Introduction
Z16F Series. This kit allows you to write application software and contains all supporting documents. This User Manual acquaints you with the ZNEO Z16F Series MCU Development Kit, and provides instructions on setting up and using the tools to start building designs and applications. -
Page 6: Zneo Z16F Series Development Board
Introduction The ZNEO Z16F Series development board is a development and proto- typing board for the ZNEO Z16F Series MCU. The board allows you to evaluate the features of ZNEO Z16F Series MCU, and to develop an application before building the hardware. -
Page 7: Features
® ZNEO Z16F Series Development Kit User Manual Features The features of ZNEO Z16F Series of Microcontrollers include: • ZNEO MCU (100-Lead LQFP package) • 1 M x 16 External Flash memory • 256 K x 16 External RAM •... -
Page 8: Development Kit Block Diagram
® ZNEO Z16F Series Development Kit User Manual Development Kit Block Diagram Figure 2 displays the block diagram of ZNEO Z16F Series development kit. GPIO Z8F1285 (128KB FLASH, 4KB SRAM, ZNEO ® 12 channel ADC, 3 channel PWM) 20 MHz... -
Page 9: Zneo Memory Layout
16-bit bus. All Write operation to Flash Memory must be 16 bits at even addresses only. Attempts to Write 1 byte will result in the byte being replicated on both the upper and lower bytes of the 16-bit bus. UM020205-0908 ZNEO Z16F Series Development Board... - Page 10 RAM on any device is FF_8000H ZNEO CPU based devices support 8 K of internal I/O memory located at addresses . This memory contains CPU control FF_E000H–FF_FFFFH registers and other SFRs, on-chip peripherals, and memory-mapped I/O ports. UM020205-0908 ZNEO Z16F Series Development Board...
-
Page 11: Mcu
The ZNEO Z16F Series Flash microcontrollers are based on Zilog’s advanced ZNEO 16-bit CPU core. The ZNEO Z16F Series MCU family of devices sets a new standard of performance and efficiency with a 24-bit address bus and 16-bit data bus. - Page 12 ® ZNEO Z16F Series Development Kit User Manual The Development board contains circuitry to support and present all the features of the ZNEO Z16F Series. The key features of ZNEO Z16F Series include: • 20 MHz ZNEO CPU Core •...
-
Page 13: Uart With Irda Endec
UART with Infrared Encoder/Decoder (ENDEC). The Infrared ENDEC is integrated with an on-chip UART (component U13) allowing easy com- munication between the ZNEO Z16F Series and IrDA transceivers. Infra- red communication provides secure, reliable, low-cost, point-to-point communication between PCs, PDAs, cell phones, printers, and other infrared enabled devices. -
Page 14: Switches And Leds
SPST switch S3, connected to the chip port PC0_T1IN Potentiometer R10 is reserved for future use. Jumper Settings Table 2 provides information on the shunt status, functions, and default settings of jumpers on the ZNEO Z16F Series development board. Table 2. ZNEO Jumper Settings Jumper Status Function... -
Page 15: External Interface Headers Jp1, Jp2, And Jp4
External Flash Write Protect enabled. Note: * These jumpers must not be OUT at the same time. External Interface Headers JP1, JP2, and JP4 External interface headers JP1, JP2, and JP4 are provided in Schematics on page 12. UM020205-0908 ZNEO Z16F Series Development Board... -
Page 16: Schematics
User Manual Schematics Figure 3 through Figure 6 on page 15 display the schematics for the ZNEO Z16F Series Development Kit. Rev C: Swapped ANA 8 and ANA 9 on MCU page and MDS interface page POWER&COMMUNICATIONS MDS INTERFACE D[15:0]... - Page 17 Size Size Size Document Number Document Number Document Number 96C0999-001 96C0999-001 96C0999-001 Date: Date: Date: Monday, May 08, 2006 Monday, May 08, 2006 Monday, May 08, 2006 Sheet Sheet Sheet Figure 4. ZNEO Z16F Series MCU Development Kit UM020205-0908 Schematics...
- Page 18 Size Size Size HDR/PIN 2x13 HDR/PIN 2x13 96C0999-001 96C0999-001 96C0999-001 Document Number Date: Date: Date: Monday, May 08, 2006 Monday, May 08, 2006 Monday, May 08, 2006 Sheet Sheet Sheet Figure 5. ZNEO Z16F Series MCU Development Kit UM020205-0908 Schematics...
- Page 19 Z8F1285 Evaluation Module. Schematic. VCC 3.3V Size Size Size Document Number 96C0999-001 96C0999-001 96C0999-001 Date: Date: Date: Thursday, March 02, 2006 Thursday, March 02, 2006 Thursday, March 02, 2006 Sheet Sheet Sheet Figure 6. ZNEO Z16F Series MCU Development Kit UM020205-0908 Schematics...
-
Page 20: Customer Support
User Manual Customer Support For answers to technical questions about the product, documentation, or any other issues with Zilog’s offerings, please visit Zilog’s Knowledge Base at http://www.zilog.com/kb. For any comments, detail technical questions, or reporting problems, please visit Zilog’s Technical Support at http://support.zilog.com. - Page 21 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: ZiLOG Z16F2800100ZCOG...
